Acme Electric® DTGA72S Encapsulated Drive Isolation Transformer, 460 VAC Delta Primary, 230Y/133 VAC Secondary, 7.5 kVA
Drive Isolation Transformers
112333
MFG #: DTGA72S
Acme Electric
2018.82000
/ ea
- Catalog URL - IDW_DOCUMENT_1480741299932.pdf(Catalog URL)
- Install Instructions 1 URL - 11112_GMEQCKR8X4L35ATS.pdf(Install Instructions 1 URL)
- Install Instructions 1 URL - 11112_HP5W1VA2YL0ZOUM3.pdf(Install Instructions 1 URL)
- Install Instructions 1 URL - Acme Electric Manual A.pdf(Install Instructions 1 URL)
- Safety Data Sheet URL - HCC_SDS.pdf(Safety Data Sheet URL)
- Seller Home Page URL - en(Seller Home Page URL)
- Spec Sheet URL - 11112_K3WUH8G74ST09ZCP.pdf(Spec Sheet URL)
- Spec Sheet URL - DTGA72S.pdf(Spec Sheet URL)
- Tech Drawing URL - Acme_DTGA72S_TECHNICAL_DRAWINGS.dwg(Tech Drawing URL)
- Tech Drawing URL - DTGA-7-2S.pdf(Tech Drawing URL)
- www.hubbell-acmeelectric.com(Seller Home Page URL)
- Applications
- Features
Drive Isolation |
Encapsulated and ventilated designs, all ventilated units, are of strip wound construction |
Acme reinforced core assemblies enhance quiet operation |
Nominally 6% impedance |
Full capacity taps are featured on all units |
Full range of kVA ratings cover all standard drive systems |
Ample wiring compartment for easy cable entry |
Aluminum foil windings |
Copper wire terminations |
Wound/distributed core construction |
Copper terminations for trouble free operation |
Wound core and strip winding for low losses |
Electrostatic shield for enhanced protection |
5% taps steps |
