Steiner serves territories in Northern Illinois, Northwest Indiana and Southern Wisconsin. Please for assistance if outside our sales territory.
Schneider Electric 9001SK1L1GH13 PUSHBUTTON 600VAC
SKU172521
MFGR #9001SK1L1GH13
Your Cost: $232.13/ea
List: Schneider Electric 9001SK1L1GH13 PUSHBUTTON 600VAC 10AMP 30MM SK +OPTIONS,1 NO - 1 NC,10A,30mm Round,600V,AC15 - DC13,Illuminated,K,NEMA 1/2/3/3R/4/4X/6/12/13,Panel,Pushbutton,Screw Clamp,UL File Number E42259 CCN NKCR - CSA File Number LR24590 Class 3211-03 - CE Marked,Water tight, Dust tight, Oil tight and Corrosion Resistant (Indoor/Outdoor),black plastic,unmarked,illuminated push-button,momentary
Schneider Electric 9001SK1L1GH13 PUSHBUTTON 600VAC 10AMP 30MM SK +OPTIONS,1 NO - 1 NC,10A,30mm Round,600V,AC15 - DC13,Illuminated,K,NEMA 1/2/3/3R/4/4X/6/12/13,Panel,Pushbutton,Screw Clamp,UL File Number E42259 CCN NKCR - CSA File Number LR24590 Class 3211-03 - CE Marked,Water tight, Dust tight, Oil tight and Corrosion Resistant (Indoor/Outdoor),black plastic,unmarked,illuminated push-button,momentary
Action Standard Actuator Green flush; spring return Alternate Catalog Number 9001SK1L1GH13 Amperage Rating 3 A 240 V, AC-15, A600-Q600 NEMA Application ILLUMINATED PUSH-BUTTON ARRA Compliant N Bezel|Housing Black Plastic Buy American Compliant N Catalog Number 9001SK1L1GH13 Connection SCREW CLAMP TERMINALS 1 X 0.22...2 X 1.5 MMA² EN/IEC 60947-1 Contact Mode Momentary Contact Rating 6 A at 120 VAC, 3 A at 240 VAC, 1.5 A at 480 VAC, 1.2 A at 600 VAC, 0.55 A at 125 VDC, 0.27 A at 250 VDC, 0.1 A at 600 VDC Country of Origin US Currency USD Enclosure NEMA 1-NEMA 12-NEMA 13-NEMA 2-NEMA 3-NEMA 3R-NEMA 4-NEMA 4X Enclosure Type NEMA 1/2/3/3R/4/4X/6/12/13/IP65 Environmental Conditions -13 to 158 deg F Operating Temperature, -40 to 158 deg F Storage Temperature EU RoHS Indicator Y Gross Volume Per Pack 20.70 Gross Volume per Pack Metric 339.21 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.4600 lb Gross Weight per Pack Metric 208.65 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536509065 Height 5.8420 in Height [Metric] 5.8420 cm Illumination Type incandescent Indicator BA 9S Insulation 250 V 3)EN/IEC 60947-1 Item Group 21429 Lamp Type BA9S Incandescent Length 11.4300 in Length [Metric] 11.4300 cm Material Plastic Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=680090&lang=en-us Mounting Panel Mounting Type Panel Operating Temperature -25-70 A°C Returnable Y Series 9001SK Standard 50 GN IEC 60068-2-27,7 GN 2-500 HZ)IEC 60068-2-6,IP66 IEC 60529,JIS C 852-UL 508-EN/IEC 60947-5-1-EN/IEC 60947-1-JIS C 4520-CSA C22.2 NO 14-EN/IEC 60947-5-4,NEMA-UL 508 Sub Brand 9001SK Substitute Product Catalog Number 9001KA2 Terminal Type Screw/Clamp Type Type SK Corrosion-Resistant Dusttight/Oiltight/Watertight Heavy Duty Transformer Unmarked UNSPSC 39122216 UPC 11 78590104035 UPC 12 785901040354 Voltage Rating 110...120 V AC 50/60 HZ Warranty Description Contractual Warranty:18 months Width 5.0800 in Width [Metric] 5.0800 cm Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Color Green Contact Configuration 1CO Contact Type Slow Break Operator Type Full Guard Button/Spring Return Size 30 mm ILLUMINATED PUSH-BUTTON FULL GUARD IN PLASTIC This Schneider electric Harmony™ 9001SK modular illuminated flush green pushbutton is supplied with a full guard It has a plastic bezel, is supplied with a 110 VAC transformer and has 1NO-1NC contacts It fits in a 30 mm hole Full size and shallow depth light modules Reduced panel space with side by side mounting Easy to actuate, tactile feel operators Maintenance-free operation Simplified installation and identification Wide range of accessories, colored lenses and knobs for customer adaptations
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Action | Standard |
| Actuator | Green flush; spring return |
| Alternate Catalog Number | 9001SK1L1GH13 |
| Amperage Rating | 3 A 240 V, AC-15, A600-Q600 NEMA |
| Application | ILLUMINATED PUSH-BUTTON |
| ARRA Compliant | N |
| Bezel|Housing | Black Plastic |
| Buy American Compliant | N |
| Catalog Number | 9001SK1L1GH13 |
| Connection | SCREW CLAMP TERMINALS 1 X 0.22...2 X 1.5 MMA² EN/IEC 60947-1 |
| Contact Mode | Momentary |
| Contact Rating | 6 A at 120 VAC, 3 A at 240 VAC, 1.5 A at 480 VAC, 1.2 A at 600 VAC, 0.55 A at 125 VDC, 0.27 A at 250 VDC, 0.1 A at 600 VDC |
| Country of Origin | US |
| Currency | USD |
| Enclosure | NEMA 1-NEMA 12-NEMA 13-NEMA 2-NEMA 3-NEMA 3R-NEMA 4-NEMA 4X |
| Enclosure Type | NEMA 1/2/3/3R/4/4X/6/12/13/IP65 |
| Environmental Conditions | -13 to 158 deg F Operating Temperature, -40 to 158 deg F Storage Temperature |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 20.70 |
| Gross Volume per Pack Metric | 339.21 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.4600 lb |
| Gross Weight per Pack Metric | 208.65 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536509065 |
| Height | 5.8420 in |
| Height [Metric] | 5.8420 cm |
| Illumination Type | incandescent |
| Indicator | BA 9S |
| Insulation | 250 V 3)EN/IEC 60947-1 |
| Item Group | 21429 |
| Lamp Type | BA9S Incandescent |
| Length | 11.4300 in |
| Length [Metric] | 11.4300 cm |
| Material | Plastic |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=680090&lang=en-us |
| Mounting | Panel |
| Mounting Type | Panel |
| Operating Temperature | -25-70 A°C |
| Returnable | Y |
| Series | 9001SK |
| Standard | 50 GN IEC 60068-2-27,7 GN 2-500 HZ)IEC 60068-2-6,IP66 IEC 60529,JIS C 852-UL 508-EN/IEC 60947-5-1-EN/IEC 60947-1-JIS C 4520-CSA C22.2 NO 14-EN/IEC 60947-5-4,NEMA-UL 508 |
| Sub Brand | 9001SK |
| Substitute Product Catalog Number | 9001KA2 |
| Terminal Type | Screw/Clamp |
| Type | Type SK Corrosion-Resistant Dusttight/Oiltight/Watertight Heavy Duty Transformer Unmarked |
| UNSPSC | 39122216 |
| UPC 11 | 78590104035 |
| UPC 12 | 785901040354 |
| Voltage Rating | 110...120 V AC 50/60 HZ |
| Warranty Description | Contractual Warranty:18 months |
| Width | 5.0800 in |
| Width [Metric] | 5.0800 cm |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Color | Green |
| Contact Configuration | 1CO |
| Contact Type | Slow Break |
| Operator Type | Full Guard Button/Spring Return |
| Size | 30 mm |
| ILLUMINATED PUSH-BUTTON |
| FULL GUARD IN PLASTIC |
| This Schneider electric Harmony™ 9001SK modular illuminated flush green pushbutton is supplied with a full guard |
| It has a plastic bezel, is supplied with a 110 VAC transformer and has 1NO-1NC contacts |
| It fits in a 30 mm hole |
| Full size and shallow depth light modules |
| Reduced panel space with side by side mounting |
| Easy to actuate, tactile feel operators |
| Maintenance-free operation |
| Simplified installation and identification |
| Wide range of accessories, colored lenses and knobs for customer adaptations |
