Square D™
Square D™ 8536SEH1V03 STARTER 600VAC 90AM
Custom_Product_Images_Illustration
Square D™
Square D™ 8536SEH1V03 STARTER 600VAC 90AM
SKU379778
MFGR #8536SEH1V03
Your Cost: $2,737.90/ea
Square D 8536SEH1V03 STARTER 600VAC 90AMP NEMA +OPTIONS,240VAC60Hz - 220VAC50Hz,25HP200VAC - 30HP230VAC - 50HP460/575VAC,3,3 phases,3-Pole,600 V AC,90 A,NEMA 3R painted sheet steel,S,Screw Clamp,UL Listed - CSA Certified,Used for Full-Voltage Starting and Stopping of AC Squirrel Cage Motors,melting alloy 3,starter
Square D 8536SEH1V03 STARTER 600VAC 90AMP NEMA +OPTIONS,240VAC60Hz - 220VAC50Hz,25HP200VAC - 30HP230VAC - 50HP460/575VAC,3,3 phases,3-Pole,600 V AC,90 A,NEMA 3R painted sheet steel,S,Screw Clamp,UL Listed - CSA Certified,Used for Full-Voltage Starting and Stopping of AC Squirrel Cage Motors,melting alloy 3,starter
Alternate Catalog Number 8536SEH1V03 Amperage Rating 90 A Application USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS ARRA Compliant N Brand Square D™ Buy American Compliant N Catalog Number 8536SEH1V03 Coil Voltage 220 VAC at 50 Hz/240 VAC at 60 Hz Connection Screw clamp terminals Connection Type Screw Clamp Country of Origin MX Dimensions 12.83 in W x 8.62 in D x 25.28 in H Enclosure Type NEMA 3R EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 27.6700 lb Gross Weight per Pack Metric 12.55 Gross Weight UOM Metric kg Height 25.04 in Height [Metric] 64.2000 cm Item Group 21193 Length 8.54 in Length [Metric] 21.9000 cm Manufacturer Schneider Electric Material Sheet Steel Motor Power 25 hp at 200 VAC/30 hp at 230 VAC/50 hp at 460/575 VAC NEMA Frame Size 3 Number Of Phases 3 Number Of Poles 3 Operating Cycles 5 cpm Operating Temperature 0 to 40 deg C Ambient Phase 3 pH Power Supply 240VAC@60HZ - 220VAC@50HZ Reset Type (3) Thermal Melting Alloy Returnable N Series 8536 Size 219 MM,326 MM,642 MM in Standard CSA-UL LISTED-NEMA Stock Status NONSTOCK Sub Brand S Type Type S UNSPSC 39121521 UPC 11 78590182327 UPC 12 785901823278 Voltage Rating 600 VAC Warranty Description Contractual Warranty:18 months Width 12.71 in Width [Metric] 32.6000 cm USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS SCREW CLAMP TERMINALS Used for full voltage starting and stopping AC squirrel cage motors NEMA type 3R rainproof, sleet resistant for outdoor use NEMA 3
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | 8536SEH1V03 |
| Amperage Rating | 90 A |
| Application | USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS |
| ARRA Compliant | N |
| Brand | Square D™ |
| Buy American Compliant | N |
| Catalog Number | 8536SEH1V03 |
| Coil Voltage | 220 VAC at 50 Hz/240 VAC at 60 Hz |
| Connection | Screw clamp terminals |
| Connection Type | Screw Clamp |
| Country of Origin | MX |
| Dimensions | 12.83 in W x 8.62 in D x 25.28 in H |
| Enclosure Type | NEMA 3R |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 27.6700 lb |
| Gross Weight per Pack Metric | 12.55 |
| Gross Weight UOM Metric | kg |
| Height | 25.04 in |
| Height [Metric] | 64.2000 cm |
| Item Group | 21193 |
| Length | 8.54 in |
| Length [Metric] | 21.9000 cm |
| Manufacturer | Schneider Electric |
| Material | Sheet Steel |
| Motor Power | 25 hp at 200 VAC/30 hp at 230 VAC/50 hp at 460/575 VAC |
| NEMA Frame Size | 3 |
| Number Of Phases | 3 |
| Number Of Poles | 3 |
| Operating Cycles | 5 cpm |
| Operating Temperature | 0 to 40 deg C Ambient |
| Phase | 3 pH |
| Power Supply | 240VAC@60HZ - 220VAC@50HZ |
| Reset Type | (3) Thermal Melting Alloy |
| Returnable | N |
| Series | 8536 |
| Size | 219 MM,326 MM,642 MM in |
| Standard | CSA-UL LISTED-NEMA |
| Stock Status | NONSTOCK |
| Sub Brand | S |
| Type | Type S |
| UNSPSC | 39121521 |
| UPC 11 | 78590182327 |
| UPC 12 | 785901823278 |
| Voltage Rating | 600 VAC |
| Warranty Description | Contractual Warranty:18 months |
| Width | 12.71 in |
| Width [Metric] | 32.6000 cm |
| USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS |
| SCREW CLAMP TERMINALS |
| Used for full voltage starting and stopping AC squirrel cage motors |
| NEMA type 3R rainproof, sleet resistant for outdoor use |
| NEMA 3 |
