Square D™ I-Line™ FHP3600015MMT Type FH Automatic High Interrupting Molded Case Switch, 600 VAC/250 VDC, 150 A, 3 Poles
Custom_Product_Images_Illustration
Square D™ I-Line™ FHP3600015MMT Type FH Automatic High Interrupting Molded Case Switch, 600 VAC/250 VDC, 150 A, 3 Poles
SKU661634
MFGR #FHP3600015MMT
Your Cost: $1,984.38/ea
Square D FHP3600015MMT by Schneider Electric AUTOMATIC MOLDED CASE SWITCH 600V 150A,Square D
Square D FHP3600015MMT by Schneider Electric AUTOMATIC MOLDED CASE SWITCH 600V 150A,Square D
Catalog Number FHP3600015MMT Connection Type Line/Load Lug Country of Origin MX Dimensions 6.4 in H x 4.5 in W x 4.13 in D Enclosure Type NEMA 1/3R/4/4X/5/7/9/12 Frame F Frequency Rating 50/60 Hz Gross Weight Per Pack 4.5800 lb Item Group 00903 Mounting Type Bolt/Unit Number Of Poles 3 Returnable N Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489CSA C22.2 No. 5-02NOM CertifiedHARC Ratedeccn: EAR99 Trip Range 900 to 1700 A Type Type FH Automatic High Interrupting UNSPSC 39121616 UPC 11 78590114961 UPC 12 78590114961 Wire Size 12 to 2/0 AWG Al/14 to 2/0 AWG Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 150 A Interrupt Rating 65 kA at 240 VAC/25 kA at 480 VAC/18 kA at 600 VAC/50 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 VDC UNIT MOUNT 65 kA at 240 VAC, 18 kA at 600 VAC, 50 kA at 250 VDC, 25 kA at 480 VAC interrupt rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Media
- Substitute Products
| Catalog Number | FHP3600015MMT |
| Connection Type | Line/Load Lug |
| Country of Origin | MX |
| Dimensions | 6.4 in H x 4.5 in W x 4.13 in D |
| Enclosure Type | NEMA 1/3R/4/4X/5/7/9/12 |
| Frame | F |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 4.5800 lb |
| Item Group | 00903 |
| Mounting Type | Bolt/Unit |
| Number Of Poles | 3 |
| Returnable | N |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489CSA C22.2 No. 5-02NOM CertifiedHARC Ratedeccn: EAR99 |
| Trip Range | 900 to 1700 A |
| Type | Type FH Automatic High Interrupting |
| UNSPSC | 39121616 |
| UPC 11 | 78590114961 |
| UPC 12 | 78590114961 |
| Wire Size | 12 to 2/0 AWG Al/14 to 2/0 AWG Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 150 A |
| Interrupt Rating | 65 kA at 240 VAC/25 kA at 480 VAC/18 kA at 600 VAC/50 kA at 250 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 VDC |
| UNIT MOUNT |
| 65 kA at 240 VAC, 18 kA at 600 VAC, 50 kA at 250 VDC, 25 kA at 480 VAC interrupt rating |
