Square D™ ZD4PA103 RPLCMT JOYSTICK BODY/C
SKU307884
MFGR #ZD4PA103
Your Cost: $121.36/ea
Schneider Electric ZD4PA103 RPLCMT JOYSTICK BODY/CONTACT ASSY,-13...158 deg.F (-25...70 deg.C),Body and contact assembly,Harmony,UL, CSA, EN/IEC,for joystick controller,panel
Schneider Electric ZD4PA103 RPLCMT JOYSTICK BODY/CONTACT ASSY,-13...158 deg.F (-25...70 deg.C),Body and contact assembly,Harmony,UL, CSA, EN/IEC,for joystick controller,panel
Alternate Catalog Number ZD4PA103 Application FOR JOYSTICK CONTROLLER ARRA Compliant N Buy American Compliant N Catalog Number ZD4PA103 Country of Origin FR Currency USD EU RoHS Indicator Y Gross Volume Per Pack 4.64 Gross Volume per Pack Metric 76.04 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 0.1300 lb Gross Weight per Pack Metric 61.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8538908180 Height 5.3000 in Height [Metric] 5.3000 cm Item Group 22469 Length 8.7000 in Length [Metric] 8.7000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=650100&lang=en-us Mounting Panel Operating Temperature -25-70 A°C Returnable N Standards EN/IEC 60947-1, 60947-5-1, 60947-5-4, JIS C 4520, 852, UL 508, CSA C22.2 No. 14 Sub Brand ZD4 Substitute Product Catalog Number ZD4PA12 Type 2 NO,COMPLETE BODY/CONTACT ASSEMBLY FOR JOYSTICK CONTROLLER,SLOW-BREAK UNSPSC 39122221 UPC 11 78590155847 UPC 12 785901558477 Warranty Description Contractual Warranty:18 months Width 3.4000 in Width [Metric] 3.4000 cm Stock Status NONSTOCK Brand Schneider Electric Manufacturer Schneider Electric FOR JOYSTICK CONTROLLER 10 A CARTRIDGE FUSE GG EN/IEC 60947-5-1 Slow break contact operation Standard contact operation =1 x 0.22 sq-mm without cable end screw clamp conforming to EN 60947-1 Without positive opening 10000000 cycles mechanical durability 0.8 to 1.2 N-m tightening torque Cross head compatible with Philips, Pozidriv #1 screwdriver, slotted head compatible with flat 4 mm/5.5 mm Dia screwdriver 10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1 short circuit protection 10 A conforming to EN/IEC 60947-5-1 conventional free air thermal current 600 VAC (degree of pollution 3) conforming to EN 60947-1 rated insulation voltage 6 kV conforming to EN 60947-1 rated impulse withstand voltage 3 A 240 VAC-15 A300 EN/IEC 60947-5-1, 6 A 120 VAC-15 A300 EN/IEC 60947-5-1, 0.1 A 600 VDC-13 Q300 EN/IEC 60947-5-1, 0.27 A 250 VDC-13 Q300 EN/IEC 60947-5-1, 0.55 A 125 VDC-13 Q300 EN/IEC 60947-5-1 rated operational current -40 to 70 deg C ambient air temperature for storage -40 to 70 deg C ambient air temperature for operation 5 gn (2 to 500 Hz) vibration resistance conforming to IEC 60068-2-6 30 gn (18 ms)/50 gn (11 ms) shock resistance, half sine wave acceleration IEC 60068-2-27
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | ZD4PA103 |
| Application | FOR JOYSTICK CONTROLLER |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | ZD4PA103 |
| Country of Origin | FR |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 4.64 |
| Gross Volume per Pack Metric | 76.04 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 0.1300 lb |
| Gross Weight per Pack Metric | 61.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8538908180 |
| Height | 5.3000 in |
| Height [Metric] | 5.3000 cm |
| Item Group | 22469 |
| Length | 8.7000 in |
| Length [Metric] | 8.7000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=650100&lang=en-us |
| Mounting | Panel |
| Operating Temperature | -25-70 A°C |
| Returnable | N |
| Standards | EN/IEC 60947-1, 60947-5-1, 60947-5-4, JIS C 4520, 852, UL 508, CSA C22.2 No. 14 |
| Sub Brand | ZD4 |
| Substitute Product Catalog Number | ZD4PA12 |
| Type | 2 NO,COMPLETE BODY/CONTACT ASSEMBLY FOR JOYSTICK CONTROLLER,SLOW-BREAK |
| UNSPSC | 39122221 |
| UPC 11 | 78590155847 |
| UPC 12 | 785901558477 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 3.4000 in |
| Width [Metric] | 3.4000 cm |
| Stock Status | NONSTOCK |
| Brand | Schneider Electric |
| Manufacturer | Schneider Electric |
| FOR JOYSTICK CONTROLLER |
| 10 A CARTRIDGE FUSE GG EN/IEC 60947-5-1 |
| Slow break contact operation |
| Standard contact operation |
| =1 x 0.22 sq-mm without cable end screw clamp conforming to EN 60947-1 |
| Without positive opening |
| 10000000 cycles mechanical durability |
| 0.8 to 1.2 N-m tightening torque |
| Cross head compatible with Philips, Pozidriv #1 screwdriver, slotted head compatible with flat 4 mm/5.5 mm Dia screwdriver |
| 10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1 short circuit protection |
| 10 A conforming to EN/IEC 60947-5-1 conventional free air thermal current |
| 600 VAC (degree of pollution 3) conforming to EN 60947-1 rated insulation voltage |
| 6 kV conforming to EN 60947-1 rated impulse withstand voltage |
| 3 A 240 VAC-15 A300 EN/IEC 60947-5-1, 6 A 120 VAC-15 A300 EN/IEC 60947-5-1, 0.1 A 600 VDC-13 Q300 EN/IEC 60947-5-1, 0.27 A 250 VDC-13 Q300 EN/IEC 60947-5-1, 0.55 A 125 VDC-13 Q300 EN/IEC 60947-5-1 rated operational current |
| -40 to 70 deg C ambient air temperature for storage |
| -40 to 70 deg C ambient air temperature for operation |
| 5 gn (2 to 500 Hz) vibration resistance conforming to IEC 60068-2-6 |
| 30 gn (18 ms)/50 gn (11 ms) shock resistance, half sine wave acceleration IEC 60068-2-27 |
