Appleton® NEER™ LB-125-SS Type LB Conduit Body, 1-1/4 in Hub, Aluminium, Epoxy Powder Coated
Custom_Product_Images_Illustration
Appleton® NEER™ LB-125-SS Type LB Conduit Body, 1-1/4 in Hub, Aluminium, Epoxy Powder Coated
SKU294155
MFGR #LB125SS
Your Cost: $55.10/ea
NEER™ aluminum threaded conduit bodies are used with rigid conduit or IMC to provide access to the interior of the raceway for wire pulling, splicing and maintenance.
NEER™ aluminum threaded conduit bodies are used with rigid conduit or IMC to provide access to the interior of the raceway for wire pulling, splicing and maintenance.
Application Provides access to the interior of the raceway for wire pulling , splicing and maintenance, Allows connection of straight and branch conduit runs and 90 degree bends ARRA Compliant N Buy American Compliant N Catalog Number LB125SS Connection Type Set Screw Country of Origin IN Currency USD Dimensions 7.81 in L x 2.49 in W x 3.5 in H Enclosure NEMA FB-1 EU RoHS Indicator C Gross Weight Per Pack 1.1700 lb Gross Weight per Pack Metric 0.53 Gross Weight UOM Metric kg Height 0.98 in Height [Metric] 24.8920 mm Length 26.50 in Length [Metric] 67.3100 cm Number of Hubs 2 Standard UL Standard: 514A; UL Listed: E53330; CSA Standard: C22.2 No. 18.3; CSA Certified: 208044; NEMA: FB-1 Standards UL 514A File No. E53330CSA C22.2 No. 18.3/208044RoHS Compliant Sub Brand NEER Type Type LB UNSPSC 39131708 UPC 11 68785536127 UPC 12 687855361274 Width 8.00 in Width [Metric] 20.3200 cm Stock Status NONSTOCK Brand Appleton™ Manufacturer Appleton Finish Epoxy Powder Coated Hub Size 1-1/4 in Material Die Cast Aluminum Provides access to the interior of the raceway for wire pulling , splicing and maintenance, Allows connection of straight and branch conduit runs and 90 degree bends 1-1/4 IN Trade Size Type LB Aluminum Set Screw Conduit Body , For Use with EMT Allows connection of straight and branch EMT conduit runs and 90 deg bends Set screw type aluminum conduit bodies are used on steel EMT providing access to the interior of the raceway for wire pulling, splicing and maintenance Die Cast Aluminum
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Provides access to the interior of the raceway for wire pulling , splicing and maintenance, Allows connection of straight and branch conduit runs and 90 degree bends |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | LB125SS |
| Connection Type | Set Screw |
| Country of Origin | IN |
| Currency | USD |
| Dimensions | 7.81 in L x 2.49 in W x 3.5 in H |
| Enclosure | NEMA FB-1 |
| EU RoHS Indicator | C |
| Gross Weight Per Pack | 1.1700 lb |
| Gross Weight per Pack Metric | 0.53 |
| Gross Weight UOM Metric | kg |
| Height | 0.98 in |
| Height [Metric] | 24.8920 mm |
| Length | 26.50 in |
| Length [Metric] | 67.3100 cm |
| Number of Hubs | 2 |
| Standard | UL Standard: 514A; UL Listed: E53330; CSA Standard: C22.2 No. 18.3; CSA Certified: 208044; NEMA: FB-1 |
| Standards | UL 514A File No. E53330CSA C22.2 No. 18.3/208044RoHS Compliant |
| Sub Brand | NEER |
| Type | Type LB |
| UNSPSC | 39131708 |
| UPC 11 | 68785536127 |
| UPC 12 | 687855361274 |
| Width | 8.00 in |
| Width [Metric] | 20.3200 cm |
| Stock Status | NONSTOCK |
| Brand | Appleton™ |
| Manufacturer | Appleton |
| Finish | Epoxy Powder Coated |
| Hub Size | 1-1/4 in |
| Material | Die Cast Aluminum |
| Provides access to the interior of the raceway for wire pulling , splicing and maintenance, Allows connection of straight and branch conduit runs and 90 degree bends |
| 1-1/4 IN Trade Size Type LB Aluminum Set Screw Conduit Body , For Use with EMT |
| Allows connection of straight and branch EMT conduit runs and 90 deg bends |
| Set screw type aluminum conduit bodies are used on steel EMT providing access to the interior of the raceway for wire pulling, splicing and maintenance |
| Die Cast Aluminum |
