Square D™ EGB36050 Type EGB Circuit Breaker, 600Y/347 VAC, 50 A, 65 kA at 240 VAC/35 kA at 480Y/277 VAC Interrupt
Custom_Product_Images_Illustration
Square D™ EGB36050 Type EGB Circuit Breaker, 600Y/347 VAC, 50 A, 65 kA at 240 VAC/35 kA at 480Y/277 VAC Interrupt
SKU432821
MFGR #EGB36050
$/ea
Square D EGB36050 MINIATURE CIRCUIT BREAKER 600V 50A,2.94 inches,3 phase,3 pole,4.05 inches,5.66 inches,50 A,50/60 Hz,600Y/347 Vac,65 kAIC 240 Vac 35 kAIC 480 Vac,Bolt-On,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,E-Frame,Lugs (1) 14 AWG-2/0 Al or Cu,Molded Case Circuit Breaker,NF Branch Circuit Breakers (Bolt-on),NF Panelboard,Provides overload and short circuit protection,Thermal Magnetic,Thermoset composite resin,UL Listed - CSA Certified,http//cisnt06.c076.us.schneider-electric.com/pubs/Circuit20Protection/Molded20Case20Circuit20Breakers/012520A20Frame20EDB-EGB-EJB/515-3.pdf
Square D EGB36050 MINIATURE CIRCUIT BREAKER 600V 50A,2.94 inches,3 phase,3 pole,4.05 inches,5.66 inches,50 A,50/60 Hz,600Y/347 Vac,65 kAIC 240 Vac 35 kAIC 480 Vac,Bolt-On,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,E-Frame,Lugs (1) 14 AWG-2/0 Al or Cu,Molded Case Circuit Breaker,NF Branch Circuit Breakers (Bolt-on),NF Panelboard,Provides overload and short circuit protection,Thermal Magnetic,Thermoset composite resin,UL Listed - CSA Certified,http//cisnt06.c076.us.schneider-electric.com/pubs/Circuit20Protection/Molded20Case20Circuit20Breakers/012520A20Frame20EDB-EGB-EJB/515-3.pdf
Alternate Catalog Number EGB36050 Application HACR rated; NF panelboard ARRA Compliant N Buy American Compliant N Catalog Number EGB36050 Connection LUGS: (1) 14 AWG-2/0 AL OR CU Connection Type Lug Country of Origin MX Currency USD Depth 4.05 in Dimensions 5.8 in H x 2.94 in W x 4.05 in D Enclosure NF PANELBOARD EU RoHS Indicator Y Frame E Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0165 lb Gross Weight per Pack Metric 1.65 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 12.1920 in Height [Metric] 12.1920 cm Item Group 00936 Length 25.1460 in Length [Metric] 25.1460 cm Material Thermoset Composite Resin Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423254430&lang=en-us Mounting Type Bolt-On Number Of Poles 3 Operating Temperature 40 °C Phase 3 pH Returnable Y Standard UL LISTED - CSA CERTIFIED Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCSA File No. LR92886Federal Specification W-C-375B/GENNOM 117cULus ListedUL 489 File No. E84967PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Sub Brand NF BRANCH CIRCUIT BREAKERS (BOLT-ON) Temperature Rating 104 °F Trip Range 630 to 1800 A Type Type EGB UNSPSC 39121603 UPC 11 78590123557 UPC 12 785901235576 Warranty Description Contractual Warranty:18 months Width 15.7480 in Width [Metric] 15.7480 cm Wire Size 12 to 2/0 AWG Al, 14 to 2/0 AWG Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 50 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480Y/277 VAC Trip Type Thermal Magnetic Voltage Rating 600Y/347 VAC HACR rated; NF panelboard BOLT-ON
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | EGB36050 |
| Application | HACR rated; NF panelboard |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | EGB36050 |
| Connection | LUGS: (1) 14 AWG-2/0 AL OR CU |
| Connection Type | Lug |
| Country of Origin | MX |
| Currency | USD |
| Depth | 4.05 in |
| Dimensions | 5.8 in H x 2.94 in W x 4.05 in D |
| Enclosure | NF PANELBOARD |
| EU RoHS Indicator | Y |
| Frame | E |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0165 lb |
| Gross Weight per Pack Metric | 1.65 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 12.1920 in |
| Height [Metric] | 12.1920 cm |
| Item Group | 00936 |
| Length | 25.1460 in |
| Length [Metric] | 25.1460 cm |
| Material | Thermoset Composite Resin |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423254430&lang=en-us |
| Mounting Type | Bolt-On |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 pH |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCSA File No. LR92886Federal Specification W-C-375B/GENNOM 117cULus ListedUL 489 File No. E84967PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Sub Brand | NF BRANCH CIRCUIT BREAKERS (BOLT-ON) |
| Temperature Rating | 104 °F |
| Trip Range | 630 to 1800 A |
| Type | Type EGB |
| UNSPSC | 39121603 |
| UPC 11 | 78590123557 |
| UPC 12 | 785901235576 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 15.7480 in |
| Width [Metric] | 15.7480 cm |
| Wire Size | 12 to 2/0 AWG Al, 14 to 2/0 AWG Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 50 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480Y/277 VAC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600Y/347 VAC |
| HACR rated; NF panelboard |
| BOLT-ON |
