Square D™ EGB14060 Type EGB Circuit Breaker, 277 VAC, 60 A, 65 kA at 240 VAC/35 kA at 480Y/277 VAC Interrupt, 1 Pole
Custom_Product_Images_Illustration
Square D™ EGB14060 Type EGB Circuit Breaker, 277 VAC, 60 A, 65 kA at 240 VAC/35 kA at 480Y/277 VAC Interrupt, 1 Pole
SKU678487
MFGR #EGB14060
$/ea
Square D EGB14060 MINIATURE CIRCUIT BREAKER 277V 60A,1-Pole,277 V AC,277 V AC,4.05 in,60 A,Bolt-On,E-Frame,EGB,HACR rated,Hold 630A - Trip 1800A,Lugs #12 to #2/0 AWG(Al) - #14 to #2/0 AWG(Cu),UL Listed - CSA Certified
Square D EGB14060 MINIATURE CIRCUIT BREAKER 277V 60A,1-Pole,277 V AC,277 V AC,4.05 in,60 A,Bolt-On,E-Frame,EGB,HACR rated,Hold 630A - Trip 1800A,Lugs #12 to #2/0 AWG(Al) - #14 to #2/0 AWG(Cu),UL Listed - CSA Certified
Alternate Catalog Number EGB14060 Application HACR rated ARRA Compliant N Buy American Compliant N Catalog Number EGB14060 Connection AWG 12...AWG 2/0 ALUMINIUM-AWG 14...AWG 2/0 COPPER,LUGS ALUMINIUM Connection Type Lug Country of Origin MX Currency USD Depth 4.05 in Dimensions 5.66 in H x 0.98 in W x 4.05 in D EU RoHS Indicator Y Frame E Frequency Rating 50/60 Hz Gross Weight Per Pack 5.7996 lb Gross Weight per Pack Metric 579.96 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200040 Height 4.5720 in Height [Metric] 4.5720 cm Item Group 00936 Length 25.9080 in Length [Metric] 25.9080 cm Material Thermoset Composite Resin Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423255347&lang=en-us Mounting Type Bolt-On Number Of Poles 1 Operating Temperature 40 °C Phase 1 pH Returnable Y Standard cULus Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCSA File No. LR92886Federal Specification W-C-375B/GENHACR RatedNOM 117cULus ListedUL 489 File No. E84967PROP65:California Provision: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov Sub Brand EGB Temperature Rating 104 °F Trip Range 630 to 1800 A Type Type EGB UNSPSC 39121603 UPC 11 78590112851 UPC 12 785901128519 Warranty Description Contractual Warranty:18 months Width 15.4940 in Width [Metric] 15.4940 cm Wire Size 12 to 2/0 AWG Al, 14 to 2/0 AWG Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 60 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480Y/277 VAC Trip Type Thermal Magnetic Voltage Rating 277 VAC HACR rated TRIP INDICATOR
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | EGB14060 |
| Application | HACR rated |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | EGB14060 |
| Connection | AWG 12...AWG 2/0 ALUMINIUM-AWG 14...AWG 2/0 COPPER,LUGS ALUMINIUM |
| Connection Type | Lug |
| Country of Origin | MX |
| Currency | USD |
| Depth | 4.05 in |
| Dimensions | 5.66 in H x 0.98 in W x 4.05 in D |
| EU RoHS Indicator | Y |
| Frame | E |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 5.7996 lb |
| Gross Weight per Pack Metric | 579.96 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 4.5720 in |
| Height [Metric] | 4.5720 cm |
| Item Group | 00936 |
| Length | 25.9080 in |
| Length [Metric] | 25.9080 cm |
| Material | Thermoset Composite Resin |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423255347&lang=en-us |
| Mounting Type | Bolt-On |
| Number Of Poles | 1 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | cULus |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCSA File No. LR92886Federal Specification W-C-375B/GENHACR RatedNOM 117cULus ListedUL 489 File No. E84967PROP65:California Provision: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Sub Brand | EGB |
| Temperature Rating | 104 °F |
| Trip Range | 630 to 1800 A |
| Type | Type EGB |
| UNSPSC | 39121603 |
| UPC 11 | 78590112851 |
| UPC 12 | 785901128519 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 15.4940 in |
| Width [Metric] | 15.4940 cm |
| Wire Size | 12 to 2/0 AWG Al, 14 to 2/0 AWG Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 60 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480Y/277 VAC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 277 VAC |
| HACR rated |
| TRIP INDICATOR |
