EricoĀ® CADWELDĀ® TAC3Q2Q Type TA Standard Weld Metal Mold, 4/0 AWG to 500 kcmil Conductor, Cable to Cable, Graphite
Custom_Product_Images_Illustration
EricoĀ® CADWELDĀ® TAC3Q2Q Type TA Standard Weld Metal Mold, 4/0 AWG to 500 kcmil Conductor, Cable to Cable, Graphite
SKU1176972
MFGR #TAC3Q2Q
$/ea
ERICO CADWELD exothermically welded connections are engineered to provide a permanent, molecular bond that will not loosen or corrode. The connections are designed to maintain for the life of the conductor and/or installation. The ERICO CADWELD connection has a current carrying capacity equal to or greater than that of the conductor and will withstand repeated fault currents without failing during operation. Once completed, installers can clearly ensure quality assurance by visual inspection of the new connection. With reliable connections that consistently exceeded IEEEĀ® 837 2014 EMF test requirements as certified by an independent lab, ERICO CADWELD is the ultimate welded connection.
ERICO CADWELD exothermically welded connections are engineered to provide a permanent, molecular bond that will not loosen or corrode. The connections are designed to maintain for the life of the conductor and/or installation. The ERICO CADWELD connection has a current carrying capacity equal to or greater than that of the conductor and will withstand repeated fault currents without failing during operation. Once completed, installers can clearly ensure quality assurance by visual inspection of the new connection. With reliable connections that consistently exceeded IEEEĀ® 837 2014 EMF test requirements as certified by an independent lab, ERICO CADWELD is the ultimate welded connection.
Catalog Number TAC3Q2Q Country of Origin US Gross Weight Per Pack 3.5300 lb Standard none Standards ARRA CompliantBuy American Act Compliant Sub Brand ERICO Type TA UNSPSC 39121457 UPC 11 78285655421 UPC 12 78285655421 Stock Status NONSTOCK Brand nVent ERICO Manufacturer nVent MOLD,CABLE HORZ TEE Forms a permanent, low resistance connection Provides a molecular bond nVent ERICOĀ® CADWELDĀ® exothermic connections are rated with the same current capacity as the conductor Portable installation equipment with no external source of power required Horizontal tee 500 kcmil Stranded Run Concentric Cable, 4/0 AWG Stranded Tap Concentric Cable Tee of horizontal run and tap cables 20.7 mm Conductor 1 and 13.4 mm Conductor 2 Nominal Outer Dia Installers can be easily trained to make ERICO CADWELD exothermic connections Connections are visually inspected Copper Cable
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Catalog Number | TAC3Q2Q |
| Country of Origin | US |
| Gross Weight Per Pack | 3.5300 lb |
| Standard | none |
| Standards | ARRA CompliantBuy American Act Compliant |
| Sub Brand | ERICO |
| Type | TA |
| UNSPSC | 39121457 |
| UPC 11 | 78285655421 |
| UPC 12 | 78285655421 |
| Stock Status | NONSTOCK |
| Brand | nVent ERICO |
| Manufacturer | nVent |
| MOLD,CABLE HORZ TEE |
| Forms a permanent, low resistance connection |
| Provides a molecular bond |
| nVent ERICOĀ® CADWELDĀ® exothermic connections are rated with the same current capacity as the conductor |
| Portable installation equipment with no external source of power required |
| Horizontal tee |
| 500 kcmil Stranded Run Concentric Cable, 4/0 AWG Stranded Tap Concentric Cable |
| Tee of horizontal run and tap cables |
| 20.7 mm Conductor 1 and 13.4 mm Conductor 2 Nominal Outer Dia |
| Installers can be easily trained to make ERICO CADWELD exothermic connections |
| Connections are visually inspected |
| Copper Cable |
