nVent HOFFMAN ULTRX™ UU756030 UX1 Solid Door Enclosure, 30.51 in L x 24.09 in W x 12.64 in D, NEMA 4X/IP66 NEMA Rating, Fiberglass
Custom_Product_Images_Illustration
nVent HOFFMAN ULTRX™ UU756030 UX1 Solid Door Enclosure, 30.51 in L x 24.09 in W x 12.64 in D, NEMA 4X/IP66 NEMA Rating, Fiberglass
SKU25035
MFGR #UU756030
Your Cost: $1,849.00/ea
nVent HOFFMAN ULTRX™ Enclosure, Solid Door, Series: UX1, 30.51 in Length, 24.09 in Width, 12.64 in Depth, NEMA 4X/IP66, Concealed Hinged Cover, 27.01 x 20.98 in Panel, Lock: Padlock Latch, 8837 cu-in Capacity, Wall Mount, Fiberglass, Acrylic Enamel Coated, Light Gray
nVent HOFFMAN ULTRX™ Enclosure, Solid Door, Series: UX1, 30.51 in Length, 24.09 in Width, 12.64 in Depth, NEMA 4X/IP66, Concealed Hinged Cover, 27.01 x 20.98 in Panel, Lock: Padlock Latch, 8837 cu-in Capacity, Wall Mount, Fiberglass, Acrylic Enamel Coated, Light Gray
Application Controls and Drives; Corrosive Environments ARRA Compliant C Assemble to Order No Brand nVent HOFFMAN Buy American Compliant C Catalog Number UU756030 Color Light Gray Color Code RAL 7035 Conductive Panel A30P24G Country of Origin US Cubic Capacity 8837 cubic in in3 Currency USD Depth 12.95 Door Type Solid EU RoHS Indicator RCP External Dimensions 30.51 x 24.09 in External Dimensions [Metric] 775 x 612 mm Finish Smooth Matte Gross Volume Per Pack 8.03 Gross Volume UOM FC Gross Weight Per Pack 43.7000 lb Gross Weight per Pack Metric 19.82 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 3926909989 Height 15.2500 in Height [Metric] 38.7350 cm Interchangeable No Internal Dimensions 29.84 x 23.43 x 12.64 in Internal Dimensions [Metric] 758 x 595 x 321 mm IP Rating IP66 Item Group UX1 Length 26.0000 in Length [Metric] 88.9000 cm Manufacturer HOFFMAN ENCLOSURES Material Fiberglass Modification Services Yes Mounting [Metric] 555 x 718 mm NEMA Rating 4X Watertight, corrosion-resistant Package Quantity 1 Panel Size 27.01 x 20.98 in Panel Size [Metric] 686 x 533 mm Panel Type A30P24 Product Family Ultrx Returnable Y Shipping Weight 45 lb Size 30.51 x 24.09 in Stock Status NONSTOCK Sub Brand Ultrx Thickness 0.15 in Thickness [Metric] 3.8 mm Type Fiberglass and Thermoplastic Wall Mounted Industrial Enclosures UNSPSC 39121324 UPC 11 78351033700 UPC 12 783510337001 Width 35.0000 in Width [Metric] 66.0400 cm Controls and Drives; Corrosive Environments Compression-molded fiberglass material has excellent temperature and chemical resistance qualities and exhibits outstanding physical properties, including high-impact resistance, Fiberglass is easily punched, drilled, filed or sawed, Seamless foam-i Fiberglass is easily punched, drilled, filed or sawed Gasket assures watertight and dusttight seal Enclosure may be rotated 180 deg for left and right hinging Molded in drip shields are standard with each enclosure Impact-resistant polycarbonate window is permanently bonded in place Fiberglass mounting brackets and stainless steel attachment screws are provided with each enclosure Unique hinge design allows for standard 180 deg door opening with a maximum opening of 270 deg Door hinges are replaceable Molded in DIN bosses Molded bosses on door provide additional mounting provisions Integral mounting rails provide infinite panel adjustment front to back Material is halogen-free Material is halogen free Optional data pocket is high-impact thermoplastic Material is halogen free Providing outstanding protection against corrosion and the elements, the clean lines and molded, embossed design of ULTRX fiberglass enclosures make them the most stylish and aesthetically pleasing of their class These enclosures feature hidden hinges, a padlocking capability for security, and flexible internal mounting options Enclosure flammability evaluated per UL 508 Solid door
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Controls and Drives; Corrosive Environments |
| ARRA Compliant | C |
| Assemble to Order | No |
| Brand | nVent HOFFMAN |
| Buy American Compliant | C |
| Catalog Number | UU756030 |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Conductive Panel | A30P24G |
| Country of Origin | US |
| Cubic Capacity | 8837 cubic in in3 |
| Currency | USD |
| Depth | 12.95 |
| Door Type | Solid |
| EU RoHS Indicator | RCP |
| External Dimensions | 30.51 x 24.09 in |
| External Dimensions [Metric] | 775 x 612 mm |
| Finish | Smooth Matte |
| Gross Volume Per Pack | 8.03 |
| Gross Volume UOM | FC |
| Gross Weight Per Pack | 43.7000 lb |
| Gross Weight per Pack Metric | 19.82 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 3926909989 |
| Height | 15.2500 in |
| Height [Metric] | 38.7350 cm |
| Interchangeable | No |
| Internal Dimensions | 29.84 x 23.43 x 12.64 in |
| Internal Dimensions [Metric] | 758 x 595 x 321 mm |
| IP Rating | IP66 |
| Item Group | UX1 |
| Length | 26.0000 in |
| Length [Metric] | 88.9000 cm |
| Manufacturer | HOFFMAN ENCLOSURES |
| Material | Fiberglass |
| Modification Services | Yes |
| Mounting [Metric] | 555 x 718 mm |
| NEMA Rating | 4X Watertight, corrosion-resistant |
| Package Quantity | 1 |
| Panel Size | 27.01 x 20.98 in |
| Panel Size [Metric] | 686 x 533 mm |
| Panel Type | A30P24 |
| Product Family | Ultrx |
| Returnable | Y |
| Shipping Weight | 45 lb |
| Size | 30.51 x 24.09 in |
| Stock Status | NONSTOCK |
| Sub Brand | Ultrx |
| Thickness | 0.15 in |
| Thickness [Metric] | 3.8 mm |
| Type | Fiberglass and Thermoplastic Wall Mounted Industrial Enclosures |
| UNSPSC | 39121324 |
| UPC 11 | 78351033700 |
| UPC 12 | 783510337001 |
| Width | 35.0000 in |
| Width [Metric] | 66.0400 cm |
| Controls and Drives; Corrosive Environments |
| Compression-molded fiberglass material has excellent temperature and chemical resistance qualities and exhibits outstanding physical properties, including high-impact resistance, Fiberglass is easily punched, drilled, filed or sawed, Seamless foam-i |
| Fiberglass is easily punched, drilled, filed or sawed |
| Gasket assures watertight and dusttight seal |
| Enclosure may be rotated 180 deg for left and right hinging |
| Molded in drip shields are standard with each enclosure |
| Impact-resistant polycarbonate window is permanently bonded in place |
| Fiberglass mounting brackets and stainless steel attachment screws are provided with each enclosure |
| Unique hinge design allows for standard 180 deg door opening with a maximum opening of 270 deg |
| Door hinges are replaceable |
| Molded in DIN bosses |
| Molded bosses on door provide additional mounting provisions |
| Integral mounting rails provide infinite panel adjustment front to back |
| Material is halogen-free |
| Material is halogen free |
| Optional data pocket is high-impact thermoplastic |
| Material is halogen free |
| Providing outstanding protection against corrosion and the elements, the clean lines and molded, embossed design of ULTRX fiberglass enclosures make them the most stylish and aesthetically pleasing of their class |
| These enclosures feature hidden hinges, a padlocking capability for security, and flexible internal mounting options |
| Enclosure flammability evaluated per UL 508 |
| Solid door |
