Killark
Killark® FXB-5 FXB Feed-Thru/Factory Sealed Splice Box, Aluminum, 1 Gangs
Custom_Product_Images_Illustration
Killark
Killark® FXB-5 FXB Feed-Thru/Factory Sealed Splice Box, Aluminum, 1 Gangs
SKU262571
MFGR #FXB-5
Your Cost: $162.27/ea
Killark® Splice Box, Feed-Thru/Factory Sealed, Series: FXB, 1 Gangs, 3/4 in Hub, NEMA 3/7/9, Aluminum, 6-13/16 in L x 3-11/16 in W x 1-3/4 in D
Killark® Splice Box, Feed-Thru/Factory Sealed, Series: FXB, 1 Gangs, 3/4 in Hub, NEMA 3/7/9, Aluminum, 6-13/16 in L x 3-11/16 in W x 1-3/4 in D
Application The FXB Series of splice boxes are designed for use with the FXCS and FXS Series of cover sub-assemblies ARRA Compliant C Buy American Compliant C Catalog Number FXB-5 Color Gray Country of Origin CN Currency USD Enclosure Type NEMA 3/7/9 Environmental Conditions Hazardous locations EU RoHS Indicator C Gross Volume Per Pack 159.52 Gross Volume per Pack Metric 2614.07 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 1.6400 lb Gross Weight per Pack Metric 0.74 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 7616995190 Height 4.12 in Height [Metric] 10.4775 cm Hub Size 3/4 in Length 9.38 in Length [Metric] 23.8125 cm Mounting Wall Mounting Type Wall Returnable Y Size 9.375 in x 4.125 in x 4.125 in Standard UL, CSA Standards ARRA CompliantBuy American Act CompliantRoHS CompliantClass I, Div 1 and 2, Groups C,D, Class I, Zones 1 and 2, Groups IIB, IIA, Class II, Div 1 and 2, Groups E, F, G, Class lll Div 1 and 2CSA LR11712CSA LR11714UL File No. E53360 Sub Brand SEAL-X Type Aluminum Factory Sealed Single Gang Feed-Thru Splice Box UNSPSC 39122216 UPC 11 78393620034 UPC 12 78393620034 Width 4.12 in Width [Metric] 10.4775 cm Stock Status NONSTOCK Brand Killark Manufacturer Hubbell Dimensions 6-13/16 in H x 3-11/16 in W x 1-3/4 in D Material Aluminum, Copper Free (less than 4/10 of 1%) Number of Gangs 1 The FXB Series of splice boxes are designed for use with the FXCS and FXS Series of cover sub-assemblies Killark SEAL-X Series FXB BACK BOXES provide control solutions in hazardous location areas to supply; START/STOP Motor Functions, LED Pilot Light Indications and more for use with Killark Factory Sealed FXCS and FXS Cover Assemblies. Utilized in Class 1 Division 1 & 2, Class 1 Zone 1 & 2 areas where Type 3, 7 & 9 protection ratings are required for indoor and outdoor use. UL Listed and CSA Certified. The FXB is offered in single and double gang configurations from ½” to 1” dead end and feed through. Device bodies are cast copper-free aluminum alloy The FXB series of splice boxes are designed for use with the FXCS and FXS series of cover sub-assemblies 6-3/16 in vertical, 2-1/4 in horizontal mounting
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | The FXB Series of splice boxes are designed for use with the FXCS and FXS Series of cover sub-assemblies |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | FXB-5 |
| Color | Gray |
| Country of Origin | CN |
| Currency | USD |
| Enclosure Type | NEMA 3/7/9 |
| Environmental Conditions | Hazardous locations |
| EU RoHS Indicator | C |
| Gross Volume Per Pack | 159.52 |
| Gross Volume per Pack Metric | 2614.07 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 1.6400 lb |
| Gross Weight per Pack Metric | 0.74 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 7616995190 |
| Height | 4.12 in |
| Height [Metric] | 10.4775 cm |
| Hub Size | 3/4 in |
| Length | 9.38 in |
| Length [Metric] | 23.8125 cm |
| Mounting | Wall |
| Mounting Type | Wall |
| Returnable | Y |
| Size | 9.375 in x 4.125 in x 4.125 in |
| Standard | UL, CSA |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantClass I, Div 1 and 2, Groups C,D, Class I, Zones 1 and 2, Groups IIB, IIA, Class II, Div 1 and 2, Groups E, F, G, Class lll Div 1 and 2CSA LR11712CSA LR11714UL File No. E53360 |
| Sub Brand | SEAL-X |
| Type | Aluminum Factory Sealed Single Gang Feed-Thru Splice Box |
| UNSPSC | 39122216 |
| UPC 11 | 78393620034 |
| UPC 12 | 78393620034 |
| Width | 4.12 in |
| Width [Metric] | 10.4775 cm |
| Stock Status | NONSTOCK |
| Brand | Killark |
| Manufacturer | Hubbell |
| Dimensions | 6-13/16 in H x 3-11/16 in W x 1-3/4 in D |
| Material | Aluminum, Copper Free (less than 4/10 of 1%) |
| Number of Gangs | 1 |
| The FXB Series of splice boxes are designed for use with the FXCS and FXS Series of cover sub-assemblies |
| Killark SEAL-X Series FXB BACK BOXES provide control solutions in hazardous location areas to supply; START/STOP Motor Functions, LED Pilot Light Indications and more for use with Killark Factory Sealed FXCS and FXS Cover Assemblies. Utilized in Class 1 Division 1 & 2, Class 1 Zone 1 & 2 areas where Type 3, 7 & 9 protection ratings are required for indoor and outdoor use. UL Listed and CSA Certified. The FXB is offered in single and double gang configurations from ½” to 1” dead end and feed through. |
| Device bodies are cast copper-free aluminum alloy |
| The FXB series of splice boxes are designed for use with the FXCS and FXS series of cover sub-assemblies |
| 6-3/16 in vertical, 2-1/4 in horizontal mounting |
