Square D™ I-Line™ PowerPact™ HGA260605 Molded Case Circuit Breaker, 600 VAC, 60 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ HGA260605 Molded Case Circuit Breaker, 600 VAC, 60 A, 2 Poles, Thermal Magnetic Trip
SKUPDW~6403463
MFGR #HGA260605
$/ea
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
Alternate Catalog Number HGA260605 ARRA Compliant N Buy American Compliant N Catalog Number HGA260605 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Country of Origin US Currency USD EU RoHS Indicator Y Frame G Gross Weight Per Pack 0.0136 lb Gross Weight per Pack Metric 1.36 Gross Weight UOM Metric kg Height 9.8430 in Height [Metric] 9.8430 cm Item Group 01117 Length 37.1480 in Length [Metric] 37.1480 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422287&lang=en-us Number Of Poles 2 Operating Temperature 40 °C Phase CA Returnable N Standard UL LISTED-CSA-CE-IEC Standards ARRA, Buy American Act Compliant, CSA C22.2 No. 5 File No. LR40970, CCC, CE, Federal Specification W-C-375B/GEN, IEC 60947-2, RoHS Compliant, UL 489 File No. E10027 Trip Range 1450 A,60 A,800 A Type Circuit Breaker UNSPSC 39121601 UPC 11 78590149121 UPC 12 785901491217 Warranty Description Contractual Warranty:18 months Width 20.6380 in Width [Metric] 20.6380 cm Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 60 A Interrupt Rating 250 V DC-500 V DC-600 V AC,65 KA AT 240 V AC-35 KA AT 480 V AC-18 KA AT 600 V AC-20 KA AT 500 V DC-20 KA AT 250 V DC Trip Type Thermal-magnetic Voltage Rating 250 V DC-600 V AC-500 V DC I-LinE Easy to install, extremely versatile, a wide variety of terminal Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | HGA260605 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HGA260605 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Country of Origin | US |
| Currency | USD |
| EU RoHS Indicator | Y |
| Frame | G |
| Gross Weight Per Pack | 0.0136 lb |
| Gross Weight per Pack Metric | 1.36 |
| Gross Weight UOM Metric | kg |
| Height | 9.8430 in |
| Height [Metric] | 9.8430 cm |
| Item Group | 01117 |
| Length | 37.1480 in |
| Length [Metric] | 37.1480 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422287&lang=en-us |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | CA |
| Returnable | N |
| Standard | UL LISTED-CSA-CE-IEC |
| Standards | ARRA, Buy American Act Compliant, CSA C22.2 No. 5 File No. LR40970, CCC, CE, Federal Specification W-C-375B/GEN, IEC 60947-2, RoHS Compliant, UL 489 File No. E10027 |
| Trip Range | 1450 A,60 A,800 A |
| Type | Circuit Breaker |
| UNSPSC | 39121601 |
| UPC 11 | 78590149121 |
| UPC 12 | 785901491217 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 20.6380 in |
| Width [Metric] | 20.6380 cm |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 60 A |
| Interrupt Rating | 250 V DC-500 V DC-600 V AC,65 KA AT 240 V AC-35 KA AT 480 V AC-18 KA AT 600 V AC-20 KA AT 500 V DC-20 KA AT 250 V DC |
| Trip Type | Thermal-magnetic |
| Voltage Rating | 250 V DC-600 V AC-500 V DC |
| I-LinE |
| Easy to install, extremely versatile, a wide variety of terminal |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
