Littelfuse®
Littelfuse® 23502.5P 235 Fast Acting Cartridge Fuse, 2.5 A, 250 VAC, 100 A Interrupt, Class RK5, Cylindrical Body
Custom_Product_Images_Illustration
Littelfuse®
Littelfuse® 23502.5P 235 Fast Acting Cartridge Fuse, 2.5 A, 250 VAC, 100 A Interrupt, Class RK5, Cylindrical Body
SKU1380565
MFGR #23502.5P
Your Cost: $3.44/ea
List: For over 85 years Littelfuse has been providing fuses to the electrical market. You can continue to count on our manufacturing and supply chain processes to deliver high quality fuses when you need them. At Littelfuse we leverage our global reach to stay on top of the latest applications and standards. Whether your circuit protection needs are focused on OEM, MRO, or construction, we are committed to being your circuit protection partner and appreciate your business.
For over 85 years Littelfuse has been providing fuses to the electrical market. You can continue to count on our manufacturing and supply chain processes to deliver high quality fuses when you need them. At Littelfuse we leverage our global reach to stay on top of the latest applications and standards. Whether your circuit protection needs are focused on OEM, MRO, or construction, we are committed to being your circuit protection partner and appreciate your business.
Alternate Catalog Number 023502.5VXP Application DC Circuits/Motors ARRA Compliant N Body Size 5 mm Dia x 20 mm L Body Type Cartridge Buy American Compliant N Catalog Number 23502.5P Country of Origin MX Currency USD EU RoHS Indicator C Gross Weight Per Pack 0.0040 lb Gross Weight per Pack Metric 1.86 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536100040 Item Group 079458-I6 Material Glass Mounting Type Holder Response Time 4 hr, 1 hr, 5 s Series 235 Standard Standard 248-12 UL & UL198M Listed/CSA Standards RoHS CompliantUL 248-12UL 198MCSA CertifiedPROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer Sub Brand POWR-GARD IDSR Series Terminal Type Ferrule Type Class RK5 UNSPSC 39121627 UPC 11 07945890871 UPC 12 079458908718 Stock Status NONSTOCK Brand Littelfuse® Manufacturer Littelfuse Inc. Amperage Rating 0.4 A Class RK5 Interrupt Rating 10 kA Voltage Rating 250 VAC DC Circuits/Motors Time-Delay Used as supplementary protection in appliance or utilization equipment to provide individual protection for components or internal circuits 0.04365 ohms resistance 5.445 I2T (A2 sec) nominal melting -55 to 125 deg C operating temperature Lead free Nickel-plated brass cap, tin plated copper leads 4 hrs minimum at 100%, 1 hr maximum at 135%, 5 sec at 200% opening time 10 kA at 125 VAC interrupting rating 4 hrs minimum at 1 1 hr maximum at 1.35 5 sec maximum at 200% response time
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | 023502.5VXP |
| Application | DC Circuits/Motors |
| ARRA Compliant | N |
| Body Size | 5 mm Dia x 20 mm L |
| Body Type | Cartridge |
| Buy American Compliant | N |
| Catalog Number | 23502.5P |
| Country of Origin | MX |
| Currency | USD |
| EU RoHS Indicator | C |
| Gross Weight Per Pack | 0.0040 lb |
| Gross Weight per Pack Metric | 1.86 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536100040 |
| Item Group | 079458-I6 |
| Material | Glass |
| Mounting Type | Holder |
| Response Time | 4 hr, 1 hr, 5 s |
| Series | 235 |
| Standard | Standard 248-12 UL & UL198M Listed/CSA |
| Standards | RoHS CompliantUL 248-12UL 198MCSA CertifiedPROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer |
| Sub Brand | POWR-GARD IDSR Series |
| Terminal Type | Ferrule |
| Type | Class RK5 |
| UNSPSC | 39121627 |
| UPC 11 | 07945890871 |
| UPC 12 | 079458908718 |
| Stock Status | NONSTOCK |
| Brand | Littelfuse® |
| Manufacturer | Littelfuse Inc. |
| Amperage Rating | 0.4 A |
| Class | RK5 |
| Interrupt Rating | 10 kA |
| Voltage Rating | 250 VAC |
| DC Circuits/Motors |
| Time-Delay |
| Used as supplementary protection in appliance or utilization equipment to provide individual protection for components or internal circuits |
| 0.04365 ohms resistance |
| 5.445 I2T (A2 sec) nominal melting |
| -55 to 125 deg C operating temperature |
| Lead free |
| Nickel-plated brass cap, tin plated copper leads |
| 4 hrs minimum at 100%, 1 hr maximum at 135%, 5 sec at 200% opening time |
| 10 kA at 125 VAC interrupting rating |
| 4 hrs minimum at 1 1 hr maximum at 1.35 5 sec maximum at 200% response time |
