Square D™ 8536SCO3V02SX11 STARTER 600VAC
SKU902452
MFGR #8536SCO3V02SX11
Your Cost: $1,038.92/ea
Square D 8536SCO3V02SX11 STARTER 600VAC 27AMP NEMA +OPTIONS,1,1 NO + 1 NC,120VAC60Hz - 110VAC50Hz,27 A,3 phases,3-Pole,600 V AC,7.5HP200/230VAC - 10HP460/575VAC,S,Screw Clamp,UL Listed - CSA Certified,Used for Full-Voltage Starting and Stopping of AC Squirrel Cage Motors,melting alloy 3,not rated (open device),starter
Square D 8536SCO3V02SX11 STARTER 600VAC 27AMP NEMA +OPTIONS,1,1 NO + 1 NC,120VAC60Hz - 110VAC50Hz,27 A,3 phases,3-Pole,600 V AC,7.5HP200/230VAC - 10HP460/575VAC,S,Screw Clamp,UL Listed - CSA Certified,Used for Full-Voltage Starting and Stopping of AC Squirrel Cage Motors,melting alloy 3,not rated (open device),starter
Action Non-Reversing Alternate Catalog Number 8536SCO3V02SX11 Amperage Rating 27 A Application USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS ARRA Compliant N Brand Square D™ Buy American Compliant N Catalog Number 8536SCO3V02SX11 Coil Voltage 110 VAC at 50 Hz/120 VAC at 60 Hz Connection Screw clamp terminals Connection Type Screw Clamp Country of Origin MX Dimensions 4.02 in W x 4.21 in D x 6.77 in H Enclosure Type Open EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 5.0000 lb Gross Weight per Pack Metric 2.27 Gross Weight UOM Metric kg Height 6.75 in Height [Metric] 17.3000 cm Item Group 21192 Length 4.17 in Length [Metric] 10.7000 cm Manufacturer Schneider Electric Motor Power 7.5 hp at 200/230 VAC/10 hp at 460/575 VAC NEMA Frame Size 1 Number Of Phases 3 Number Of Poles 3 Operating Temperature 0 to 40 deg C Ambient Overload Relay Thermal Melting Alloy 3 Phase 3 pH Power Supply 120VAC@60HZ - 110VAC@50HZ Reset Type (3) Thermal Melting Alloy Returnable N Series 8536 Size 102 MM,107 MM,172 MM in Standard NEMA-CSA-UL LISTED Stock Status NONSTOCK Sub Brand S Type Type S UNSPSC 39121521 UPC 11 78590101926 UPC 12 785901019268 Voltage Rating 600 VAC Warranty Description Contractual Warranty:18 months Wattage 5.5 kW at 200/230 VAC/7.5 kW at 460/575 VAC Width 3.98 in Width [Metric] 10.2000 cm USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS 1 NO + 1 NC Used for full voltage starting and stopping AC squirrel cage motors X11 (1) normally open and (1) normally close NEMA 1
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Action | Non-Reversing |
| Alternate Catalog Number | 8536SCO3V02SX11 |
| Amperage Rating | 27 A |
| Application | USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS |
| ARRA Compliant | N |
| Brand | Square D™ |
| Buy American Compliant | N |
| Catalog Number | 8536SCO3V02SX11 |
| Coil Voltage | 110 VAC at 50 Hz/120 VAC at 60 Hz |
| Connection | Screw clamp terminals |
| Connection Type | Screw Clamp |
| Country of Origin | MX |
| Dimensions | 4.02 in W x 4.21 in D x 6.77 in H |
| Enclosure Type | Open |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 5.0000 lb |
| Gross Weight per Pack Metric | 2.27 |
| Gross Weight UOM Metric | kg |
| Height | 6.75 in |
| Height [Metric] | 17.3000 cm |
| Item Group | 21192 |
| Length | 4.17 in |
| Length [Metric] | 10.7000 cm |
| Manufacturer | Schneider Electric |
| Motor Power | 7.5 hp at 200/230 VAC/10 hp at 460/575 VAC |
| NEMA Frame Size | 1 |
| Number Of Phases | 3 |
| Number Of Poles | 3 |
| Operating Temperature | 0 to 40 deg C Ambient |
| Overload Relay | Thermal Melting Alloy 3 |
| Phase | 3 pH |
| Power Supply | 120VAC@60HZ - 110VAC@50HZ |
| Reset Type | (3) Thermal Melting Alloy |
| Returnable | N |
| Series | 8536 |
| Size | 102 MM,107 MM,172 MM in |
| Standard | NEMA-CSA-UL LISTED |
| Stock Status | NONSTOCK |
| Sub Brand | S |
| Type | Type S |
| UNSPSC | 39121521 |
| UPC 11 | 78590101926 |
| UPC 12 | 785901019268 |
| Voltage Rating | 600 VAC |
| Warranty Description | Contractual Warranty:18 months |
| Wattage | 5.5 kW at 200/230 VAC/7.5 kW at 460/575 VAC |
| Width | 3.98 in |
| Width [Metric] | 10.2000 cm |
| USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS |
| 1 NO + 1 NC |
| Used for full voltage starting and stopping AC squirrel cage motors |
| X11 (1) normally open and (1) normally close |
| NEMA 1 |
