SKU259549
MFGR #DAH2002A
Your Cost: $606.32/ea
nVent HOFFMAN Electric Heater, Series: D85, 200 W, 230 VAC, 0.95 A, 0 to 100 deg F, 4 in Overall Width, 5-1/2 in Overall Height, Panel Mount, Aluminum, Brushed Aluminum, Domestic
nVent HOFFMAN Electric Heater, Series: D85, 200 W, 230 VAC, 0.95 A, 0 to 100 deg F, 4 in Overall Width, 5-1/2 in Overall Height, Panel Mount, Aluminum, Brushed Aluminum, Domestic
Amperage Rating 0.95 A Application Controls and Drives; Power Distribution ARRA Compliant C Buy American Compliant C Catalog Number DAH2002A Color Unpainted Country of Origin US Currency USD Current 0.95 A EU RoHS Indicator RCP Finish Brushed Frequency Rating 50/60 Hz Gross Volume Per Pack 0.20 Gross Volume UOM FC Gross Weight Per Pack 2.0000 lb Gross Weight per Pack Metric 0.91 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8516290090 Height 6.3000 in Height [Metric] 16.0020 cm Housing Material Aluminum Item Group D85 Length 6.2000 in Length [Metric] 22.0980 cm Material Aluminum Nominal Watts 200 W Package Quantity 1 Returnable Y Standards CE Certified, LR42186 CSA Certified, RoHS Complaint, UL E61997, 508A Listed Thickness 0.06 V Thickness [Metric] 1.5 mm Type Heaters UNSPSC 40101811 UPC 11 78351070560 UPC 12 783510705602 Voltage AC 200 - 250 VAC Voltage Rating 200 - 250 VAC Weight [Metric] 0.73 kg Width 8.7000 in Width [Metric] 15.7480 cm Stock Status NONSTOCK Brand nVent HOFFMAN Manufacturer HOFFMAN ENCLOSURES Controls and Drives; Power Distribution Aluminum housing, Thermostat range adjustable from 0 F to 100 F (-18 C to 38 C), Four 10-32 x self-tapping screws are included with each heater, Ball bearing fan, Terminal strip with clamp connector that accepts both solid and stranded wire Thermostat range adjustable from 0 to 100 deg F (-18 to 38 deg C) Ball bearing fan Terminal strip with clamp connector that accepts both solid and stranded wire Fan draws cool air from the bottom of the enclosure and passes this air across the thermostat and heating element before being released into enclosure cavity Heated air is discharged through the top of the heater unit
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Amperage Rating | 0.95 A |
| Application | Controls and Drives; Power Distribution |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | DAH2002A |
| Color | Unpainted |
| Country of Origin | US |
| Currency | USD |
| Current | 0.95 A |
| EU RoHS Indicator | RCP |
| Finish | Brushed |
| Frequency Rating | 50/60 Hz |
| Gross Volume Per Pack | 0.20 |
| Gross Volume UOM | FC |
| Gross Weight Per Pack | 2.0000 lb |
| Gross Weight per Pack Metric | 0.91 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8516290090 |
| Height | 6.3000 in |
| Height [Metric] | 16.0020 cm |
| Housing Material | Aluminum |
| Item Group | D85 |
| Length | 6.2000 in |
| Length [Metric] | 22.0980 cm |
| Material | Aluminum |
| Nominal Watts | 200 W |
| Package Quantity | 1 |
| Returnable | Y |
| Standards | CE Certified, LR42186 CSA Certified, RoHS Complaint, UL E61997, 508A Listed |
| Thickness | 0.06 V |
| Thickness [Metric] | 1.5 mm |
| Type | Heaters |
| UNSPSC | 40101811 |
| UPC 11 | 78351070560 |
| UPC 12 | 783510705602 |
| Voltage AC | 200 - 250 VAC |
| Voltage Rating | 200 - 250 VAC |
| Weight [Metric] | 0.73 kg |
| Width | 8.7000 in |
| Width [Metric] | 15.7480 cm |
| Stock Status | NONSTOCK |
| Brand | nVent HOFFMAN |
| Manufacturer | HOFFMAN ENCLOSURES |
| Controls and Drives; Power Distribution |
| Aluminum housing, Thermostat range adjustable from 0 F to 100 F (-18 C to 38 C), Four 10-32 x self-tapping screws are included with each heater, Ball bearing fan, Terminal strip with clamp connector that accepts both solid and stranded wire |
| Thermostat range adjustable from 0 to 100 deg F (-18 to 38 deg C) |
| Ball bearing fan |
| Terminal strip with clamp connector that accepts both solid and stranded wire |
| Fan draws cool air from the bottom of the enclosure and passes this air across the thermostat and heating element before being released into enclosure cavity |
| Heated air is discharged through the top of the heater unit |
