Square D™
Square D™ I-Line™ PowerPact™ HJA261502 Type HJA Molded Case Circuit Breaker, 600 VAC/250 VDC, 150 A, 2 Poles
Custom_Product_Images_Illustration
Square D™
Square D™ I-Line™ PowerPact™ HJA261502 Type HJA Molded Case Circuit Breaker, 600 VAC/250 VDC, 150 A, 2 Poles
SKU1024987
MFGR #HJA261502
Your Cost: $4,465.60/ea
List: Square D HJA261502 MOLDED CASE CIRCUIT BREAKER 600V 150A,150 A,150 A,1700 A,900 A,2-Pole,600 V AC,600 V AC,65 kA 480 V AC-25 kA 600 V AC-100 kA 240 V AC,I-Line Connection (ON end) - Lugs (OFF end) AC,J,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Square D HJA261502 MOLDED CASE CIRCUIT BREAKER 600V 150A,150 A,150 A,1700 A,900 A,2-Pole,600 V AC,600 V AC,65 kA 480 V AC-25 kA 600 V AC-100 kA 240 V AC,I-Line Connection (ON end) - Lugs (OFF end) AC,J,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Actuator Type Toggle Alternate Catalog Number HJA261502 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number HJA261502 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Connection Type A-Line/Line/Load Lugs Country of Origin US Currency USD Dimensions 9.73 in H x 2.94 in W x 4.8 in D EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 3.9900 lb Gross Weight per Pack Metric 1.81 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.6530 in Height [Metric] 13.6530 cm Item Group 01117 Length 37.1480 in Length [Metric] 37.1480 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423367&lang=en-us Mounting Type Plug-In/Unit Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable Y Standard CSA-CE-IEC-UL LISTED Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 900 to 1700 A Type Type HJA UNSPSC 39121601 UPC 11 78590193927 UPC 12 785901939276 Warranty Description Contractual Warranty:18 months Width 20.6380 in Width [Metric] 20.6380 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 150 A Interrupt Rating 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 VDC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | HJA261502 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HJA261502 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Connection Type | A-Line/Line/Load Lugs |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 9.73 in H x 2.94 in W x 4.8 in D |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 3.9900 lb |
| Gross Weight per Pack Metric | 1.81 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.6530 in |
| Height [Metric] | 13.6530 cm |
| Item Group | 01117 |
| Length | 37.1480 in |
| Length [Metric] | 37.1480 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423367&lang=en-us |
| Mounting Type | Plug-In/Unit |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | CSA-CE-IEC-UL LISTED |
| Sub Brand | POWERPACT |
| Temperature Rating | 104 °F |
| Trip Range | 900 to 1700 A |
| Type | Type HJA |
| UNSPSC | 39121601 |
| UPC 11 | 78590193927 |
| UPC 12 | 785901939276 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 20.6380 in |
| Width [Metric] | 20.6380 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 150 A |
| Interrupt Rating | 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 VDC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating |
