Square D™ QO130HID Type QO-HID Miniature Circuit Breaker, 120/240 VAC/48 VDC, 30 A, 1 Pole, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ QO130HID Type QO-HID Miniature Circuit Breaker, 120/240 VAC/48 VDC, 30 A, 1 Pole, Thermal Magnetic Trip
SKU98797
MFGR #QO130HID
Your Cost: $35.62/ea
List: Square D QO130HID MINIATURE CIRCUIT BREAKER 120/240V 30A,1-Phase,10kA,120/240 Vac,1P,30A,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,High Intensity Discharge Plug-On,Miniature Circuit Breaker,Pressure Plate #14 to #8 AWG(Al/Cu),Provides overload and short circuit protection Designed for use on circuits feeding fluorescent and other high intensity discharge lighting systems.,QO,UL Listed - CSA Certified
Square D QO130HID MINIATURE CIRCUIT BREAKER 120/240V 30A,1-Phase,10kA,120/240 Vac,1P,30A,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,High Intensity Discharge Plug-On,Miniature Circuit Breaker,Pressure Plate #14 to #8 AWG(Al/Cu),Provides overload and short circuit protection Designed for use on circuits feeding fluorescent and other high intensity discharge lighting systems.,QO,UL Listed - CSA Certified
ARRA Compliant N Buy American Compliant N Catalog Number QO130HID Connection Type Pressure Plate Country of Origin MX Dimensions 2.91 in L x 0.75 in W x 3.12 in H EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 0.2700 lb Harmonization Tariff Schedule Code 8536200020 Item Group 00080 Material Fiberglass Filled Thermoset Mounting Type Plug-In Number Of Poles 1 Phase 1 Returnable Y Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Temperature Rating 104 °F Type Type QO UNSPSC 39121603 UPC 11 78590154373 UPC 12 785901543732 Wire Size 14 to 8 AWG Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 30 A Interrupt Rating 10 kA Trip Type Thermal Magnetic Voltage Rating 120/240 VAC HIGH INTENSITY DISCHARGE PLUG-ON Designed for superior safety, quality and reliability Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection Saves space compact 3/4 in W design for small system footprint Faster installation fewer connections Frees gutter space no pigtails with the innovative plug-on neutral design Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button High intensity discharge rated
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QO130HID |
| Connection Type | Pressure Plate |
| Country of Origin | MX |
| Dimensions | 2.91 in L x 0.75 in W x 3.12 in H |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.2700 lb |
| Harmonization Tariff Schedule Code | 8536200020 |
| Item Group | 00080 |
| Material | Fiberglass Filled Thermoset |
| Mounting Type | Plug-In |
| Number Of Poles | 1 |
| Phase | 1 |
| Returnable | Y |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Temperature Rating | 104 °F |
| Type | Type QO |
| UNSPSC | 39121603 |
| UPC 11 | 78590154373 |
| UPC 12 | 785901543732 |
| Wire Size | 14 to 8 AWG |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 30 A |
| Interrupt Rating | 10 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 120/240 VAC |
| HIGH INTENSITY DISCHARGE PLUG-ON |
| Designed for superior safety, quality and reliability |
| Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners |
| First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection |
| Saves space compact 3/4 in W design for small system footprint |
| Faster installation fewer connections |
| Frees gutter space no pigtails with the innovative plug-on neutral design |
| Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button |
| High intensity discharge rated |
