- Applications
- Features
General Purpose |
Time-Delay |
Designed to international (IEC) standards for use globally |
Meets the IEC 60127-2, sheet 3 specification for time lag fuses |
Lead free |
Nickel-plated brass cap, tin plated copper leads |
-55 to 125 deg C operating temperature |
30 min minimum at 150%, 2 min maximum at 210%, 0.6 to 10 sec at 275%, 0.15 to 3 sec at 400%, 0.02 to 0.3 sec at 1000% opening time |
80 A at 250 VAC interrupting rating |
35 kA at 250 VAC interrupt rating |
