Leviton® 8350 Non-Grounding Straight Blade Power Receptacle, 120/208 VAC, 50 A, 4 Poles, 4 Wires, Black
Custom_Product_Images_Illustration
Leviton® 8350 Non-Grounding Straight Blade Power Receptacle, 120/208 VAC, 50 A, 4 Poles, 4 Wires, Black
SKU320579
MFGR #8350
$/ea
Leviton's line of extra heavy duty industrial grade receptacles are designed and manufactured to withstand the harsh conditions typically associated with industrial environments. Available in a wide variety of configurations, including isolated ground, tamper-resistant, hospital grade, etc., these industrial grade devices are the electrical contractor's choice for use in factories, schools, hospitals and commercial office buildings.
Leviton's line of extra heavy duty industrial grade receptacles are designed and manufactured to withstand the harsh conditions typically associated with industrial environments. Available in a wide variety of configurations, including isolated ground, tamper-resistant, hospital grade, etc., these industrial grade devices are the electrical contractor's choice for use in factories, schools, hospitals and commercial office buildings.
Application Commercial ARRA Compliant C Buy American Compliant C Catalog Number 8350 Connection Side Wired Country of Origin MX Currency USD Depth 2.10 in Dielectric Strength 2000 (Min.) V Dimensions 3.75 in H x 2.75 in W x 2.1 in D Environmental Conditions Flammability (Rated V-2 per UL94) EU RoHS Indicator C Grade Commercial Gross Weight Per Pack 4.4000 lb Gross Weight per Pack Metric 0.20 Gross Weight UOM Metric kg Height 6.0000 in Height [Metric] 9.8425 cm Horsepower 7-1/2 hp Length 12.0000 in Length [Metric] 7.3025 cm Material Thermoplastic Mounting Box NEMA Rating 18-50R Number Of Poles 4 Phase 3 Size 3.75 H x 2.75 W x 2.10 D in Standard NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File 152105);UL Listed 498 (File E13399, File E13393) Standards ARRA CompliantBuy American Act CompliantRoHS CompliantNEMA WD1/WD6ANSI C73NOM 057CSA C22.2 No. 42 File No. 152105UL 498 File No. E13399/E13393UL94 V-2 Flammability Rating Temperature Rating -40 to +60 °C Terminal Type Side Wired Type Power Receptacle UNSPSC 39121406 UPC 11 07847784328 UPC 12 078477843284 Width 2.28 in Width [Metric] 5.7937 cm Wire Size 14-6 AWG Stock Status NONSTOCK Brand Leviton® Manufacturer Leviton Manufacturing Co., Inc. Amperage Rating 50 A Color Black Number of Wires 4 Voltage Rating 120/208 V Commercial Box mounting Withstands 2000 VAC per UL498 dielectric voltage Maximum 30 deg C after 50 cycles OL at 150% rated current temperature rise Brass-hot, green-ground, silver-neutral terminal Nylon face material Brass double-wipe line contacts Galvanized steel strap material 3 phase, up to 4 AWG terminal accommodation
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Commercial |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | 8350 |
| Connection | Side Wired |
| Country of Origin | MX |
| Currency | USD |
| Depth | 2.10 in |
| Dielectric Strength | 2000 (Min.) V |
| Dimensions | 3.75 in H x 2.75 in W x 2.1 in D |
| Environmental Conditions | Flammability (Rated V-2 per UL94) |
| EU RoHS Indicator | C |
| Grade | Commercial |
| Gross Weight Per Pack | 4.4000 lb |
| Gross Weight per Pack Metric | 0.20 |
| Gross Weight UOM Metric | kg |
| Height | 6.0000 in |
| Height [Metric] | 9.8425 cm |
| Horsepower | 7-1/2 hp |
| Length | 12.0000 in |
| Length [Metric] | 7.3025 cm |
| Material | Thermoplastic |
| Mounting | Box |
| NEMA Rating | 18-50R |
| Number Of Poles | 4 |
| Phase | 3 |
| Size | 3.75 H x 2.75 W x 2.10 D in |
| Standard | NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File 152105);UL Listed 498 (File E13399, File E13393) |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantNEMA WD1/WD6ANSI C73NOM 057CSA C22.2 No. 42 File No. 152105UL 498 File No. E13399/E13393UL94 V-2 Flammability Rating |
| Temperature Rating | -40 to +60 °C |
| Terminal Type | Side Wired |
| Type | Power Receptacle |
| UNSPSC | 39121406 |
| UPC 11 | 07847784328 |
| UPC 12 | 078477843284 |
| Width | 2.28 in |
| Width [Metric] | 5.7937 cm |
| Wire Size | 14-6 AWG |
| Stock Status | NONSTOCK |
| Brand | Leviton® |
| Manufacturer | Leviton Manufacturing Co., Inc. |
| Amperage Rating | 50 A |
| Color | Black |
| Number of Wires | 4 |
| Voltage Rating | 120/208 V |
| Commercial |
| Box mounting |
| Withstands 2000 VAC per UL498 dielectric voltage |
| Maximum 30 deg C after 50 cycles OL at 150% rated current temperature rise |
| Brass-hot, green-ground, silver-neutral terminal |
| Nylon face material |
| Brass double-wipe line contacts |
| Galvanized steel strap material |
| 3 phase, up to 4 AWG terminal accommodation |
