Schneider Electric Square D™ TeSys™ D LC1D258F7 D-Line Standard IEC Contactor With Protective Cover, 110/690 VAC, 300 VDC V Coil, 40 A, 2NO-2NC Contact, 4 Poles
Custom_Product_Images_Illustration
Schneider Electric Square D™ TeSys™ D LC1D258F7 D-Line Standard IEC Contactor With Protective Cover, 110/690 VAC, 300 VDC V Coil, 40 A, 2NO-2NC Contact, 4 Poles
SKU1144949
MFGR #LC1D258F7
Call For Price
List: Schneider Electric Square D™ TeSys™ D IEC Contactor, D-Line Standard, Series: LC1D, 110/690 VAC, 300 VDC Coil, 40 A Maximum Load Current, 7.5/7.7 VA Coil, 4 Pole, 25 to 400 Hz Frequency, 3.2 W Wattage, Non-Reversing Contact, 2NO-2NC Contact Configuration, 1NO-1NC Auxiliary Contacts, 10/60 A at 600 VAC, 40/60 at 600 VAC Contact, Power Factor: 0.75 Inrush, 0.3 Hold-In, Screw Clamp Connection, 105/45/99 mm Size, Screw Clamp Terminal, IP2X Enclosure, 3600 cycles/hr Operating Cycles, -5 to 60/-40 to 70 deg C Operating, Rail/Surface Mounting, 45 mm W x 99 mm D x 105 mm H Dimensions
Schneider Electric Square D™ TeSys™ D IEC Contactor, D-Line Standard, Series: LC1D, 110/690 VAC, 300 VDC Coil, 40 A Maximum Load Current, 7.5/7.7 VA Coil, 4 Pole, 25 to 400 Hz Frequency, 3.2 W Wattage, Non-Reversing Contact, 2NO-2NC Contact Configuration, 1NO-1NC Auxiliary Contacts, 10/60 A at 600 VAC, 40/60 at 600 VAC Contact, Power Factor: 0.75 Inrush, 0.3 Hold-In, Screw Clamp Connection, 105/45/99 mm Size, Screw Clamp Terminal, IP2X Enclosure, 3600 cycles/hr Operating Cycles, -5 to 60/-40 to 70 deg C Operating, Rail/Surface Mounting, 45 mm W x 99 mm D x 105 mm H Dimensions
Alternate Catalog Number LC1D258F7 Application Resistive Load Applications ARRA Compliant N Buy American Compliant N Catalog Number LC1D258F7 Coil Power Rating 7.5-7.5 VA 60 HZ 0.3 20 A?°C)-7-7 VA 50 HZ 0.3 20 A?°C) Country of Origin SG Currency USD EU RoHS Indicator Y Gross Volume Per Pack 38.26 Gross Volume per Pack Metric 626.97 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 4.6800 lb Gross Weight per Pack Metric 465.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536490065 Height 5.8000 in Height [Metric] 5.8000 cm Item Group 22354 Length 12.0000 in Length [Metric] 12.0000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=615612&lang=en-us Mounting Rail;plate Returnable Y Substitute Product Catalog Number LAD6K10F UNSPSC 39121529 Warranty Description Contractual Warranty:18 months Wattage 3.2 . W Width 9.5000 in Width [Metric] 9.5000 cm Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Coil Voltage 110 V AC 50/60 Hz Contact Configuration 1 NO + 1 NC;2 NO + 2 NC;Mechanically linked 1 NO + 1 NC IEC 60947-5-1;mirror contact 1 NC IEC 60947-4-1 Type contactor Resistive Load Applications Without built-in suppressor module Without built-in bi-directional peak limiting diode suppressor coil technology 40 A at 140 deg F power circuit, 10 A at 140 deg F signaling circuit conventional-free air thermal current
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | LC1D258F7 |
| Application | Resistive Load Applications |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | LC1D258F7 |
| Coil Power Rating | 7.5-7.5 VA 60 HZ 0.3 20 A?°C)-7-7 VA 50 HZ 0.3 20 A?°C) |
| Country of Origin | SG |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 38.26 |
| Gross Volume per Pack Metric | 626.97 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 4.6800 lb |
| Gross Weight per Pack Metric | 465.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536490065 |
| Height | 5.8000 in |
| Height [Metric] | 5.8000 cm |
| Item Group | 22354 |
| Length | 12.0000 in |
| Length [Metric] | 12.0000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=615612&lang=en-us |
| Mounting | Rail;plate |
| Returnable | Y |
| Substitute Product Catalog Number | LAD6K10F |
| UNSPSC | 39121529 |
| Warranty Description | Contractual Warranty:18 months |
| Wattage | 3.2 . W |
| Width | 9.5000 in |
| Width [Metric] | 9.5000 cm |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Coil Voltage | 110 V AC 50/60 Hz |
| Contact Configuration | 1 NO + 1 NC;2 NO + 2 NC;Mechanically linked 1 NO + 1 NC IEC 60947-5-1;mirror contact 1 NC IEC 60947-4-1 |
| Type | contactor |
| Resistive Load Applications |
| Without built-in suppressor module |
| Without built-in bi-directional peak limiting diode suppressor coil technology |
| 40 A at 140 deg F power circuit, 10 A at 140 deg F signaling circuit conventional-free air thermal current |
