Square D™ 8536S Type S Non-Reversing NEMA Magnetic Starter, 440 to 480 VAC Coil, 3-Poles, Open Enclosure
Starters
100015
MFG #: 8536SCO3V06
Square D™
557.00000
/ ea
Square D 8536SCO3V06 STARTER 600VAC 27AMP NEMA +OPTIONS,1,27 A,3 phases,480VAC60Hz - 440VAC50Hz,600 V AC,7.5HP200/230VAC - 10HP460/575VAC,S,Screw Clamp,UL Listed - CSA Certified,Used for Full-Voltage Starting and Stopping of AC Squirrel Cage Motors,melting alloy 3,not rated (open device),starter
- 360 Degree View URL - 360(360 Degree View URL)
- 360 Degree View URL - index.html?pid=11003&id=8065001360Den&ext=webp(360 Degree View URL)
- Brochure URL - 11003_Q3DJ6XGCRSHN7LFO.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_9aa2c308c6c64eeadd67861ceed28d46585a4dcd0225d98e5f489de68498bb16.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - files?p_enDocType=CAD&p_File_Name=E0303001-01.dwg(Computer~Aided [CAD|BIM] Model URL)
- Install Instructions 1 URL - 11003_CSZWV63BJ0UK47ED.pdf(Install Instructions 1 URL)
- Install Instructions URL - SquareD_8536SCG2V02S_Instruction_Sheet.pdf(Install Instructions URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Spec Sheet 1 URL - SquareD_8536SCO3V06_Datasheet.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - 11003_FXPK8HA3U70SCZMW.pdf(Spec Sheet URL)
- Tech Bulletin URL - 11003_8G547S3DJIOHPNLZ.pdf(Tech Bulletin URL)
- Tech Bulletin URL - 11003_R8DPHVO6FAXJE9S2.pdf(Tech Bulletin URL)
- Tech Drawing URL - 11003_1685U70JPTFIGBVH.pdf(Tech Drawing URL)
- Tech Drawing URL - 11003_WDQCK4RX13FT26V5.pdf(Tech Drawing URL)
- Video - https://www.youtube.com/embed/MsloUt8sPL0(Video)
- Applications
- Features
| USED FOR FULL-VOLTAGE STARTING AND STOPPING OF AC SQUIRREL CAGE MOTORS |
| SCREW CLAMP TERMINALS |
| 7-1/2 hp at 200/230 VAC, 10 hp at 460/575 VAC motor power rating |
| Melting alloy 3 overload relay |
| Trip-free construction allows overload relay to trip even if reset lever is blocked or in the reset position |
| Open enclosure Normally open holding circuit contact for 3-wire control |
| Angled contacts provide high contact pressure and positive seating |
| Provide class 20 protection |
| Surface mounting |
| 7.5 hp at 200/230 VAC, 10 hp at 460/575 VAC |
| Type S starter |
| Open enclosure |
