Schneider Electric TeSys™ LC2D25F7 Standard IEC Contactor With Protective Cover, 110 VAC Coil, 25 A Max Load, 3NO
Custom_Product_Images_Illustration
Schneider Electric TeSys™ LC2D25F7 Standard IEC Contactor With Protective Cover, 110 VAC Coil, 25 A Max Load, 3NO
SKU61618
MFGR #LC2D25F7
Call For Price
List: Schneider Electric LC2D25F7 REVERSING CONTACTOR 575VAC 25A IEC,110 V AC 50/60 Hz,3 NO,3P,40 A at <= 60 deg.C for power circuit-10 A at <= 60 deg.C for signalling circuit,mechanical,LC2D,motor control-resistive load,LC2D,reversing contactor,Screw Clamp,TeSys,TeSys D,UL Listed (E164862 / NLDX) - CSA Certified (LR43364 3211 04) - IEC Rated (60647-4) - CE Marked - RoHS Compliant,rail-plate
Schneider Electric LC2D25F7 REVERSING CONTACTOR 575VAC 25A IEC,110 V AC 50/60 Hz,3 NO,3P,40 A at <= 60 deg.C for power circuit-10 A at <= 60 deg.C for signalling circuit,mechanical,LC2D,motor control-resistive load,LC2D,reversing contactor,Screw Clamp,TeSys,TeSys D,UL Listed (E164862 / NLDX) - CSA Certified (LR43364 3211 04) - IEC Rated (60647-4) - CE Marked - RoHS Compliant,rail-plate
Alternate Catalog Number LC2D25F7 Application Resistive load;motor control ARRA Compliant N Brand Schneider Electric Buy American Compliant N Catalog Number LC2D25F7 Coil Power Rating 70 VA Inrush/7/7.5 VA Hold-In Coil Voltage 110 VAC Connection Type Screw Clamp Contact Configuration 3NO Contact Rating 25 A at 575 VAC Contact Type Reversing Country of Origin ID Currency USD Dimensions 82-1/2 mm H x 90 mm W x 86 mm D Enclosure Type IP2X EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Volume Per Pack 113.85 Gross Volume per Pack Metric 1865.66 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 9.4000 lb Gross Weight per Pack Metric 940.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536490065 Height 14.0000 in Height [Metric] 14.0000 cm Item Group 22354 Length 11.4000 in Length [Metric] 11.4000 cm Manufacturer Schneider Electric Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=1474965&lang=en-us Maximum Load Current 40 A Mounting RAIL-PLATE Mounting Type Surface Number of Auxiliary Contacts 1NO-1NC Number Of Poles 3 Operating Cycles 15000000 Operating Temperature -5 to 60 Returnable Y Series D-Line LC2D Size 85 MM,90 MM,92 MM Standard 850 A°C IEC 60695-2-1,CSA C22.2 NO 14-EN 60947-4-1-EN 60947-5-1-IEC 60947-4-1-IEC 60947-5-1-UL 508,DNV-BV-RINA-GOST-CSA-LROS (LLOYDS REGISTER OF SHIPPING)-UL-GL-CCC,IP20 FRONT FACE IEC 60529,V1 UL 94 Stock Status NONSTOCK Sub Brand TESYS D Substitute Product Catalog Number LAD6K10F Terminal Type Screw/Clamp Type Standard UNSPSC 39121529 Warranty Description Contractual Warranty:18 months Wattage 11 kW Width 11.4000 in Width [Metric] 11.4000 cm Resistive load;motor control 3 HP 230/240 V AC 60 HZ 1 PHASE-5 HP 200/208 V AC 60 HZ 3 PHASE-2 HP 115 V AC 60 HZ 1 PHASE-7.5 HP 230/240 V AC 60 HZ 3 PHASE-15 HP 460/480 V AC 60 HZ 3 PHASE-20 HP 575/600 V AC 60 HZ 3 PHASE,WITHOUT BUILT-IN SUPPRESSOR MODULE 40 A at 140 deg F power circuit, 10 A at 140 deg F signaling circuit conventional-free air thermal current
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | LC2D25F7 |
| Application | Resistive load;motor control |
| ARRA Compliant | N |
| Brand | Schneider Electric |
| Buy American Compliant | N |
| Catalog Number | LC2D25F7 |
| Coil Power Rating | 70 VA Inrush/7/7.5 VA Hold-In |
| Coil Voltage | 110 VAC |
| Connection Type | Screw Clamp |
| Contact Configuration | 3NO |
| Contact Rating | 25 A at 575 VAC |
| Contact Type | Reversing |
| Country of Origin | ID |
| Currency | USD |
| Dimensions | 82-1/2 mm H x 90 mm W x 86 mm D |
| Enclosure Type | IP2X |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 113.85 |
| Gross Volume per Pack Metric | 1865.66 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 9.4000 lb |
| Gross Weight per Pack Metric | 940.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536490065 |
| Height | 14.0000 in |
| Height [Metric] | 14.0000 cm |
| Item Group | 22354 |
| Length | 11.4000 in |
| Length [Metric] | 11.4000 cm |
| Manufacturer | Schneider Electric |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=1474965&lang=en-us |
| Maximum Load Current | 40 A |
| Mounting | RAIL-PLATE |
| Mounting Type | Surface |
| Number of Auxiliary Contacts | 1NO-1NC |
| Number Of Poles | 3 |
| Operating Cycles | 15000000 |
| Operating Temperature | -5 to 60 |
| Returnable | Y |
| Series | D-Line LC2D |
| Size | 85 MM,90 MM,92 MM |
| Standard | 850 A°C IEC 60695-2-1,CSA C22.2 NO 14-EN 60947-4-1-EN 60947-5-1-IEC 60947-4-1-IEC 60947-5-1-UL 508,DNV-BV-RINA-GOST-CSA-LROS (LLOYDS REGISTER OF SHIPPING)-UL-GL-CCC,IP20 FRONT FACE IEC 60529,V1 UL 94 |
| Stock Status | NONSTOCK |
| Sub Brand | TESYS D |
| Substitute Product Catalog Number | LAD6K10F |
| Terminal Type | Screw/Clamp |
| Type | Standard |
| UNSPSC | 39121529 |
| Warranty Description | Contractual Warranty:18 months |
| Wattage | 11 kW |
| Width | 11.4000 in |
| Width [Metric] | 11.4000 cm |
| Resistive load;motor control |
| 3 HP 230/240 V AC 60 HZ 1 PHASE-5 HP 200/208 V AC 60 HZ 3 PHASE-2 HP 115 V AC 60 HZ 1 PHASE-7.5 HP 230/240 V AC 60 HZ 3 PHASE-15 HP 460/480 V AC 60 HZ 3 PHASE-20 HP 575/600 V AC 60 HZ 3 PHASE,WITHOUT BUILT-IN SUPPRESSOR MODULE |
| 40 A at 140 deg F power circuit, 10 A at 140 deg F signaling circuit conventional-free air thermal current |
