Leviton® 1254-R 1-Phase 4-in-1 Extra Heavy Duty Grounding Quadruplex Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Red
Custom_Product_Images_Illustration
Leviton® 1254-R 1-Phase 4-in-1 Extra Heavy Duty Grounding Quadruplex Straight Blade Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Red
SKU1288279
MFGR #1254-R
$/ea
Leviton®, 1254-R, Straight Blade Receptacle, 1-Phase 4-in-1 Extra Heavy Duty Grounding Quadruplex, 125 VAC, 15 A, 1/2 hp, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Commercial Grade, -40 to 60 deg C, Screw Terminal, Nylon, Red, 4.5 in L x 4.5 in W x 1.15 in D Dimensions
Leviton®, 1254-R, Straight Blade Receptacle, 1-Phase 4-in-1 Extra Heavy Duty Grounding Quadruplex, 125 VAC, 15 A, 1/2 hp, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Commercial Grade, -40 to 60 deg C, Screw Terminal, Nylon, Red, 4.5 in L x 4.5 in W x 1.15 in D Dimensions
Application Commercial ARRA Compliant C Buy American Compliant C Catalog Number 1254-R Connection Screw Terminal Country of Origin MX Depth 1.15 in Dielectric Strength 2000 (Min.) Dimensions 4.5 in L x 4.5 in W x 1.15 in D Environmental Conditions Flammability (Rated V-2 per UL94) EU RoHS Indicator C Grade Commercial Gross Weight Per Pack 6.1000 lb Gross Weight per Pack Metric 0.28 Gross Weight UOM Metric kg Hazard Class N Height 8.5000 in Height [Metric] 11.5875 cm Horsepower 1/2 Length 12.7500 in Length [Metric] 11.5875 cm Material Nylon Mounting Wall Box NEMA Rating NEMA 5-15R Number Of Poles 2 Phase 1 Standard ANSI (C-73);CSA C22.2 No. 42 (File 152105);NEMA (WD-1, WD-6);NOM Certified (057);UL Listed 498 (File E13399) Temperature Rating -40 to 60 °C Terminal Type Screw Type 1-Phase 4-in-1 Extra Heavy Duty Grounding Quadruplex UNSPSC 39121406 UPC 11 07847783046 UPC 12 078477830468 Width 1.78 in Width [Metric] 4.5237 cm Wire Size 14-12 Stock Status NONSTOCK Brand Leviton® Manufacturer Leviton Manufacturing Co., Inc. Amperage Rating 15 A Color Red Number of Wires 3 Voltage Rating 125 Commercial Terminal wiring screws fit inside a standard 1-gang wall box, adapter plate not required Impact resistant nylon cover and base for strength and resistance to chemicals and corros Easy-to-read voltage and amperage rating molded onto smooth face T-type triple wipe bronze contacts for maximum performance Ground holes configured up or down to be outside the device, accommodating up to 4 fe #8 terminal screws accept up to no 12 AWG solid or stranded copper wire Termination anchor holes for easy conductor wiring Exclusive shield wall design protects ground connection from contact with live circuit conduc A and B molded on face and back for easy identification of receptacle pairs for split circuit c Wallbox mounting Grounding
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Commercial |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | 1254-R |
| Connection | Screw Terminal |
| Country of Origin | MX |
| Depth | 1.15 in |
| Dielectric Strength | 2000 (Min.) |
| Dimensions | 4.5 in L x 4.5 in W x 1.15 in D |
| Environmental Conditions | Flammability (Rated V-2 per UL94) |
| EU RoHS Indicator | C |
| Grade | Commercial |
| Gross Weight Per Pack | 6.1000 lb |
| Gross Weight per Pack Metric | 0.28 |
| Gross Weight UOM Metric | kg |
| Hazard Class | N |
| Height | 8.5000 in |
| Height [Metric] | 11.5875 cm |
| Horsepower | 1/2 |
| Length | 12.7500 in |
| Length [Metric] | 11.5875 cm |
| Material | Nylon |
| Mounting | Wall Box |
| NEMA Rating | NEMA 5-15R |
| Number Of Poles | 2 |
| Phase | 1 |
| Standard | ANSI (C-73);CSA C22.2 No. 42 (File 152105);NEMA (WD-1, WD-6);NOM Certified (057);UL Listed 498 (File E13399) |
| Temperature Rating | -40 to 60 °C |
| Terminal Type | Screw |
| Type | 1-Phase 4-in-1 Extra Heavy Duty Grounding Quadruplex |
| UNSPSC | 39121406 |
| UPC 11 | 07847783046 |
| UPC 12 | 078477830468 |
| Width | 1.78 in |
| Width [Metric] | 4.5237 cm |
| Wire Size | 14-12 |
| Stock Status | NONSTOCK |
| Brand | Leviton® |
| Manufacturer | Leviton Manufacturing Co., Inc. |
| Amperage Rating | 15 A |
| Color | Red |
| Number of Wires | 3 |
| Voltage Rating | 125 |
| Commercial |
| Terminal wiring screws fit inside a standard 1-gang wall box, adapter plate not required |
| Impact resistant nylon cover and base for strength and resistance to chemicals and corros |
| Easy-to-read voltage and amperage rating molded onto smooth face |
| T-type triple wipe bronze contacts for maximum performance |
| Ground holes configured up or down to be outside the device, accommodating up to 4 fe |
| #8 terminal screws accept up to no 12 AWG solid or stranded copper wire |
| Termination anchor holes for easy conductor wiring |
| Exclusive shield wall design protects ground connection from contact with live circuit conduc |
| A and B molded on face and back for easy identification of receptacle pairs for split circuit c |
| Wallbox mounting |
| Grounding |
