Appleton® CGG275 CG Series Liquidtight Strain Relief Cord Connector, 5/8 to 3/4 in Cable Openings, Neoprene Grommet
Liquid Tight Straight Cord Connectors
903473
MFG #: CGG275
Appleton™
4.45000
/ ea
These cord and cable connectors provide a liquidtight and strain relief termination for flexible type neoprene, hypalon and PVC jacketed power or control cord and cable.
- Catalog URL - Appleton_SEHT_75_Brochure.pdf(Catalog URL)
- http://www.appletonelec.com(Seller Home Page URL)
- Line Drawing URL - 11043_CGG-221.jpg(Line Drawing URL)
- Line Drawing URL - CGG-221.jpg(Line Drawing URL)
- Seller Home Page URL - appleton(Seller Home Page URL)
- Spec Sheet URL(Spec Sheet URL)
- Warranty URL - appleton-grp-terms-and-conditions.pdf(Warranty URL)
- Applications
- Features
| For 1/2 IN Hub Straight CG-6250 And 90 DEG CG90-6250 Connector |
| Color code identifies the catalog number and minimum/maximum cable diameter |
| Neoprene sealing grommet firmly but safely grips cable jacket to provide strain relief while protecting internal wiring connections against external tension |
| Steel or Teflon washer reduces friction between grommet and connector cap providing even pressure distribution, eliminating leakage resulting from grommet distortion |
| Large aluminum connectors 1-1/2 in thru 4 in and all steel connectors are constructed with hex head cap |
| For particularly harsh applications, wire mesh strain reliefs may be used with cord and cable connectors |
| Silicone free |
