Carlon®
Carlon® C2016A4 Single Door JIC Enclosure Assembly, 20 in L x 16 in W x 7-1/2 in D, NEMA 12/4X, Noryl
Custom_Product_Images_Illustration
Carlon®
Carlon® C2016A4 Single Door JIC Enclosure Assembly, 20 in L x 16 in W x 7-1/2 in D, NEMA 12/4X, Noryl
SKU507917
MFGR #C2016A4
Your Cost: $932.14/ea
Manufactured from structural foam thermoplastic, Carlon® Circuit Safe® JIC enclosures provide high impact strength to eliminate dents and deformations along with high dielectric
Manufactured from structural foam thermoplastic, Carlon® Circuit Safe® JIC enclosures provide high impact strength to eliminate dents and deformations along with high dielectric
Alternate Catalog Number 7TAA238230R0000 Application Instrument case ARRA Compliant C Buy American Compliant C Catalog Number C2016A4 Country of Origin US Currency USD EU RoHS Indicator C Gross Weight Per Pack 16.8800 lb Gross Weight per Pack Metric 7.66 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 3926909989 Height [Metric] 0.0254 cm Item Group 5Y Item Group 2 5YE Length [Metric] 0.0254 cm Returnable C Standards UL E108856, CSA Certified, RoHS Complaint Type Circuit Safe JIC Enclosures UNSPSC 39121324 UPC 11 03448103276 UPC 12 034481032762 Width [Metric] 0.0254 cm Stock Status NONSTOCK Brand Carlon® Manufacturer Thomas & Betts Height 0.01 in Length 0.01 in Material Noryl Width 0.01 in Instrument case Non-metallic mounting feet with all mounting hardware included. Non-metallic mounting feet and all mounting hardware included White painted 14 gauge steel or 1/4 in PVC back panel (order separately) 304 (18-8) stainless steel screw (10-32 x 1-1/8 in) Completely nonmetallic hinges Brass screw inserts NORYL base and cover Lid design provides greater usable internal volume Opaque cover
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | 7TAA238230R0000 |
| Application | Instrument case |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | C2016A4 |
| Country of Origin | US |
| Currency | USD |
| EU RoHS Indicator | C |
| Gross Weight Per Pack | 16.8800 lb |
| Gross Weight per Pack Metric | 7.66 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 3926909989 |
| Height [Metric] | 0.0254 cm |
| Item Group | 5Y |
| Item Group 2 | 5YE |
| Length [Metric] | 0.0254 cm |
| Returnable | C |
| Standards | UL E108856, CSA Certified, RoHS Complaint |
| Type | Circuit Safe JIC Enclosures |
| UNSPSC | 39121324 |
| UPC 11 | 03448103276 |
| UPC 12 | 034481032762 |
| Width [Metric] | 0.0254 cm |
| Stock Status | NONSTOCK |
| Brand | Carlon® |
| Manufacturer | Thomas & Betts |
| Height | 0.01 in |
| Length | 0.01 in |
| Material | Noryl |
| Width | 0.01 in |
| Instrument case |
| Non-metallic mounting feet with all mounting hardware included. |
| Non-metallic mounting feet and all mounting hardware included |
| White painted 14 gauge steel or 1/4 in PVC back panel (order separately) |
| 304 (18-8) stainless steel screw (10-32 x 1-1/8 in) |
| Completely nonmetallic hinges |
| Brass screw inserts |
| NORYL base and cover |
| Lid design provides greater usable internal volume |
| Opaque cover |
