Square D™
Square D™ I-Line™ PowerPact™ HGA261503 Molded Case Circuit Breaker, 600 VAC, 150 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Square D™ I-Line™ PowerPact™ HGA261503 Molded Case Circuit Breaker, 600 VAC, 150 A, 2 Poles, Thermal Magnetic Trip
SKUPDW~11720166
MFGR #HGA261503
Price Not Available
Schneider Electric HGA261503,MOLDED CASE CIRCUIT BREAKER 600V 150A
Schneider Electric HGA261503,MOLDED CASE CIRCUIT BREAKER 600V 150A
Alternate Catalog Number HGA261503 ARRA Compliant N Buy American Compliant N Catalog Number HGA261503 Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0136 lb Gross Weight per Pack Metric 1.36 Gross Weight UOM Metric kg Height 9.8430 in Height [Metric] 9.8430 cm Item Group 01117 Length 37.1480 in Length [Metric] 37.1480 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422393&lang=en-us Mounting Type Surface Number Of Poles 2 Phase 1 pH Returnable N Standards ARRA, Buy American Act Compliant, CSA C22.2 No. 5 File No. LR40970, CCC, CE, Federal Specification W-C-375B/GEN, IEC 60947-2, RoHS Compliant, UL 489 File No. E10027 Temperature Rating 104 °F Trip Range 900 to 1700 A UNSPSC 39121616 UPC 11 78590148337 UPC 12 785901483373 Warranty Description Contractual Warranty:18 months Width 20.6380 in Width [Metric] 20.6380 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 150 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250/500 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC Easy to install, extremely versatile, a wide variety of terminal Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | HGA261503 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HGA261503 |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 2.74 in W x 4.36 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0136 lb |
| Gross Weight per Pack Metric | 1.36 |
| Gross Weight UOM Metric | kg |
| Height | 9.8430 in |
| Height [Metric] | 9.8430 cm |
| Item Group | 01117 |
| Length | 37.1480 in |
| Length [Metric] | 37.1480 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422393&lang=en-us |
| Mounting Type | Surface |
| Number Of Poles | 2 |
| Phase | 1 pH |
| Returnable | N |
| Standards | ARRA, Buy American Act Compliant, CSA C22.2 No. 5 File No. LR40970, CCC, CE, Federal Specification W-C-375B/GEN, IEC 60947-2, RoHS Compliant, UL 489 File No. E10027 |
| Temperature Rating | 104 °F |
| Trip Range | 900 to 1700 A |
| UNSPSC | 39121616 |
| UPC 11 | 78590148337 |
| UPC 12 | 785901483373 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 20.6380 in |
| Width [Metric] | 20.6380 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 150 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250/500 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC |
| Easy to install, extremely versatile, a wide variety of terminal |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
