Square D™
Square D™ 8501RSD42P14V53 RELAY 240VAC 10
Custom_Product_Images_Illustration
Square D™
Square D™ 8501RSD42P14V53 RELAY 240VAC 10
SKU96714
MFGR #8501RSD42P14V53
Your Cost: $66.09/ea
Square D 8501RSD42P14V53 RELAY 240VAC 10AMP TYPE R +OPTIONS,-40F to 158F,10A (30Vdc),24Vdc,DPDT,Miniature Relay,Pick-Up 25ms(max) Drop-Out 20ms(max),Spade,socket,standard
Square D 8501RSD42P14V53 RELAY 240VAC 10AMP TYPE R +OPTIONS,-40F to 158F,10A (30Vdc),24Vdc,DPDT,Miniature Relay,Pick-Up 25ms(max) Drop-Out 20ms(max),Spade,socket,standard
Alternate Catalog Number 8501RSD42P14V53 Amperage Rating 10 A Application 8501NR42 ARRA Compliant N Brand Square D™ Buy American Compliant N Catalog Number 8501RSD42P14V53 Coil 300 V AT AC-30 V AT DC Coil Voltage 24 VDC Connection SPADE Contact Configuration DPDT Contact Form DPDT (2C/O) Contact Material Silver alloy, gold flashed Contact Rating 15 A Country of Origin US Currency USD Depth 1.6457 in Dimensions 27.3 mm H x 21 mm W x 41.8 mm D Display Type LED EU RoHS Indicator Y Gross Volume Per Pack 3.64 Gross Volume per Pack Metric 59.65 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.0900 lb Gross Weight per Pack Metric 40.82 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536410060 Height 3.5560 in Height [Metric] 3.5560 cm Item Group 21143 Length 3.3020 in Length [Metric] 3.3020 cm Manufacturer Schneider Electric Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=367711&lang=en-us Mounting Socket Mounting Type Socket Number Of Poles 2 Operating Temperature -40-131 A°F Pickup Voltage 24 V DC Power Rating 1 hp at 277 VAC Returnable Y Series 8501 Standard UL LISTED-UL RECOGNIZED-CSA-CE Stock Status NONSTOCK Substitute Product Catalog Number 8501NR42 Temperature Rating 21 mm W x 41.8 mm D x 27.3 mm H Terminal Type Spade Type Type R UNSPSC 39122325 UPC 11 78590113139 UPC 12 785901131397 Warranty Description Contractual Warranty:18 months Width 5.0800 in Width [Metric] 5.0800 cm 8501NR42 GREEN INDICATOR RELAY ENERGISED LED,WITHOUT TEST BUTTON Complete socket line 0.5 hp at 120 VAC power
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | 8501RSD42P14V53 |
| Amperage Rating | 10 A |
| Application | 8501NR42 |
| ARRA Compliant | N |
| Brand | Square D™ |
| Buy American Compliant | N |
| Catalog Number | 8501RSD42P14V53 |
| Coil | 300 V AT AC-30 V AT DC |
| Coil Voltage | 24 VDC |
| Connection | SPADE |
| Contact Configuration | DPDT |
| Contact Form | DPDT (2C/O) |
| Contact Material | Silver alloy, gold flashed |
| Contact Rating | 15 A |
| Country of Origin | US |
| Currency | USD |
| Depth | 1.6457 in |
| Dimensions | 27.3 mm H x 21 mm W x 41.8 mm D |
| Display Type | LED |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 3.64 |
| Gross Volume per Pack Metric | 59.65 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.0900 lb |
| Gross Weight per Pack Metric | 40.82 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536410060 |
| Height | 3.5560 in |
| Height [Metric] | 3.5560 cm |
| Item Group | 21143 |
| Length | 3.3020 in |
| Length [Metric] | 3.3020 cm |
| Manufacturer | Schneider Electric |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=367711&lang=en-us |
| Mounting | Socket |
| Mounting Type | Socket |
| Number Of Poles | 2 |
| Operating Temperature | -40-131 A°F |
| Pickup Voltage | 24 V DC |
| Power Rating | 1 hp at 277 VAC |
| Returnable | Y |
| Series | 8501 |
| Standard | UL LISTED-UL RECOGNIZED-CSA-CE |
| Stock Status | NONSTOCK |
| Substitute Product Catalog Number | 8501NR42 |
| Temperature Rating | 21 mm W x 41.8 mm D x 27.3 mm H |
| Terminal Type | Spade |
| Type | Type R |
| UNSPSC | 39122325 |
| UPC 11 | 78590113139 |
| UPC 12 | 785901131397 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 5.0800 in |
| Width [Metric] | 5.0800 cm |
| 8501NR42 |
| GREEN INDICATOR RELAY ENERGISED LED,WITHOUT TEST BUTTON |
| Complete socket line |
| 0.5 hp at 120 VAC power |
