Square D™ EGB34040 Miniature Circuit Breaker, 277/480 VAC, 40 A, 35 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ EGB34040 Miniature Circuit Breaker, 277/480 VAC, 40 A, 35 kA Interrupt, 3 Poles, Thermal Magnetic Trip
SKU113282
MFGR #EGB34040
$/ea
Square D EGB34040 MINIATURE CIRCUIT BREAKER 480Y/277V 40A,35kA,40A,Bolt-On,E frame,E-Frame,Hold 630A - Trip 1800A,Lugs #12 to #2/0 AWG(Al) - #14 to #2/0 AWG(Cu),Molded Case Circuit Breaker,Provides overload and short circuit protection,UL Listed - CSA Certified
Square D EGB34040 MINIATURE CIRCUIT BREAKER 480Y/277V 40A,35kA,40A,Bolt-On,E frame,E-Frame,Hold 630A - Trip 1800A,Lugs #12 to #2/0 AWG(Al) - #14 to #2/0 AWG(Cu),Molded Case Circuit Breaker,Provides overload and short circuit protection,UL Listed - CSA Certified
Alternate Catalog Number EGB34040 Application HID rated;HACR rated; NF panelboard ARRA Compliant N Buy American Compliant N Catalog Number EGB34040 Connection LUGS #12 TO #2/0 AWG(AL) - #14 TO #2/0 AWG(CU) Connection Type Lug Country of Origin MX Currency USD Depth 4.05 in Dimensions 4.05 in L x 2.94 in W x 5.66 in H EU RoHS Indicator Y Frame E Frequency Rating 50/60 Hz Gross Volume Per Pack 273.42 Gross Volume per Pack Metric 4480.53 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.0160 lb Gross Weight per Pack Metric 1.61 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 12.1920 in Height [Metric] 11.7000 cm Item Group 00936 Length 25.6540 in Length [Metric] 24.9000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423253601&lang=en-us Mounting Type Bolt-On Number Of Poles 3 Operating Temperature 40 °C Phase 3 Returnable Y Standard UL LISTED - CSA CERTIFIED Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL ListedCSA CertifiedHACR RatedNOM 117PPROP65: Cancer and Reproductive Harm - www.P65warnings.ca.gov Sub Brand E FRAME Substitute Product Catalog Number HPAFD Temperature Rating 104 °F Trip Range 630 to 1800 A Type Molded Case Standard UNSPSC 39121603 UPC 11 78590131117 UPC 12 785901311171 Warranty Description Contractual Warranty:18 months Width 15.4940 in Width [Metric] 15.7000 cm Wire Size 12 to 2 AWG, 14 to 2/0 AWG Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 40 A Interrupt Rating 35 kA Trip Type Thermal Magnetic Voltage Rating 277/480Y VAC HID rated;HACR rated; NF panelboard BOLT-ON Visi-Trip® trip indicator 630 A hold, 1800 A trip current For merchandised NF panelboards 12 to 2/0 AWG aluminum, 14 to 2/0 AWG copper wire
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | EGB34040 |
| Application | HID rated;HACR rated; NF panelboard |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | EGB34040 |
| Connection | LUGS #12 TO #2/0 AWG(AL) - #14 TO #2/0 AWG(CU) |
| Connection Type | Lug |
| Country of Origin | MX |
| Currency | USD |
| Depth | 4.05 in |
| Dimensions | 4.05 in L x 2.94 in W x 5.66 in H |
| EU RoHS Indicator | Y |
| Frame | E |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 273.42 |
| Gross Volume per Pack Metric | 4480.53 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.0160 lb |
| Gross Weight per Pack Metric | 1.61 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 12.1920 in |
| Height [Metric] | 11.7000 cm |
| Item Group | 00936 |
| Length | 25.6540 in |
| Length [Metric] | 24.9000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423253601&lang=en-us |
| Mounting Type | Bolt-On |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL ListedCSA CertifiedHACR RatedNOM 117PPROP65: Cancer and Reproductive Harm - www.P65warnings.ca.gov |
| Sub Brand | E FRAME |
| Substitute Product Catalog Number | HPAFD |
| Temperature Rating | 104 °F |
| Trip Range | 630 to 1800 A |
| Type | Molded Case Standard |
| UNSPSC | 39121603 |
| UPC 11 | 78590131117 |
| UPC 12 | 785901311171 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 15.4940 in |
| Width [Metric] | 15.7000 cm |
| Wire Size | 12 to 2 AWG, 14 to 2/0 AWG |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 40 A |
| Interrupt Rating | 35 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 277/480Y VAC |
| HID rated;HACR rated; NF panelboard |
| BOLT-ON |
| Visi-Trip® trip indicator |
| 630 A hold, 1800 A trip current |
| For merchandised NF panelboards |
| 12 to 2/0 AWG aluminum, 14 to 2/0 AWG copper wire |
