Leviton® 2310-B Grounding Locking Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Black
Custom_Product_Images_Illustration
Leviton® 2310-B Grounding Locking Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Black
SKU1053218
MFGR #2310-B
Your Cost: $13.37/ea
List: Leviton®, 2310-B, Locking Receptacle, Grounding, 125 VAC, 20 A, 1 hp, 2 Pole, 3 Wires, NEMA L5-20R NEMA Rating, Industrial Grade, -40 to 60 deg C, Back/Side Wire Terminal, Polybutylene Terephthalate, Black, 3.63 in H x 1.69 in W x 1.31 in D Dimensions
Leviton®, 2310-B, Locking Receptacle, Grounding, 125 VAC, 20 A, 1 hp, 2 Pole, 3 Wires, NEMA L5-20R NEMA Rating, Industrial Grade, -40 to 60 deg C, Back/Side Wire Terminal, Polybutylene Terephthalate, Black, 3.63 in H x 1.69 in W x 1.31 in D Dimensions
Application Commercial Applications ARRA Compliant C Buy American Compliant C Catalog Number 2310-B Connection Back Wired;Side Wired Country of Origin MX Currency USD Depth 1.31 in Dielectric Strength 2000 (Min.) Dimensions 3.63 in H x 1.69 in W x 1.31 in D Environmental Conditions Flammability (Rated V-2, Rated V-0 per UL94) EU RoHS Indicator C Grade Industrial Gross Weight Per Pack 7.0980 lb Gross Weight per Pack Metric 0.10 Gross Weight UOM Metric kg Height 9.3750 in Horsepower 1 Length 9.3750 in Material Polybutylene Terephthalate Mounting Box NEMA Rating NEMA L5-20R Number Of Poles 2 Standard ANSI (C-73);CSA C22.2 No. 42 (File LR-406);NEMA (WD-1, WD-6);NOM Certified (057);UL Fed Spec WC-596 (File E13399);UL Listed 498 (File E13399) Temperature Rating -40 to 60 DEG C Terminal Type Back/Side Wired Type Grounding UNSPSC 39121406 UPC 11 07847713108 UPC 12 078477131084 Width 1.69 in Wire Size 14-8 Stock Status NONSTOCK Brand Leviton® Manufacturer Leviton Manufacturing Co., Inc. Amperage Rating 20 AMP Color Black Number of Wires 3 Voltage Rating 125 Commercial Applications Full rated current limiting Ratings and NEMA ID permanently marked on device for identification Box mounting 14 to 8 AWG terminal accommodation Flush mount
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Commercial Applications |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | 2310-B |
| Connection | Back Wired;Side Wired |
| Country of Origin | MX |
| Currency | USD |
| Depth | 1.31 in |
| Dielectric Strength | 2000 (Min.) |
| Dimensions | 3.63 in H x 1.69 in W x 1.31 in D |
| Environmental Conditions | Flammability (Rated V-2, Rated V-0 per UL94) |
| EU RoHS Indicator | C |
| Grade | Industrial |
| Gross Weight Per Pack | 7.0980 lb |
| Gross Weight per Pack Metric | 0.10 |
| Gross Weight UOM Metric | kg |
| Height | 9.3750 in |
| Horsepower | 1 |
| Length | 9.3750 in |
| Material | Polybutylene Terephthalate |
| Mounting | Box |
| NEMA Rating | NEMA L5-20R |
| Number Of Poles | 2 |
| Standard | ANSI (C-73);CSA C22.2 No. 42 (File LR-406);NEMA (WD-1, WD-6);NOM Certified (057);UL Fed Spec WC-596 (File E13399);UL Listed 498 (File E13399) |
| Temperature Rating | -40 to 60 DEG C |
| Terminal Type | Back/Side Wired |
| Type | Grounding |
| UNSPSC | 39121406 |
| UPC 11 | 07847713108 |
| UPC 12 | 078477131084 |
| Width | 1.69 in |
| Wire Size | 14-8 |
| Stock Status | NONSTOCK |
| Brand | Leviton® |
| Manufacturer | Leviton Manufacturing Co., Inc. |
| Amperage Rating | 20 AMP |
| Color | Black |
| Number of Wires | 3 |
| Voltage Rating | 125 |
| Commercial Applications |
| Full rated current limiting |
| Ratings and NEMA ID permanently marked on device for identification |
| Box mounting |
| 14 to 8 AWG terminal accommodation |
| Flush mount |
