Square D™ 8903SMO3V04 LIGHTING CONTACTOR
SKU361325
MFGR #8903SMO3V04
Your Cost: $718.43/ea
Square D 8903SMO3V04 LIGHTING CONTACTOR 600VAC 30A NEMA,277Vac60Hz,30 A,4-Pole,4P,8903S,Electrically Held,Lighting Contactor,Screw Clamp,UL Listed - CSA Certified,no indicator
Square D 8903SMO3V04 LIGHTING CONTACTOR 600VAC 30A NEMA,277Vac60Hz,30 A,4-Pole,4P,8903S,Electrically Held,Lighting Contactor,Screw Clamp,UL Listed - CSA Certified,no indicator
Application ELECTRICALLY HELD ARRA Compliant C Brand Square D™ Buy American Compliant C Catalog Number 8903SMO3V04 Coil Voltage 277 VAC at 60 Hz V Connection Screw Clamp Connection Type Screw Clamp Contact Configuration 4-POLE Contact Rating 30 A Country of Origin MX Enclosure Type Open EU RoHS Indicator U Frequency Rating 50/60 Hz Gross Weight Per Pack 3.5000 lb Gross Weight per Pack Metric 1.59 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536490065 Indicator No indicator Item Group 21325 Manufacturer Schneider Electric Mounting Type Surface Number Of Poles 4 Operating Cycles 10000 cpm Operating Temperature 0 to 40 Returnable N Series 8903 Size 4P Standard UL LISTED - CSA CERTIFIED Stock Status NONSTOCK Sub Brand 8903S Terminal Type Screw/Clamp Type Electrically Held Type S UNSPSC 39121529 UPC 11 78590102387 UPC 12 785901023876 Wattage 10.3 kW at 200 V/11.9 kW at 230 V/19.7 kW at 380 V/23.9 kW at 460 V/30 kW at 575 V ELECTRICALLY HELD COMMON CONTROL CIRCUIT,NONE Factory wired controls and clearly marked termination points 600 VAC system voltage Lug connection Without indicator
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | ELECTRICALLY HELD |
| ARRA Compliant | C |
| Brand | Square D™ |
| Buy American Compliant | C |
| Catalog Number | 8903SMO3V04 |
| Coil Voltage | 277 VAC at 60 Hz V |
| Connection | Screw Clamp |
| Connection Type | Screw Clamp |
| Contact Configuration | 4-POLE |
| Contact Rating | 30 A |
| Country of Origin | MX |
| Enclosure Type | Open |
| EU RoHS Indicator | U |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 3.5000 lb |
| Gross Weight per Pack Metric | 1.59 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536490065 |
| Indicator | No indicator |
| Item Group | 21325 |
| Manufacturer | Schneider Electric |
| Mounting Type | Surface |
| Number Of Poles | 4 |
| Operating Cycles | 10000 cpm |
| Operating Temperature | 0 to 40 |
| Returnable | N |
| Series | 8903 |
| Size | 4P |
| Standard | UL LISTED - CSA CERTIFIED |
| Stock Status | NONSTOCK |
| Sub Brand | 8903S |
| Terminal Type | Screw/Clamp |
| Type | Electrically Held Type S |
| UNSPSC | 39121529 |
| UPC 11 | 78590102387 |
| UPC 12 | 785901023876 |
| Wattage | 10.3 kW at 200 V/11.9 kW at 230 V/19.7 kW at 380 V/23.9 kW at 460 V/30 kW at 575 V |
| ELECTRICALLY HELD |
| COMMON CONTROL CIRCUIT,NONE |
| Factory wired controls and clearly marked termination points |
| 600 VAC system voltage |
| Lug connection |
| Without indicator |
