SmartlockPro® X7899-E GFCI Duplex Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Black

GFCI Receptacles
578094 MFG #: X7899-E
Leviton®
28.56000 / ea
Slim is in. New SmartlockPro Slim GFCIs Install Easily Industry-leading quality, professional grade lockout action, and the slimmest profile on the market make SmartlockPro Slim GFCIs the smartest choice in ground fault circuit interrupter protection. Faster and easier to install in any wallbox because depth is reduced, the slim GFCIs flush mount to the wall with minimal protrusion for a sleek, finished look. Enhanced features include external back wiring for positive indication the wire is properly seated, exceptional resistance to wire pullout and the ability to withstand high torque. Tamper-Resistant to meet 2008 NEC Requirements for new or renovated residential construction.
QTY
  • Features
Self Grounding, Tamper Resistant, 2-Year Limited Warranty, LED Indicator, Made in China
Reduced depth of SmartLockPro® Slim GFCI makes it easier to install in any electrical box, even shallow ones
Terminals allow for easy wiring options back and Side wire capable
External Back-wire clamps provide visual indication of proper wire seating
Withstands high torque and resists wire pullout
Standard brass self-grounding clips
Automatically test the GFCI every time the RESET button is pushed in the GFCI will not reset if the GFCI circuit is not functioning properly
By blocking reset of the GFCI if protection has been compromised, SmartlockPro Slim GFCI reduces the possibility of end-users incorrectly assuming that a reset GFCI outlet is providing ground fault protection when it actually is not
A line load reversal diagnostic feature is provided which prevents the GFCI from being reset and stops power from being fed to the GFCI receptacle face or through to downstream devices, A green LED indicator on the GFCI face also illuminates to alert the installer to the line load wiring reversal
Trip threshold meets or exceeds UL requirements for tripping time
Improved immunity to high frequency noise reduces nuisance tripping
Advanced electronics design provides superior resistance to electrical surges and over-voltages
Compatible with all Decora® devices and wallplates available in select Decora® colors
With LED indicator light
Tamper-resistant
UL 94V-2 flammability rated
1250 VAC dielectric strength
Back and Side wire connection
14 to 10 AWG
