Square D™ HOM2200BB Type HOM Standard Miniature Circuit Breaker, 120/240 VAC, 200 A, 10 kA Interrupt, 2 Poles
Custom_Product_Images_Illustration
Square D™ HOM2200BB Type HOM Standard Miniature Circuit Breaker, 120/240 VAC, 200 A, 10 kA Interrupt, 2 Poles
SKU100087
MFGR #HOM2200BB
Your Cost: $497.49/ea
Square D HOM2200BB MINIATURE CIRCUIT BREAKER 120/240V 200A,10kA,120/240VAC,200A,HomeLine,Miniature Circuit Breaker,Provides overload and short circuit protection,Screw #4-300 AWG/kcmil (Al/Cu),UL Listed - CSA Certified
Square D HOM2200BB MINIATURE CIRCUIT BREAKER 120/240V 200A,10kA,120/240VAC,200A,HomeLine,Miniature Circuit Breaker,Provides overload and short circuit protection,Screw #4-300 AWG/kcmil (Al/Cu),UL Listed - CSA Certified
Alternate Catalog Number HOM2200BB Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number HOM2200BB Connection SCREW #4-300 AWG/KCMIL (AL/CU) Connection Type Screw Country of Origin US Currency USD Dimensions 3.13 in H x 2 in W x 2.98 in D EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Volume Per Pack 303.69 Gross Volume per Pack Metric 4976.54 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 3.0600 lb Gross Weight per Pack Metric 1.39 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 14.7320 in Height [Metric] 14.7320 cm Item Group 00144 Length 20.3200 in Length [Metric] 20.3200 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=398079&lang=en-us Mounting PLUG-IN Mounting Type Plug-In Number Of Poles 2 Operating Temperature 40 °C Phase 1 Returnable Y Standard UL LISTED - CSA CERTIFIED Standards UL Listed, HACR Rated Sub Brand HOMELINE Substitute Product Catalog Number HOM4080M200PCVP Temperature Rating 40 °C Type Standard UNSPSC 39121601 UPC 11 78590187660 UPC 12 785901876601 Warranty Description Contractual Warranty:Lifetime Width 18.5420 in Width [Metric] 18.5420 cm Wire Size 4 AWG to 300 kcmil Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 200 A Interrupt Rating 10 kA Trip Type Instantaneous/Long Time Voltage Rating 120/240 VAC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION STANDARD Square D is the industry leader in circuit protection with a long-standing reputation for quality and reliability Square D offers Homeline a wide range of circuit breakers to meet all National electric code requirements and provide superior electrical safety Homeline load centers accept plug-on neutral, pigtail, full-size, and tandem circuit breakers on every space Faster installation fewer connections Saves wire fully distributed split neutral bar Frees gutter space no pigtails Easier troubleshooting TIME SAVER diagnostics provide additional circuit information at the touch of a button Faster and easier wiring All spaces accept tandems The Square D Homeline circuit breakers are in a 1 in wide format for 1-pole circuit breakers They are designed to plug into Homeline load centers Cu/Al wire
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | HOM2200BB |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HOM2200BB |
| Connection | SCREW #4-300 AWG/KCMIL (AL/CU) |
| Connection Type | Screw |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 3.13 in H x 2 in W x 2.98 in D |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 303.69 |
| Gross Volume per Pack Metric | 4976.54 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 3.0600 lb |
| Gross Weight per Pack Metric | 1.39 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 14.7320 in |
| Height [Metric] | 14.7320 cm |
| Item Group | 00144 |
| Length | 20.3200 in |
| Length [Metric] | 20.3200 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=398079&lang=en-us |
| Mounting | PLUG-IN |
| Mounting Type | Plug-In |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED |
| Standards | UL Listed, HACR Rated |
| Sub Brand | HOMELINE |
| Substitute Product Catalog Number | HOM4080M200PCVP |
| Temperature Rating | 40 °C |
| Type | Standard |
| UNSPSC | 39121601 |
| UPC 11 | 78590187660 |
| UPC 12 | 785901876601 |
| Warranty Description | Contractual Warranty:Lifetime |
| Width | 18.5420 in |
| Width [Metric] | 18.5420 cm |
| Wire Size | 4 AWG to 300 kcmil |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 200 A |
| Interrupt Rating | 10 kA |
| Trip Type | Instantaneous/Long Time |
| Voltage Rating | 120/240 VAC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| STANDARD |
| Square D is the industry leader in circuit protection with a long-standing reputation for quality and reliability |
| Square D offers Homeline a wide range of circuit breakers to meet all National electric code requirements and provide superior electrical safety |
| Homeline load centers accept plug-on neutral, pigtail, full-size, and tandem circuit breakers on every space |
| Faster installation fewer connections |
| Saves wire fully distributed split neutral bar |
| Frees gutter space no pigtails |
| Easier troubleshooting TIME SAVER diagnostics provide additional circuit information at the touch of a button |
| Faster and easier wiring All spaces accept tandems |
| The Square D Homeline circuit breakers are in a 1 in wide format for 1-pole circuit breakers |
| They are designed to plug into Homeline load centers |
| Cu/Al wire |
