Square D™ I-Line™ PowerPact™ JLA262001 Molded Case Circuit Breaker, 600 VAC, 200 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ JLA262001 Molded Case Circuit Breaker, 600 VAC, 200 A, 2 Poles, Thermal Magnetic Trip
SKUPDW~6404971
MFGR #JLA262001
Price Not Available
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
Actuator Type Toggle Alternate Catalog Number JLA262001 ARRA Compliant N Buy American Compliant N Catalog Number JLA262001 Connection AWG 3/0...350 KCMIL ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D EU RoHS Indicator Y Frame J Frame Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0204 lb Gross Weight per Pack Metric 2.04 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.6530 in Height [Metric] 13.6530 cm Item Group 01122 Length 37.1480 in Length [Metric] 37.1480 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=426263&lang=en-us Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable Y Standard CE-IEC-UL LISTED-CCC-CSA Temperature Rating 104 °F Trip Range 1000 to 2000 A Type 80% Rated UNSPSC 39121601 UPC 11 78590193929 UPC 12 785901939290 Warranty Description Contractual Warranty:18 months Width 20.6380 in Width [Metric] 20.6380 cm Wire Size 3/0 AWG to 350 kcmil Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 200 A Interrupt Rating 125 kA at 240 VAC/100 kA at 480 VAC/50 kA at 600 VAC/20 kA at 250 VDC/50 kA at 500 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC I-LINE Rated current from 70 to 250 A Breaking capacity from 18 to 65 kA at 480 VAC Common accessories and auxiliaries with other PowerPact™ frames 20 kA at 250 VDC, 125 kA at 240 VAC, 100 kA at 480 VAC, 50 kA at 600 VAC, 50 kA at 500 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | JLA262001 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | JLA262001 |
| Connection | AWG 3/0...350 KCMIL ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 2.74 in W x 4.36 in D |
| EU RoHS Indicator | Y |
| Frame | J Frame |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0204 lb |
| Gross Weight per Pack Metric | 2.04 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.6530 in |
| Height [Metric] | 13.6530 cm |
| Item Group | 01122 |
| Length | 37.1480 in |
| Length [Metric] | 37.1480 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=426263&lang=en-us |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | CE-IEC-UL LISTED-CCC-CSA |
| Temperature Rating | 104 °F |
| Trip Range | 1000 to 2000 A |
| Type | 80% Rated |
| UNSPSC | 39121601 |
| UPC 11 | 78590193929 |
| UPC 12 | 785901939290 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 20.6380 in |
| Width [Metric] | 20.6380 cm |
| Wire Size | 3/0 AWG to 350 kcmil |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 200 A |
| Interrupt Rating | 125 kA at 240 VAC/100 kA at 480 VAC/50 kA at 600 VAC/20 kA at 250 VDC/50 kA at 500 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC |
| I-LINE |
| Rated current from 70 to 250 A |
| Breaking capacity from 18 to 65 kA at 480 VAC |
| Common accessories and auxiliaries with other PowerPact™ frames |
| 20 kA at 250 VDC, 125 kA at 240 VAC, 100 kA at 480 VAC, 50 kA at 600 VAC, 50 kA at 500 VDC interrupt rating |
