Square D™
Square D™ I-Line™ LHP36400MB Molded Case Circuit Breaker With Short Lever Operator, 600 VAC, 400 A, 3 Poles
Custom_Product_Images_Illustration
Square D™
Square D™ I-Line™ LHP36400MB Molded Case Circuit Breaker With Short Lever Operator, 600 VAC, 400 A, 3 Poles
SKU295037
MFGR #LHP36400MB
Call For Price
List: Square D LHP36400MB MOLDED CASE CIRCUIT BREAKER 600V 400A,25 kA at 600 V AC-50 kA at 250 V DC-65 kA at 240 V AC-35 kA at 480 V AC,600 V AC,3P,400 A,400 A,600 V AC,H,UL Listed,circuit breaker,thermal-magnetic,unit mount
Square D LHP36400MB MOLDED CASE CIRCUIT BREAKER 600V 400A,25 kA at 600 V AC-50 kA at 250 V DC-65 kA at 240 V AC-35 kA at 480 V AC,600 V AC,3P,400 A,400 A,600 V AC,H,UL Listed,circuit breaker,thermal-magnetic,unit mount
Actuator SHORT LEVER Actuator Type Short Lever Alternate Catalog Number LHP36400MB ARRA Compliant N Buy American Compliant N Catalog Number LHP36400MB Connection AWG 1...600 KCMIL ALUMINIUM/COPPER)1 -AWG 1...250 KCMIL ALUMINIUM/COPPER)2,LUGS LOAD-TERMINAL LINE Connection Type Line/Load Lugs Country of Origin MX Currency USD Dimensions 12-1/2 in H x 6 in W x 4 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame L Frame Frequency Rating 50/60 Hz Gross Volume Per Pack 1851.50 Gross Volume per Pack Metric 30340.53 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.0710 lb Gross Weight per Pack Metric 7.10 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 23.1000 CM Height [Metric] 23.1000 cm Item Group 00935 Length 44.2000 CM Length [Metric] 44.2000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430617&lang=en-us Mounting Type Unit Number Of Poles 3 Phase 3 pH Returnable Y Standard UL LISTED-CSA Temperature Rating -13 to 158 °F Trip Range 2000 to 4000 A Type CIRCUIT BREAKER,HANDLE UNSPSC 39121601 UPC 11 78590120512 UPC 12 785901205128 Warranty Description Contractual Warranty:18 months Width 29.0000 CM Width [Metric] 29.2000 cm Wire Size 1 AWG to 600 kcmil/1 AWG to 250 kcmil Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 400 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480 VAC/25 kA at 600 VAC/50 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC UNIT MOUNT 65 kA at 240 VAC, 35 kA at 480 VAC, 25 kA at 600 VAC, 50 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Actuator | SHORT LEVER |
| Actuator Type | Short Lever |
| Alternate Catalog Number | LHP36400MB |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | LHP36400MB |
| Connection | AWG 1...600 KCMIL ALUMINIUM/COPPER)1 -AWG 1...250 KCMIL ALUMINIUM/COPPER)2,LUGS LOAD-TERMINAL LINE |
| Connection Type | Line/Load Lugs |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 12-1/2 in H x 6 in W x 4 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | L Frame |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 1851.50 |
| Gross Volume per Pack Metric | 30340.53 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.0710 lb |
| Gross Weight per Pack Metric | 7.10 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 23.1000 CM |
| Height [Metric] | 23.1000 cm |
| Item Group | 00935 |
| Length | 44.2000 CM |
| Length [Metric] | 44.2000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430617&lang=en-us |
| Mounting Type | Unit |
| Number Of Poles | 3 |
| Phase | 3 pH |
| Returnable | Y |
| Standard | UL LISTED-CSA |
| Temperature Rating | -13 to 158 °F |
| Trip Range | 2000 to 4000 A |
| Type | CIRCUIT BREAKER,HANDLE |
| UNSPSC | 39121601 |
| UPC 11 | 78590120512 |
| UPC 12 | 785901205128 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 29.0000 CM |
| Width [Metric] | 29.2000 cm |
| Wire Size | 1 AWG to 600 kcmil/1 AWG to 250 kcmil Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 400 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480 VAC/25 kA at 600 VAC/50 kA at 250 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC |
| UNIT MOUNT |
| 65 kA at 240 VAC, 35 kA at 480 VAC, 25 kA at 600 VAC, 50 kA at 250 VDC interrupt rating |
