Square D™
Square D™ I-Line™ PowerPact™ QGA222004 Type QG Molded Case Circuit Breaker, 240 VAC, 200 A, 65 kA Interrupt, 2 Poles
Custom_Product_Images_Illustration
Square D™
Square D™ I-Line™ PowerPact™ QGA222004 Type QG Molded Case Circuit Breaker, 240 VAC, 200 A, 65 kA Interrupt, 2 Poles
SKU307536
MFGR #QGA222004
Your Cost: $1,015.30/ea
List: Square D QGA222004 MOLDED CASE CIRCUIT BREAKER 240V 200A,1200 A,200 A,2400 A,2-Pole,200 A,240 V AC,240 V AC,65 kA 240 V AC,G,I-Line Connection (ON end) - Lugs (OFF end) BC,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in
Square D QGA222004 MOLDED CASE CIRCUIT BREAKER 240V 200A,1200 A,200 A,2400 A,2-Pole,200 A,240 V AC,240 V AC,65 kA 240 V AC,G,I-Line Connection (ON end) - Lugs (OFF end) BC,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in
Actuator Type Toggle Alternate Catalog Number QGA222004 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number QGA222004 Connection LUGS LOAD AWG 4...300 KCMIL ALUMINIUM/COPPER-I-LINE CONNECTION LINE BC Connection Type I/ON End Shroud Country of Origin US Currency USD Dimensions 6.47 in H x 3 in W x 3.93 in D EU RoHS Indicator Y Frame Q Series Frequency Rating 50/60 Hz Gross Weight Per Pack 4.7400 lb Gross Weight per Pack Metric 2.15 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 10.7950 in Height [Metric] 10.7950 cm Item Group 01023 Length 31.2750 in Length [Metric] 31.2750 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=435839&lang=en-us Number Of Poles 2 Phase 1 pH Returnable Y Standard IEC-CSA-UL LISTED Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489CSA C22.2 No. 5-02IEC 60947-2PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Sub Brand POWERPACT Substitute Product Catalog Number QBPA Temperature Rating 104 °F Trip Range 1200 to 2400 A Type Type QG UNSPSC 39121601 UPC 11 78590147869 UPC 12 785901478690 Warranty Description Contractual Warranty:18 months Width 18.8930 in Width [Metric] 18.8930 cm Wire Size 4 AWG to 300 kcmil Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 200 A Interrupt Rating 65 kA Trip Type Thermal Magnetic Voltage Rating 240 VAC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE Field installable handle padlock attachment available for locking in ON or OFF position and may be used with available mechanical interlocks
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | QGA222004 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QGA222004 |
| Connection | LUGS LOAD AWG 4...300 KCMIL ALUMINIUM/COPPER-I-LINE CONNECTION LINE BC |
| Connection Type | I/ON End Shroud |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.47 in H x 3 in W x 3.93 in D |
| EU RoHS Indicator | Y |
| Frame | Q Series |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 4.7400 lb |
| Gross Weight per Pack Metric | 2.15 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 10.7950 in |
| Height [Metric] | 10.7950 cm |
| Item Group | 01023 |
| Length | 31.2750 in |
| Length [Metric] | 31.2750 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=435839&lang=en-us |
| Number Of Poles | 2 |
| Phase | 1 pH |
| Returnable | Y |
| Standard | IEC-CSA-UL LISTED |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489CSA C22.2 No. 5-02IEC 60947-2PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Sub Brand | POWERPACT |
| Substitute Product Catalog Number | QBPA |
| Temperature Rating | 104 °F |
| Trip Range | 1200 to 2400 A |
| Type | Type QG |
| UNSPSC | 39121601 |
| UPC 11 | 78590147869 |
| UPC 12 | 785901478690 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 18.8930 in |
| Width [Metric] | 18.8930 cm |
| Wire Size | 4 AWG to 300 kcmil Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 200 A |
| Interrupt Rating | 65 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 240 VAC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE |
| Field installable handle padlock attachment available for locking in ON or OFF position and may be used with available mechanical interlocks |
