Acme Electric® DTGB72S Encapsulated Drive Isolation Transformer, 460 VAC Delta Primary, 460Y/266 VAC Secondary, 7.5 kVA
Custom_Product_Images_Illustration
Acme Electric® DTGB72S Encapsulated Drive Isolation Transformer, 460 VAC Delta Primary, 460Y/266 VAC Secondary, 7.5 kVA
SKU68617
MFGR #DTGB72S
Your Cost: $2,139.95/ea
The Acme Drive Isolation Transformers are specifically designed to accommodate the special voltages and kVA sizes unique to AC and DC motor drive applications.
The Acme Drive Isolation Transformers are specifically designed to accommodate the special voltages and kVA sizes unique to AC and DC motor drive applications.
Application Drive Isolation ARRA Compliant C Buy American Compliant C Catalog Number DTGB72S Connection Type Lead Wire Country of Origin MX Currency USD Dimensions 15.21 in H x 19.25 in W x 7.37 in D Enclosure Type NEMA 3R Frequency 60 Hz Gross Weight Per Pack 180.0000 lb Gross Weight per Pack Metric 70.31 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8504320000 Height 15.21 in Height [Metric] 38.6334 cm KVA Rating 7 Length 7.37 in Length [Metric] 18.7198 cm Mounting Wall Mounting Type Wall Number Of Phases 3 Number Of Taps 2 Returnable Y Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 506E79947C22.2 File No. 47LR7357-32 Temperature Rating 115 °C Type Encapsulated UNSPSC 39121029 UPC 11 04750308823 UPC 12 047503088234 Width 19.25 in Width [Metric] 48.8950 cm Stock Status NONSTOCK Brand Acme Electric Manufacturer Acme Electric Frequency Rating 60 Hz Phase 3 Power Rating 7 kVA Primary Voltage 460 VAC Delta Secondary Voltage 460Y/266 VAC Drive Isolation Encapsulated and ventilated designs, all ventilated units, are of strip wound construction Acme reinforced core assemblies enhance quiet operation Nominally 6% impedance Full capacity taps are featured on all units Full range of kVA ratings cover all standard drive systems Ample wiring compartment for easy cable entry Aluminum foil windings Copper wire terminations Wound/distributed core construction Copper terminations for trouble free operation Wound core and strip winding for low losses Electrostatic shield for enhanced protection 5% taps steps
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Drive Isolation |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | DTGB72S |
| Connection Type | Lead Wire |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 15.21 in H x 19.25 in W x 7.37 in D |
| Enclosure Type | NEMA 3R |
| Frequency | 60 Hz |
| Gross Weight Per Pack | 180.0000 lb |
| Gross Weight per Pack Metric | 70.31 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8504320000 |
| Height | 15.21 in |
| Height [Metric] | 38.6334 cm |
| KVA Rating | 7 |
| Length | 7.37 in |
| Length [Metric] | 18.7198 cm |
| Mounting | Wall |
| Mounting Type | Wall |
| Number Of Phases | 3 |
| Number Of Taps | 2 |
| Returnable | Y |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 506E79947C22.2 File No. 47LR7357-32 |
| Temperature Rating | 115 °C |
| Type | Encapsulated |
| UNSPSC | 39121029 |
| UPC 11 | 04750308823 |
| UPC 12 | 047503088234 |
| Width | 19.25 in |
| Width [Metric] | 48.8950 cm |
| Stock Status | NONSTOCK |
| Brand | Acme Electric |
| Manufacturer | Acme Electric |
| Frequency Rating | 60 Hz |
| Phase | 3 |
| Power Rating | 7 kVA |
| Primary Voltage | 460 VAC Delta |
| Secondary Voltage | 460Y/266 VAC |
| Drive Isolation |
| Encapsulated and ventilated designs, all ventilated units, are of strip wound construction |
| Acme reinforced core assemblies enhance quiet operation |
| Nominally 6% impedance |
| Full capacity taps are featured on all units |
| Full range of kVA ratings cover all standard drive systems |
| Ample wiring compartment for easy cable entry |
| Aluminum foil windings |
| Copper wire terminations |
| Wound/distributed core construction |
| Copper terminations for trouble free operation |
| Wound core and strip winding for low losses |
| Electrostatic shield for enhanced protection |
| 5% taps steps |
