Square D™ I-Line™ PowerPact™ HGA260405 Molded Case Circuit Breaker, 600 VAC, 40 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ I-Line™ PowerPact™ HGA260405 Molded Case Circuit Breaker, 600 VAC, 40 A, 2 Poles, Thermal Magnetic Trip
SKUPDW~6403451
MFGR #HGA260405
$/ea
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
Alternate Catalog Number HGA260405 ARRA Compliant N Buy American Compliant N Catalog Number HGA260405 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 6.8000 lb Gross Weight per Pack Metric 680.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200020 Height 6.0000 in Height [Metric] 6.0000 cm Item Group 01117 Length 21.0000 in Length [Metric] 21.0000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422243&lang=en-us Mounting Type Surface Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable Y Standard CSA-UL LISTED-IEC-CE Temperature Rating 104 °F Trip Range 400 to 850 A Type Type HGA UNSPSC 39121601 UPC 11 78590149109 UPC 12 785901491095 Warranty Description Contractual Warranty:18 months Width 12.0000 in Width [Metric] 12.0000 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 40 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250/500 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 to 500 VDC I-LINE Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency CA-phase 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 500 VDC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Media
- Substitute Products
| Alternate Catalog Number | HGA260405 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HGA260405 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,I-LINE CONNECTION LINE-LUGS LOAD |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 2.74 in W x 4.36 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 6.8000 lb |
| Gross Weight per Pack Metric | 680.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 6.0000 in |
| Height [Metric] | 6.0000 cm |
| Item Group | 01117 |
| Length | 21.0000 in |
| Length [Metric] | 21.0000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422243&lang=en-us |
| Mounting Type | Surface |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | CSA-UL LISTED-IEC-CE |
| Temperature Rating | 104 °F |
| Trip Range | 400 to 850 A |
| Type | Type HGA |
| UNSPSC | 39121601 |
| UPC 11 | 78590149109 |
| UPC 12 | 785901491095 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 12.0000 in |
| Width [Metric] | 12.0000 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 40 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250/500 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 to 500 VDC |
| I-LINE |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| CA-phase |
| 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 500 VDC, 20 kA at 250 VDC interrupt rating |
