Square D™
Schneider Electric Square D™ LZ8H6X5BD Ultra Compact Motor Starter, 24 VDC V Coil, Direct/Reverse Action, 3 Poles, IP20 Enclosure
Custom_Product_Images_Illustration
Square D™
Schneider Electric Square D™ LZ8H6X5BD Ultra Compact Motor Starter, 24 VDC V Coil, Direct/Reverse Action, 3 Poles, IP20 Enclosure
SKUPDW~12047165
MFGR #LZ8H6X5BD
$/ea
Schneider Electric Square D™ Motor Starter, Ultra Compact, Series: LZ8H, 500 VAC, 6.5 A, 3 kW Motor, 24 VDC Coil, 3 Pole, 120 cycles/min and 6 cycles/min Timing, Manual/Electrical Reset, 3 ph, Direct/Reverse Action, 1CO Auxiliary, IP20 Enclosure, Starting Modes: Direct-On-Line, 30 M cycles Operating Cycles, -25 to 30 deg C Without Derating/-30 to 70 deg C With Derating Operating, 22.5 mm W x 114.5 mm D x 99 mm H Dimensions
Schneider Electric Square D™ Motor Starter, Ultra Compact, Series: LZ8H, 500 VAC, 6.5 A, 3 kW Motor, 24 VDC Coil, 3 Pole, 120 cycles/min and 6 cycles/min Timing, Manual/Electrical Reset, 3 ph, Direct/Reverse Action, 1CO Auxiliary, IP20 Enclosure, Starting Modes: Direct-On-Line, 30 M cycles Operating Cycles, -25 to 30 deg C Without Derating/-30 to 70 deg C With Derating Operating, 22.5 mm W x 114.5 mm D x 99 mm H Dimensions
Alternate Catalog Number LZ8H6X5BD ARRA Compliant N Buy American Compliant N Catalog Number LZ8H6X5BD Country of Origin DE Currency USD EU RoHS Indicator Y Gross Weight Per Pack 2.5500 lb Gross Weight per Pack Metric 265.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8537109170 Height 3.5000 in Height [Metric] 3.5000 cm Item Group 22349 Length 11.9000 in Length [Metric] 11.9000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422433183&lang=en-us Motor Power 1 HP 200 V AC-1.5 HP 230 V AC-3 HP 460 V AC,1.5 KW 220 V AC 0.65 -1.5 KW 230 V AC 0.65 -2.2 KW 380 V AC 0.65 -3 KW 400 V AC 0.65 -3 KW 415 V AC 0.65 -3 KW 440 V AC 0.65 -3 KW 500 V AC 0.65 Reset Type manual;electrical reset Returnable N Standard UL 60947-4-1 ; IEC 60947-4-2 UNSPSC 39121521 Width 11.7000 in Width [Metric] 11.7000 cm Brand Square D™ Manufacturer Schneider Electric
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Substitute Products
| Alternate Catalog Number | LZ8H6X5BD |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | LZ8H6X5BD |
| Country of Origin | DE |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 2.5500 lb |
| Gross Weight per Pack Metric | 265.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8537109170 |
| Height | 3.5000 in |
| Height [Metric] | 3.5000 cm |
| Item Group | 22349 |
| Length | 11.9000 in |
| Length [Metric] | 11.9000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422433183&lang=en-us |
| Motor Power | 1 HP 200 V AC-1.5 HP 230 V AC-3 HP 460 V AC,1.5 KW 220 V AC 0.65 -1.5 KW 230 V AC 0.65 -2.2 KW 380 V AC 0.65 -3 KW 400 V AC 0.65 -3 KW 415 V AC 0.65 -3 KW 440 V AC 0.65 -3 KW 500 V AC 0.65 |
| Reset Type | manual;electrical reset |
| Returnable | N |
| Standard | UL 60947-4-1 ; IEC 60947-4-2 |
| UNSPSC | 39121521 |
| Width | 11.7000 in |
| Width [Metric] | 11.7000 cm |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
