Leviton® ML3-P Locking Plug, 125/250 VAC, 15 A, 3 Poles, 3 Wires, Black/White
Custom_Product_Images_Illustration
Leviton® ML3-P Locking Plug, 125/250 VAC, 15 A, 3 Poles, 3 Wires, Black/White
SKU73541
MFGR #ML3-P
Your Cost: $14.27/ea
List: Leviton® Locking Plug, 125/250 VAC, 15 A, 1/2 hp, 3 Poles, 3 Wires, NEMA ML1P, Industrial Grade, 0.218 to 0.43 in Cord Dia, Screw Terminal, Nylon, Black/White, 1.26 in Dia x 1.88 in L
Leviton® Locking Plug, 125/250 VAC, 15 A, 1/2 hp, 3 Poles, 3 Wires, NEMA ML1P, Industrial Grade, 0.218 to 0.43 in Cord Dia, Screw Terminal, Nylon, Black/White, 1.26 in Dia x 1.88 in L
Application Industrial ARRA Compliant C Buy American Compliant C Catalog Number ML3-P Cord Diameter 0.218 to 0.43 in Country of Origin US Currency USD Dimensions 1.26 in Dia x 1.88 in H Environmental Conditions Flammability (Rated HB or better UL94) EU RoHS Indicator C Grade Industrial Gross Weight Per Pack 0.1200 lb Gross Weight per Pack Metric 0.05 Gross Weight UOM Metric kg Height 6.6250 in Height [Metric] 3.2004 cm Horsepower 1/2 hp Length 9.0000 in Length [Metric] 12.7000 cm Material Super Tough Nylon (Body) Mounting Cable NEMA Rating ML1P Number Of Poles 3 Size 1.26 Dia x 1.88 H in Standard NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File LR-406);UL Listed 498 (File E13393);UL Fed Spec WC-596 (File E13393) Standards ARRA CompliantBuy American Act CompliantRoHS CompliantNEMA WD1/WD6ANSI C73NOM 057CSA C22.2 No.42 File No. LR406UL 498 File No. E13393Federal Specification WC596UL94 V-2 Flammability Rating Sub Brand Black & White Midget Terminal Type Screw Type Locking Plug UNSPSC 39121402 UPC 11 07847798721 UPC 12 078477987216 Width 6.00 in Width [Metric] 15.2400 cm Wire Size 18-14 (Terminal Accommodation);.218-.430 IN (Cord Grip Range) Stock Status NONSTOCK Brand Leviton® Manufacturer Leviton Manufacturing Co., Inc. Amperage Rating 15 A Color Black/White Number of Wires 3 Voltage Rating 125/250 V Industrial Offers a smaller form factor for limited-space applications Locking plugs feature heavy-duty nylon construction for top performance in the environmental extremes of grueling industrial settings Backed by a lifetime warranty Flammability rated HB or better UL 94 Cable mounting Non-grounding Super tough nylon MiniLock 0.218 - 0.43 in Cord
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Industrial |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | ML3-P |
| Cord Diameter | 0.218 to 0.43 in |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 1.26 in Dia x 1.88 in H |
| Environmental Conditions | Flammability (Rated HB or better UL94) |
| EU RoHS Indicator | C |
| Grade | Industrial |
| Gross Weight Per Pack | 0.1200 lb |
| Gross Weight per Pack Metric | 0.05 |
| Gross Weight UOM Metric | kg |
| Height | 6.6250 in |
| Height [Metric] | 3.2004 cm |
| Horsepower | 1/2 hp |
| Length | 9.0000 in |
| Length [Metric] | 12.7000 cm |
| Material | Super Tough Nylon (Body) |
| Mounting | Cable |
| NEMA Rating | ML1P |
| Number Of Poles | 3 |
| Size | 1.26 Dia x 1.88 H in |
| Standard | NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File LR-406);UL Listed 498 (File E13393);UL Fed Spec WC-596 (File E13393) |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantNEMA WD1/WD6ANSI C73NOM 057CSA C22.2 No.42 File No. LR406UL 498 File No. E13393Federal Specification WC596UL94 V-2 Flammability Rating |
| Sub Brand | Black & White Midget |
| Terminal Type | Screw |
| Type | Locking Plug |
| UNSPSC | 39121402 |
| UPC 11 | 07847798721 |
| UPC 12 | 078477987216 |
| Width | 6.00 in |
| Width [Metric] | 15.2400 cm |
| Wire Size | 18-14 (Terminal Accommodation);.218-.430 IN (Cord Grip Range) |
| Stock Status | NONSTOCK |
| Brand | Leviton® |
| Manufacturer | Leviton Manufacturing Co., Inc. |
| Amperage Rating | 15 A |
| Color | Black/White |
| Number of Wires | 3 |
| Voltage Rating | 125/250 V |
| Industrial |
| Offers a smaller form factor for limited-space applications |
| Locking plugs feature heavy-duty nylon construction for top performance in the environmental extremes of grueling industrial settings |
| Backed by a lifetime warranty |
| Flammability rated HB or better UL 94 |
| Cable mounting |
| Non-grounding |
| Super tough nylon |
| MiniLock |
| 0.218 - 0.43 in Cord |
