Square D™ 8536SBO2V03 Type S Non-Reversing NEMA Magnetic Starter, 220/240 VAC Coil, 3-Poles, Open Enclosure
Custom_Product_Images_Illustration
Square D™ 8536SBO2V03 Type S Non-Reversing NEMA Magnetic Starter, 220/240 VAC Coil, 3-Poles, Open Enclosure
SKU34889
MFGR #8536SBO2V03
Your Cost: $454.51/ea
List: Square D 8536SBO2V03 STARTER 600VAC 18AMP NEMA +OPTIONS,0,18 A,240VAC60Hz - 220VAC50Hz,3 phases,3HP200/230VAC - 5HP460/575VAC,600 V AC,S,Screw Clamp,UL Listed - CSA Certified,Used for Full-Voltage Starting and Stopping of AC Squirrel Cage Motors,melting alloy 3,not rated (open device),starter
Square D 8536SBO2V03 STARTER 600VAC 18AMP NEMA +OPTIONS,0,18 A,240VAC60Hz - 220VAC50Hz,3 phases,3HP200/230VAC - 5HP460/575VAC,600 V AC,S,Screw Clamp,UL Listed - CSA Certified,Used for Full-Voltage Starting and Stopping of AC Squirrel Cage Motors,melting alloy 3,not rated (open device),starter
Action Non-Reversing Alternate Catalog Number 8536SBO2V03 Amperage Rating 18 A Application USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS ARRA Compliant N Brand Square D™ Buy American Compliant N Catalog Number 8536SBO2V03 Coil Voltage 220/240 VAC Connection Screw clamp terminals Connection Type Screw Clamp Country of Origin MX Currency USD Dimensions 6.77 in H x 3.5 in W x 4.21 in D Enclosure Type NEMA 0/Open EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Volume Per Pack 212.40 Gross Volume per Pack Metric 3480.60 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 4.0600 lb Gross Weight per Pack Metric 1.84 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536504000 Height 11.4300 in Height [Metric] 11.4300 cm Item Group 21191 Length 20.3200 in Length [Metric] 20.3200 cm Manufacturer Schneider Electric Motor Power 3/5 hp NEMA Frame Size 0 Number Of Phases 3 Number Of Poles 3 Overload Relay Thermal Melting Alloy 3 Phase 3 pH Power Supply 240VAC@60HZ - 220VAC@50HZ Reset Type MELTING ALLOY 3 THERMAL UNITS Returnable Y Size 107 MM,172 MM,89 MM Standard NEMA-UL LISTED-CSA Stock Status NONSTOCK Sub Brand S Substitute Product Catalog Number 9999ST1 Type Type S UNSPSC 39121521 UPC 11 78590187182 UPC 12 785901871828 Voltage Rating 600 VAC Warranty Description Contractual Warranty:18 months Width 14.9860 in Width [Metric] 14.9860 cm USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS SCREW CLAMP TERMINALS 3 hp at 200/230 VAC, 5 hp at 460/575 VAC power rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Action | Non-Reversing |
| Alternate Catalog Number | 8536SBO2V03 |
| Amperage Rating | 18 A |
| Application | USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS |
| ARRA Compliant | N |
| Brand | Square D™ |
| Buy American Compliant | N |
| Catalog Number | 8536SBO2V03 |
| Coil Voltage | 220/240 VAC |
| Connection | Screw clamp terminals |
| Connection Type | Screw Clamp |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 6.77 in H x 3.5 in W x 4.21 in D |
| Enclosure Type | NEMA 0/Open |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 212.40 |
| Gross Volume per Pack Metric | 3480.60 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 4.0600 lb |
| Gross Weight per Pack Metric | 1.84 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536504000 |
| Height | 11.4300 in |
| Height [Metric] | 11.4300 cm |
| Item Group | 21191 |
| Length | 20.3200 in |
| Length [Metric] | 20.3200 cm |
| Manufacturer | Schneider Electric |
| Motor Power | 3/5 hp |
| NEMA Frame Size | 0 |
| Number Of Phases | 3 |
| Number Of Poles | 3 |
| Overload Relay | Thermal Melting Alloy 3 |
| Phase | 3 pH |
| Power Supply | 240VAC@60HZ - 220VAC@50HZ |
| Reset Type | MELTING ALLOY 3 THERMAL UNITS |
| Returnable | Y |
| Size | 107 MM,172 MM,89 MM |
| Standard | NEMA-UL LISTED-CSA |
| Stock Status | NONSTOCK |
| Sub Brand | S |
| Substitute Product Catalog Number | 9999ST1 |
| Type | Type S |
| UNSPSC | 39121521 |
| UPC 11 | 78590187182 |
| UPC 12 | 785901871828 |
| Voltage Rating | 600 VAC |
| Warranty Description | Contractual Warranty:18 months |
| Width | 14.9860 in |
| Width [Metric] | 14.9860 cm |
| USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS |
| SCREW CLAMP TERMINALS |
| 3 hp at 200/230 VAC, 5 hp at 460/575 VAC power rating |
