Schneider Electric PowerPact™ MGL36800SA Molded Case Circuit Breaker, 600 VAC, 800 A, 3 Poles
Custom_Product_Images_Illustration
Schneider Electric PowerPact™ MGL36800SA Molded Case Circuit Breaker, 600 VAC, 800 A, 3 Poles
SKU760438
MFGR #MGL36800SA
Your Cost: $11,776.19/ea
Schneider Electric MGL36800SA MOLDED CASE CIRCUIT BREAKER 600V 800A
Schneider Electric MGL36800SA MOLDED CASE CIRCUIT BREAKER 600V 800A
Actuator Type Manual Alternate Catalog Number MGL36800SA Application Distribution ARRA Compliant N Buy American Compliant N Catalog Number MGL36800SA Connection AWG 3/0...500 KCMIL ALUMINIUM/COPPER)3,LUGS LOAD-LUGS LINE Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 12.86 in H x 8.27 in W x 8.07 in D EU RoHS Indicator Y Frame M Frequency Rating 50/60 Hz Gross Weight Per Pack 29.0000 lb Gross Weight per Pack Metric 13.15 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 9.91 in Height [Metric] 25.4000 cm Item Group 01205 Length 17.64 in Length [Metric] 45.2400 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430913&lang=en-us Mounting Type DIN Rail/Unit Number Of Poles 3 Phase 3 pH Returnable Y Standard IEC-CSA-UL LISTED Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489CSA C22.2 No.5IEC 60947-2Federal Specification W-C-375B/GENNEMA AB1NMX J-266UTE/VDE/BS/CEI/UNE/CCC/CE MarkedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Temperature Rating -13 to 158 °F Trip Range 800 A,800 A Type 80% Rated UNSPSC 39121601 UPC 11 78590159003 UPC 12 785901590033 Warranty Description Contractual Warranty:18 months Width 11.64 in Width [Metric] 29.8500 cm Wire Size 3/0 AWG to 500 kcmil Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 800 A Interrupt Rating 18 kA Trip Type Electronic Basic ET 1.0 LI/Non-Interchangeable Voltage Rating 600 VAC Distribution UNIT MOUNT A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility 600 VAC, 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC interrupt rating Provide means to manually disconnect power to the circuit Provide enhanced coordination by their adjustabilit Provide high interrupting ratings and withstand ratings
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Manual |
| Alternate Catalog Number | MGL36800SA |
| Application | Distribution |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | MGL36800SA |
| Connection | AWG 3/0...500 KCMIL ALUMINIUM/COPPER)3,LUGS LOAD-LUGS LINE |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 12.86 in H x 8.27 in W x 8.07 in D |
| EU RoHS Indicator | Y |
| Frame | M |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 29.0000 lb |
| Gross Weight per Pack Metric | 13.15 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 9.91 in |
| Height [Metric] | 25.4000 cm |
| Item Group | 01205 |
| Length | 17.64 in |
| Length [Metric] | 45.2400 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430913&lang=en-us |
| Mounting Type | DIN Rail/Unit |
| Number Of Poles | 3 |
| Phase | 3 pH |
| Returnable | Y |
| Standard | IEC-CSA-UL LISTED |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489CSA C22.2 No.5IEC 60947-2Federal Specification W-C-375B/GENNEMA AB1NMX J-266UTE/VDE/BS/CEI/UNE/CCC/CE MarkedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Temperature Rating | -13 to 158 °F |
| Trip Range | 800 A,800 A |
| Type | 80% Rated |
| UNSPSC | 39121601 |
| UPC 11 | 78590159003 |
| UPC 12 | 785901590033 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 11.64 in |
| Width [Metric] | 29.8500 cm |
| Wire Size | 3/0 AWG to 500 kcmil |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 800 A |
| Interrupt Rating | 18 kA |
| Trip Type | Electronic Basic ET 1.0 LI/Non-Interchangeable |
| Voltage Rating | 600 VAC |
| Distribution |
| UNIT MOUNT |
| A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility |
| 600 VAC, 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC interrupt rating |
| Provide means to manually disconnect power to the circuit |
| Provide enhanced coordination by their adjustabilit |
| Provide high interrupting ratings and withstand ratings |
