Fluke® FLUKE-289 Digital Multimeter, 1000 VDC/VAC, 10 A, 500 MOhm, 1000 VAC/VDC, 10 A, 500 MOhm, Dot Matrix Display
Multimeters
395276
MFG #: FLUKE-289
Fluke®
899.99000
/ ea
Fluke 289 is the next generation high performance industrial logging multimeter designed to solve complex problems in electronics, plant automation, power distribution, and electro-mechanical equipment. With the ability to log data and review it graphically on-screen, you can solve problems faster and help minimize downtime. Let the new 289 be your watchdog for systems or processes while you are off solving other problems.
- http://www.fluke.com(Seller Home Page URL)
- Install Instructions URL - ID-INS-FLUKE-289.pdf(Install Instructions URL)
- Spec Sheet URL - 11095_Spec sheet reference.pdf(Spec Sheet URL)
- Owners Manual URL - 11095_4DRWYJGH1IUC96LO.jpg(Owners Manual URL)
- Video - https://www.youtube.com/embed/mRwsxmn2P-s(Video)
- Applications
- Features
| Solve complex problems in electronics, plant automation, power distribution, and electro-mechanical equipment |
| TrendCapture quickly graphically displays logged data session to quickly determine whether anomalies may have occurred |
| Zoom on trend provides unprecedented ability to view and analyze TrendCapture data, zoom in up to 14 times |
| Selectable AC filter (smoothing mode) helps display a steadier reading when the input signal is changing rapidly or noisy |
| Adjustable recording and auto-hold thresholds, specify a percentage change in the readings that begins a new event |
| Large 50000 count, 1/4 VGA display with white backlight, multiple sets of measurement information can be simultaneously displayed at the same time |
| Logging function with expanded memory for unattended monitoring of signals over time, using on board TrendCapture users can graphically review logged readings without needing a PC |
| Stores up to 15000 recorded events, on board help screens for measurement function |
| Saved measurements allow to name and recall measurements made in the field, optional infrared connector via Fluke® IR3000 FC |
| Real time clock for automatic time stamping of saved readings |
| True-RMS AC voltage and current for accurate measurements on complex signals or non-linear loads, AC bandwidth specified to 100 kHz |
| Relative mode to remove test lead resistance from low Ohm or capacitance measurements, voltage DC, 0.025%, voltage AC, 0.4% (True-RMS) accuracy |
| Resistance range - 500 Ohm, 5 kOhm, 50 kOhm, 500 kOhm, 5 MOhm, 50 MOhm, 500 MOhm with accuracy of +/- 0.05% |
| Capacitance range 1 nF, 10 nF, 100 nF, 1 uF, 10 uF, 100uF, 1000 uF, 10 mF, 100 mF with accuracy of 1% |
| Frequency range 99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz with accuracy of +/-0.005% |
| 100 hr min, 200 hr in logging mode |
| 50000 count, 1/4 VGA display with white backlight display |
| Capacitance range 1 nF, 10 nF, 100 nF, 1 uF, 10 uF, 100uF, 1000 uF, 10 mF, 100 mF with accuracy of 1 % |
| Frequency range 99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz with accuracy of +/- 0.005% |
| 100 hrs minimum, 200 hrs in logging mode |
| 50000 count, 1/4 VGA display with white backlight display |
