Square D™ 8502S Full Voltage Contactor 8502SCO2V02S, 110/120 VAC Coil, 27 A Max Load, 3 Poles
Starters
34837
MFG #: 8502SCO2V02S
Square D™
454.51000
/ ea
Square D 8502SCO2V02S CONTACTOR 600VAC 27AMP NEMA +OPTIONS,1,3P,120 V AC 60 Hz-110 V AC 50 Hz,3-Phase,3-Pole,8502S,Screw Clamp,UL Listed - CSA Certified,contactor,no indicator,non-reversing
- 360 Degree View URL - index.html?pid=11003&id=8064520360Den&ext=webp(360 Degree View URL)
- 3D Rendering URL - SEproductListV2.html?p=8502SCO2V02S(3D Rendering URL)
- Brochure URL - 1b27ab4ed991044d15147558595d991bbb4abc6a.pdf(Brochure URL)
- Compliance Cert URL - Square_D_8502SCO2V02S_Compliance_Certificate.pdf(Compliance Cert URL)
- Computer~Aided [CAD|BIM] Model URL - files?p_enDocType=CAD&p_File_Name=8502SCO1V02S.dwf(Computer~Aided [CAD|BIM] Model URL)
- Install Instructions 1 URL - 11003_CSZWV63BJ0UK47ED.pdf(Install Instructions 1 URL)
- Install Instructions URL - files?p_Doc_Ref=30072-013-10(Install Instructions URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Spec Sheet 1 URL - Square_D_8502SCO2V02S_Specification_Sheet.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - 11003_AY2J1KT3GFI4O9CE.pdf(Spec Sheet URL)
- Tech Bulletin URL - 11003_8G547S3DJIOHPNLZ.pdf(Tech Bulletin URL)
- Tech Drawing URL - 11003_B3GKER8JACP0U1F5.dwg(Tech Drawing URL)
- Applications
- Features
| Non-reversing;Circuit-breaker 70 A maximum, SCCR: 100 kA at 480 V AC;fuse J 60 A maximum, SCCR: 100 kA at 600 V AC;fuse T 60 A maximum, SCCR: 100 kA at 600 V AC;fuse RK1 60 A maximum, SCCR: 100 kA at 600 V AC;fuse RK5 60 A maximum, SCCR: 100 kA at 600 V AC |
| 7.5 HP 200 V AC-7.5 HP 230 V AC-10 HP 460 V AC-10 HP 575 V AC,SEPARATE CONTROL CIRCUIT |
| Class 8502 contactors are available in NEMA Sizes 00-7, type S contactors are designed for operation at 600 volts, AC 50-60 Hz |
