Acme Electric
ACME CE250B002 ICT .250KVA 120X240-24
Acme Electric
ACME CE250B002 ICT .250KVA 120X240-24
SKU1078766
MFGR #CE250B002
Your Cost: $95.09/ea
Industrial Control Transformer .250 kVA, 120 X 240 Primary Volts - 24 Secondary Volts
Industrial Control Transformer .250 kVA, 120 X 240 Primary Volts - 24 Secondary Volts
Application Open Core & Coil ARRA Compliant C Buy American Compliant C Catalog Number CE250B002 Connection Type Integrally Molded Terminal Block Country of Origin US Currency USD Dimensions 4 in L x 4-1/2 in W x 4 in H Enclosure Type Open EU RoHS Indicator Y Gross Weight Per Pack 11.0000 lb Gross Weight per Pack Metric 4.99 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8504314065 Height 4.00 in Height [Metric] 10.1600 cm Insulation Class 130C KVA Rating .25 Length 4.00 in Length [Metric] 10.1600 cm Maximum Amperage Rating 1 to 2.1 A Input, 10.416 A Output Maximum Input Current 2.1,1 Maximum Output Current 10.4166666666667 Mounting Panel Mounting Type Panel Number Of Phases 1 Returnable N Series CE Series Standard UL, CSA, CE Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCE EN61558-2-2CSA C22.2 No. 66.1CSA C22.2 No. 66.2UL 5085-1UL 5085-2cUL Listed Sub Brand Industrial Control Temperature Rating 80 °C Type Encapsulated Open Core and Coil UNSPSC 39121026 UPC 11 04750300563 UPC 12 047503005637 Wattage 250 W Width 4.50 in Width [Metric] 11.4300 cm Wiring Configuration 2 Stock Status NONSTOCK Brand Acme Electric Manufacturer Acme Electric Frequency Rating 50/60 Hz Phase 1 Power Rating 0.25 kVA Primary Voltage 120 x 240 VAC Secondary Voltage 24 VAC Open Core & Coil 1 phase Epoxy encapsulated design protects core and coil assembly from potentially damaging contaminants Integrally molded terminal blocks with isolation barriers to prevent arc over, terminal blocks allow full access for ring terminals for easy installation and solid termination Heavy gauge steel mounting feet Dual labeling for easy product identification when equipped with a fuse block 1/2.1 A input, 10.416 A output
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Open Core & Coil |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | CE250B002 |
| Connection Type | Integrally Molded Terminal Block |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 4 in L x 4-1/2 in W x 4 in H |
| Enclosure Type | Open |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 11.0000 lb |
| Gross Weight per Pack Metric | 4.99 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8504314065 |
| Height | 4.00 in |
| Height [Metric] | 10.1600 cm |
| Insulation Class | 130C |
| KVA Rating | .25 |
| Length | 4.00 in |
| Length [Metric] | 10.1600 cm |
| Maximum Amperage Rating | 1 to 2.1 A Input, 10.416 A Output |
| Maximum Input Current | 2.1,1 |
| Maximum Output Current | 10.4166666666667 |
| Mounting | Panel |
| Mounting Type | Panel |
| Number Of Phases | 1 |
| Returnable | N |
| Series | CE Series |
| Standard | UL, CSA, CE |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCE EN61558-2-2CSA C22.2 No. 66.1CSA C22.2 No. 66.2UL 5085-1UL 5085-2cUL Listed |
| Sub Brand | Industrial Control |
| Temperature Rating | 80 °C |
| Type | Encapsulated Open Core and Coil |
| UNSPSC | 39121026 |
| UPC 11 | 04750300563 |
| UPC 12 | 047503005637 |
| Wattage | 250 W |
| Width | 4.50 in |
| Width [Metric] | 11.4300 cm |
| Wiring Configuration | 2 |
| Stock Status | NONSTOCK |
| Brand | Acme Electric |
| Manufacturer | Acme Electric |
| Frequency Rating | 50/60 Hz |
| Phase | 1 |
| Power Rating | 0.25 kVA |
| Primary Voltage | 120 x 240 VAC |
| Secondary Voltage | 24 VAC |
| Open Core & Coil |
| 1 phase |
| Epoxy encapsulated design protects core and coil assembly from potentially damaging contaminants |
| Integrally molded terminal blocks with isolation barriers to prevent arc over, terminal blocks allow full access for ring terminals for easy installation and solid termination |
| Heavy gauge steel mounting feet |
| Dual labeling for easy product identification when equipped with a fuse block |
| 1/2.1 A input, 10.416 A output |
