Square D™ I-Line™ PowerPact™ MGA36350 80% Rated Molded Case Circuit Breaker, 600 VAC, 350 A, 3 Poles
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ MGA36350 80% Rated Molded Case Circuit Breaker, 600 VAC, 350 A, 3 Poles
SKU714057
MFGR #MGA36350
Your Cost: $5,852.30/ea
List: Square D MGA36350 MOLDED CASE CIRCUIT BREAKER 600V 350A,12.80 in.,3-Phase,350A,350A,3P,40deg Celsius,50/60Hz,600 Vac,65kA240Vac - 35kA480Vac - 18kA600Vac,8.10 in.,8.30 in.,Ambient environment,Basic (ET1.0) Fixed Long-Time Adjustable Instantaneous Trip,Electronic,Electronic Trip Circuit Breaker,I-Line Connection (ON end) - Lugs (OFF end) ABC,I-Line Plug-On,M-Frame,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,Various
Square D MGA36350 MOLDED CASE CIRCUIT BREAKER 600V 350A,12.80 in.,3-Phase,350A,350A,3P,40deg Celsius,50/60Hz,600 Vac,65kA240Vac - 35kA480Vac - 18kA600Vac,8.10 in.,8.30 in.,Ambient environment,Basic (ET1.0) Fixed Long-Time Adjustable Instantaneous Trip,Electronic,Electronic Trip Circuit Breaker,I-Line Connection (ON end) - Lugs (OFF end) ABC,I-Line Plug-On,M-Frame,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,Various
Actuator ELECTRONIC Alternate Catalog Number MGA36350 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number MGA36350 Connection I-LINE CONNECTION (ON END) - LUGS (OFF END) ABC Connection Type Line/Load Lugs Country of Origin US Currency USD Dimensions 8.1 in L x 8.3 in W x 12.8 in H Enclosure Type NEMA AB1 Environmental Conditions AMBIENT ENVIRONMENT EU RoHS Indicator Y Frame M Frame Frequency Rating 50/60 Hz Gross Weight Per Pack 29.0000 lb Harmonization Tariff Schedule Code 8536200020 Height 32.7000 in Item Group 01200 Length 21.0000 in Material Various Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430827&lang=en-us Mounting Type Plug-On Number Of Poles 3 Operating Temperature 40 °C Phase 3 pH Returnable Y Standard UL LISTED - CSA CERTIFIED - IEC RATED Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 700 to 3500 A Type 80% Rated UNSPSC 39121601 UPC 11 78590149609 UPC 12 785901496090 Warranty Description Contractual Warranty:18 months Width 0.8000 in Wire Size 3/0 AWG to 500 kcmil Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 350 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC Trip Type Electronic Basic ET 1.0 LI Voltage Rating 600 VAC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE PLUG-ON True RMS sensing devices Provide means to manually disconnect power to the circuit Provide enhanced coordination by their adjustability Provide high interrupting ratings and withstand ratings
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | ELECTRONIC |
| Alternate Catalog Number | MGA36350 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | MGA36350 |
| Connection | I-LINE CONNECTION (ON END) - LUGS (OFF END) ABC |
| Connection Type | Line/Load Lugs |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 8.1 in L x 8.3 in W x 12.8 in H |
| Enclosure Type | NEMA AB1 |
| Environmental Conditions | AMBIENT ENVIRONMENT |
| EU RoHS Indicator | Y |
| Frame | M Frame |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 29.0000 lb |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 32.7000 in |
| Item Group | 01200 |
| Length | 21.0000 in |
| Material | Various |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430827&lang=en-us |
| Mounting Type | Plug-On |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 pH |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED - IEC RATED |
| Sub Brand | POWERPACT |
| Temperature Rating | 104 °F |
| Trip Range | 700 to 3500 A |
| Type | 80% Rated |
| UNSPSC | 39121601 |
| UPC 11 | 78590149609 |
| UPC 12 | 785901496090 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 0.8000 in |
| Wire Size | 3/0 AWG to 500 kcmil Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 350 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC |
| Trip Type | Electronic Basic ET 1.0 LI |
| Voltage Rating | 600 VAC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE PLUG-ON |
| True RMS sensing devices |
| Provide means to manually disconnect power to the circuit |
| Provide enhanced coordination by their adjustability |
| Provide high interrupting ratings and withstand ratings |
