Square D™ I-Line™ PowerPact™ HGA36045 Type HGA Molded Case Circuit Breaker, 600 VAC/250 to 500 VDC, 45 A, 3 Poles
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ HGA36045 Type HGA Molded Case Circuit Breaker, 600 VAC/250 to 500 VDC, 45 A, 3 Poles
SKU433177
MFGR #HGA36045
$/ea
Square D HGA36045 MOLDED CASE CIRCUIT BREAKER 600V 45A,3-Pole,400 A,45 A,850 A,45 A,600 V AC,600 V AC,65 kA 240 V AC-35 kA 480 V AC-18 kA 600 V AC,G,I-Line Connection (ON end) - Lugs (OFF end) ABC,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Square D HGA36045 MOLDED CASE CIRCUIT BREAKER 600V 45A,3-Pole,400 A,45 A,850 A,45 A,600 V AC,600 V AC,65 kA 240 V AC-35 kA 480 V AC-18 kA 600 V AC,G,I-Line Connection (ON end) - Lugs (OFF end) ABC,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,plug-in,thermal-magnetic
Alternate Catalog Number HGA36045 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number HGA36045 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Connection Type A-Line/Line/Load Lugs Country of Origin MX Currency USD Dimensions 9.73 in H x 4.48 in W x 4.8 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Volume Per Pack 765.00 Gross Volume per Pack Metric 12536.06 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.0247 lb Gross Weight per Pack Metric 2.47 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 15.2400 in Height [Metric] 15.2400 cm Item Group 01117 Length 38.1000 in Length [Metric] 38.1000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422443&lang=en-us Mounting Type Plug-On Number Of Poles 3 Operating Temperature 40 °C Phase 3 pH Returnable Y Standard CE-CSA-IEC-UL LISTED Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 400 to 850 A Type Type HGA UNSPSC 39121601 UPC 11 78590142231 UPC 12 785901422310 Warranty Description Contractual Warranty:18 months Width 21.5900 in Width [Metric] 21.5900 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 45 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC/500 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 to 500 VDC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency ABC-phase connection 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 500 VDC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | HGA36045 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HGA36045 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Connection Type | A-Line/Line/Load Lugs |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 9.73 in H x 4.48 in W x 4.8 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 765.00 |
| Gross Volume per Pack Metric | 12536.06 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.0247 lb |
| Gross Weight per Pack Metric | 2.47 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 15.2400 in |
| Height [Metric] | 15.2400 cm |
| Item Group | 01117 |
| Length | 38.1000 in |
| Length [Metric] | 38.1000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422443&lang=en-us |
| Mounting Type | Plug-On |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 pH |
| Returnable | Y |
| Standard | CE-CSA-IEC-UL LISTED |
| Sub Brand | POWERPACT |
| Temperature Rating | 104 °F |
| Trip Range | 400 to 850 A |
| Type | Type HGA |
| UNSPSC | 39121601 |
| UPC 11 | 78590142231 |
| UPC 12 | 785901422310 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 21.5900 in |
| Width [Metric] | 21.5900 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 45 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC/500 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 to 500 VDC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| ABC-phase connection |
| 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 500 VDC, 20 kA at 250 VDC interrupt rating |
