Fluke®
Amprobe® Navigator™ ACDC-52NAV Clamp Multimeter, 1000 VAC/VDC, 600 A, 100 kOhm, 20 Hz to 10 kHz, 37 mm Jaw
Custom_Product_Images_Illustration
Fluke®
Amprobe® Navigator™ ACDC-52NAV Clamp Multimeter, 1000 VAC/VDC, 600 A, 100 kOhm, 20 Hz to 10 kHz, 37 mm Jaw
SKU772187
MFGR #ACDC-52NAV
Your Cost: $562.99/ea
Amprobe ACDC-52NAV clamp-on power meter is the ideal choice for jobs that require AC/DC current measurements to 600A, AC/DC voltage to 1000V and wide jaws to accommodate large conductors. This AC/DC current clamp meter offers a full range of power quality diagnostics including power and power factor, total harmonics distortion, individual harmonics, in-rush current, phase sequence, TRMS and low pass filter for industrial power monitoring and verifying system conditions
Amprobe ACDC-52NAV clamp-on power meter is the ideal choice for jobs that require AC/DC current measurements to 600A, AC/DC voltage to 1000V and wide jaws to accommodate large conductors. This AC/DC current clamp meter offers a full range of power quality diagnostics including power and power factor, total harmonics distortion, individual harmonics, in-rush current, phase sequence, TRMS and low pass filter for industrial power monitoring and verifying system conditions
AC Current Accuracy +/-1.5 % RDG + 5 LSD Alternate Catalog Number 3729961 Application For professional Use ARRA Compliant U Battery Type 9 Buy American Compliant U Catalog Number ACDC-52NAV Country of Origin TW Counts 10000 Currency USD Dimensions 9.4 in L x 3.4 in W x 2 in H EU RoHS Indicator Y Gross Weight Per Pack 0.8400 lb Gross Weight per Pack Metric 0.38 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 9030310000 Height 2.00 in Height [Metric] 5.0800 cm Jaw size 45 mm Length 9.40 in Length [Metric] 23.8760 cm Operating Temperature 0 to 10 °C Power Accuracy +/-2.5 % RDG + 5 LSD at 10 to 600 kW Power Source 9 VDC AA Alkaline Battery Safety Rating CAT IV 600 V, CAT III 1000 V Standard CE Certified, CAT IV 600 V , CAT III 1000 V Safety Standard Standards RoHS CompliantCE MarkedcULus ListedPROP65: This product is in compliance with PROP65; it is not known to contain any chemicals associated with this regulation Sub Brand True-Rms Navigator Type Clamp Meter UNSPSC 41113678 UPC 11 09596955665 UPC 12 095969556651 Voltage Accuracy +/-1% RDG + 5 LSD for VAC, +/-0.7% RDG + 2 LSD for VDC Voltage Rating 100/1,000//100/1,000 VAC//VDC Width 3.40 in Width [Metric] 8.6360 cm Stock Status NONSTOCK Brand Fluke® Manufacturer Fluke Corporation Display Type Large Backlit LCD Electrical Ratings 100 to 600 A AC/DC, 100 to 1000 VAC/VDC Frequency Rating 20 Hz to 10 kHz Jaw Capacity 45 mm Resistance 1 to 100 kOhm For professional Use True-rms technology improves accuracy in noisy environments, Measures AC/DC voltage to 1000 VAC current to 600 AMP, plus resistance, frequency, capacitance, power factor, total harmonics distortion (THD) and individual harmonics from 1 to 25; Includes inrush current measurement and phase rotation indication for 3-phase motors, Non-contact voltage detection enhances safety; Low pass filter allows measurement of voltage and frequency of variable frequency drives, Continuity beeper quickly identifies shorts and opens; Large backlit digital display with analog bar graph presents the full picture, Min, max, and smart data hold, Peak hold identifies spikes and transients; In-jaw flashlight automatically lights when jaws open to illuminate dark panels and junction boxes, Auto power off conserves battery life, Maximum jaw opening accommodates large conductors up to 1.45 (37 MM), Rubber overmold body absorbs shocks drop proof to 4 FT (1.2 MR); Includes: Test leads, batteries (installed), deluxe carrying case, and user's manual; Storage temperature: -10 To 50 DEG C for current -20 To 60 DEG C for other function, 0 - 80 PCT RH (batteries not fitted) True rms technology improves accuracy in noisy environments Includes inrush current measurement and phase rotation indication for 3-phase motors Non-contact voltage detection enhances safety Low pass filter allows measurement of voltage and frequency of variable frequency drives Continuity beeper quickly identifies shorts and opens Large backlit digital display with analog bar graph presents the full picture Maximum, minimum and smart data hold Peak hold identifies spikes and transients In-jaw flashlight automatically lights when jaws open to illuminate dark panels and junction boxes Auto power off conserves battery life Maximum jaw opening accommodates large conductors up to 1.45 in Rubber over mold body absorbs shocks - drop proof to 4 ft +/-1% RDG + 3 LSD resistance accuracy +/-0.5% RDG + 3 LSD frequency accuracy Measures AC/DC voltage to 1000 VAC/VDC, AC/DC current to 600 A, plus resistance, frequency, capacitance, power and power factor, total harmonics distortion (THD) and individual harmonics from 1 to 25 DC voltage range - 100 V, 1000 V +/- (0.7% rdg + 2 LSD) Capacitance - 400 uF, 4 mF +/- (1.9 % rdg + 8 LSD)
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Media
- Substitute Products
| AC Current Accuracy | +/-1.5 % RDG + 5 LSD |
| Alternate Catalog Number | 3729961 |
| Application | For professional Use |
| ARRA Compliant | U |
| Battery Type | 9 |
| Buy American Compliant | U |
| Catalog Number | ACDC-52NAV |
| Country of Origin | TW |
| Counts | 10000 |
| Currency | USD |
| Dimensions | 9.4 in L x 3.4 in W x 2 in H |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 0.8400 lb |
| Gross Weight per Pack Metric | 0.38 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 9030310000 |
| Height | 2.00 in |
| Height [Metric] | 5.0800 cm |
| Jaw size | 45 mm |
| Length | 9.40 in |
| Length [Metric] | 23.8760 cm |
| Operating Temperature | 0 to 10 °C |
| Power Accuracy | +/-2.5 % RDG + 5 LSD at 10 to 600 kW |
| Power Source | 9 VDC AA Alkaline Battery |
| Safety Rating | CAT IV 600 V, CAT III 1000 V |
| Standard | CE Certified, CAT IV 600 V , CAT III 1000 V Safety Standard |
| Standards | RoHS CompliantCE MarkedcULus ListedPROP65: This product is in compliance with PROP65; it is not known to contain any chemicals associated with this regulation |
| Sub Brand | True-Rms Navigator |
| Type | Clamp Meter |
| UNSPSC | 41113678 |
| UPC 11 | 09596955665 |
| UPC 12 | 095969556651 |
| Voltage Accuracy | +/-1% RDG + 5 LSD for VAC, +/-0.7% RDG + 2 LSD for VDC |
| Voltage Rating | 100/1,000//100/1,000 VAC//VDC |
| Width | 3.40 in |
| Width [Metric] | 8.6360 cm |
| Stock Status | NONSTOCK |
| Brand | Fluke® |
| Manufacturer | Fluke Corporation |
| Display Type | Large Backlit LCD |
| Electrical Ratings | 100 to 600 A AC/DC, 100 to 1000 VAC/VDC |
| Frequency Rating | 20 Hz to 10 kHz |
| Jaw Capacity | 45 mm |
| Resistance | 1 to 100 kOhm |
| For professional Use |
| True-rms technology improves accuracy in noisy environments, Measures AC/DC voltage to 1000 VAC current to 600 AMP, plus resistance, frequency, capacitance, power factor, total harmonics distortion (THD) and individual harmonics from 1 to 25; Includes inrush current measurement and phase rotation indication for 3-phase motors, Non-contact voltage detection enhances safety; Low pass filter allows measurement of voltage and frequency of variable frequency drives, Continuity beeper quickly identifies shorts and opens; Large backlit digital display with analog bar graph presents the full picture, Min, max, and smart data hold, Peak hold identifies spikes and transients; In-jaw flashlight automatically lights when jaws open to illuminate dark panels and junction boxes, Auto power off conserves battery life, Maximum jaw opening accommodates large conductors up to 1.45 (37 MM), Rubber overmold body absorbs shocks drop proof to 4 FT (1.2 MR); Includes: Test leads, batteries (installed), deluxe carrying case, and user's manual; Storage temperature: -10 To 50 DEG C for current -20 To 60 DEG C for other function, 0 - 80 PCT RH (batteries not fitted) |
| True rms technology improves accuracy in noisy environments |
| Includes inrush current measurement and phase rotation indication for 3-phase motors |
| Non-contact voltage detection enhances safety |
| Low pass filter allows measurement of voltage and frequency of variable frequency drives |
| Continuity beeper quickly identifies shorts and opens |
| Large backlit digital display with analog bar graph presents the full picture |
| Maximum, minimum and smart data hold |
| Peak hold identifies spikes and transients |
| In-jaw flashlight automatically lights when jaws open to illuminate dark panels and junction boxes |
| Auto power off conserves battery life |
| Maximum jaw opening accommodates large conductors up to 1.45 in |
| Rubber over mold body absorbs shocks - drop proof to 4 ft |
| +/-1% RDG + 3 LSD resistance accuracy |
| +/-0.5% RDG + 3 LSD frequency accuracy |
| Measures AC/DC voltage to 1000 VAC/VDC, AC/DC current to 600 A, plus resistance, frequency, capacitance, power and power factor, total harmonics distortion (THD) and individual harmonics from 1 to 25 |
| DC voltage range - 100 V, 1000 V +/- (0.7% rdg + 2 LSD) |
| Capacitance - 400 uF, 4 mF +/- (1.9 % rdg + 8 LSD) |
