Schneider Electric PowerPact™ HLL26030 Molded Case Circuit Breaker, 600 VAC, 30 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Schneider Electric PowerPact™ HLL26030 Molded Case Circuit Breaker, 600 VAC, 30 A, 2 Poles, Thermal Magnetic Trip
SKU429255
MFGR #HLL26030
$/ea
Schneider Electric HLL26030 MOLDED CASE CIRCUIT BREAKER 600V 30A,250 V DC-600 V AC,250 V DC-600 V AC,50 kA 600 V AC-125 kA 240 V AC-100 kA 480 V AC-20 kA 250 V DC,30 A,30 A,350 A,750 A,L,circuit breaker,thermal-magnetic,unit mount
Schneider Electric HLL26030 MOLDED CASE CIRCUIT BREAKER 600V 30A,250 V DC-600 V AC,250 V DC-600 V AC,50 kA 600 V AC-125 kA 240 V AC-100 kA 480 V AC-20 kA 250 V DC,30 A,30 A,350 A,750 A,L,circuit breaker,thermal-magnetic,unit mount
Alternate Catalog Number HLL26030 ARRA Compliant N Buy American Compliant N Catalog Number HLL26030 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE Connection Type Line/Load Lug Country of Origin MX Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0214 lb Gross Weight per Pack Metric 2.14 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.0180 in Height [Metric] 13.0180 cm Item Group 01120 Length 21.4330 in Length [Metric] 21.4330 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=424457&lang=en-us Mounting Type Surface Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable Y Standard CSA-CE-UL LISTED-IEC Temperature Rating 104 °F Trip Range 350 to 750 A Type Type HLL UNSPSC 39121601 UPC 11 78590165918 UPC 12 785901659181 Warranty Description Contractual Warranty:18 months Width 18.4150 in Width [Metric] 18.4150 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 30 A Interrupt Rating 125 kA at 240 VAC/100 kA at 480 VAC/50 kA at 600 VAC/20 kA at 250 VDC/50 kA at 500 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 to 500 VDC UNIT MOUNT Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency 125 kA at 240 VAC, 100 kA at 480 VAC, 50 kA at 600 VAC, 20 kA at 250 VDC, 50 kA at 500 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | HLL26030 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HLL26030 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE |
| Connection Type | Line/Load Lug |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 6.4 in H x 2.74 in W x 4.36 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0214 lb |
| Gross Weight per Pack Metric | 2.14 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.0180 in |
| Height [Metric] | 13.0180 cm |
| Item Group | 01120 |
| Length | 21.4330 in |
| Length [Metric] | 21.4330 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=424457&lang=en-us |
| Mounting Type | Surface |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | Y |
| Standard | CSA-CE-UL LISTED-IEC |
| Temperature Rating | 104 °F |
| Trip Range | 350 to 750 A |
| Type | Type HLL |
| UNSPSC | 39121601 |
| UPC 11 | 78590165918 |
| UPC 12 | 785901659181 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 18.4150 in |
| Width [Metric] | 18.4150 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 30 A |
| Interrupt Rating | 125 kA at 240 VAC/100 kA at 480 VAC/50 kA at 600 VAC/20 kA at 250 VDC/50 kA at 500 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 to 500 VDC |
| UNIT MOUNT |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 125 kA at 240 VAC, 100 kA at 480 VAC, 50 kA at 600 VAC, 20 kA at 250 VDC, 50 kA at 500 VDC interrupt rating |
