nVent HOFFMAN TFP424 D85 TFP Filter Fan, 24 VDC, 0.35 A, 8.4 W Power Rating, 55 cfm Air Flow, NEMA 1 Enclosure
Custom_Product_Images_Illustration
nVent HOFFMAN TFP424 D85 TFP Filter Fan, 24 VDC, 0.35 A, 8.4 W Power Rating, 55 cfm Air Flow, NEMA 1 Enclosure
SKU453656
MFGR #TFP424
Your Cost: $384.39/ea
nVent HOFFMAN Filter Fan, TFP, Series: D85, 24 VDC, 0.35 A, 8.4 W, 65 dBA, 55 cfm, Side Mount, Split Capacitor Motor, 4 in Grille, ABS Grille, NEMA 1, Polycarbonate Housing, 6.29 in H x 7.37 in W x 2.65 in D
nVent HOFFMAN Filter Fan, TFP, Series: D85, 24 VDC, 0.35 A, 8.4 W, 65 dBA, 55 cfm, Side Mount, Split Capacitor Motor, 4 in Grille, ABS Grille, NEMA 1, Polycarbonate Housing, 6.29 in H x 7.37 in W x 2.65 in D
Ambient Temperature 158 Deg F max Application Controls and Drives; Power Distribution ARRA Compliant C Buy American Compliant C Catalog Number TFP424 Color Light Gray Color Code RAL 7035 Country of Origin CN Currency USD EU RoHS Indicator RCP Finish Smooth Matte Flow Rate 55 CFM max Gross Volume Per Pack 0.16 Gross Volume UOM FC Gross Weight Per Pack 1.4000 lb Gross Weight per Pack Metric 0.64 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8414596590 Height 4.7000 in Height [Metric] 11.9380 cm Item Group D85 Length 7.8000 in Length [Metric] 19.8120 cm Material Composite Max CFM 55 CFM Max Current .35 A Max m3|hr 93 CMH Max Temperature 158 °F Package Quantity 1 Returnable Y Size 6 x 7 x 2 in Standards UL 508A, File No. E61997, CSA Certified, CE Certified, RoHS Complaint Type Fans and Filter Fans UNSPSC 40101604 UPC 11 78351017387 UPC 12 78351017387 Voltage AC 24 VDC Weight [Metric] 1.9 kg Width 7.7000 in Width [Metric] 19.5580 cm Stock Status NORMALLY STOCKED Brand nVent HOFFMAN Manufacturer HOFFMAN ENCLOSURES Amperage Rating .35 A Voltage Rating 24 VDC Controls and Drives; Power Distribution Cooling fan package includes fan, air filter, composite air plenum, finger guard and grille EMC upgrade kit includes a grille standoff collar and a special EMC shielding grille Reliable cooling for enclosures with limited space requiring simple filtered airflow for basic cooling Washable foam (Type 1) or disposable (Type 12) filter in fan Dynamically balanced fan impellers molded from polycarbonate material 4 in fan is thermally protected and uses permanently lubricated ball bearings Fans have lead wires for power connection with ends stripped 1/2 in (12 mm) All mounting hardware and installation instructions are furnished Engineered for 50000 hr of continuous operation without lubrication or service (a monthly maintenance schedule is recommended to ensure optimal cooling performance) ABS composite grille is black TFP side-mount fans provide reliable cooling for enclosures with limited space requiring simple filtered airflow for basic cooling
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Ambient Temperature | 158 Deg F max |
| Application | Controls and Drives; Power Distribution |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | TFP424 |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Country of Origin | CN |
| Currency | USD |
| EU RoHS Indicator | RCP |
| Finish | Smooth Matte |
| Flow Rate | 55 CFM max |
| Gross Volume Per Pack | 0.16 |
| Gross Volume UOM | FC |
| Gross Weight Per Pack | 1.4000 lb |
| Gross Weight per Pack Metric | 0.64 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8414596590 |
| Height | 4.7000 in |
| Height [Metric] | 11.9380 cm |
| Item Group | D85 |
| Length | 7.8000 in |
| Length [Metric] | 19.8120 cm |
| Material | Composite |
| Max CFM | 55 CFM |
| Max Current | .35 A |
| Max m3|hr | 93 CMH |
| Max Temperature | 158 °F |
| Package Quantity | 1 |
| Returnable | Y |
| Size | 6 x 7 x 2 in |
| Standards | UL 508A, File No. E61997, CSA Certified, CE Certified, RoHS Complaint |
| Type | Fans and Filter Fans |
| UNSPSC | 40101604 |
| UPC 11 | 78351017387 |
| UPC 12 | 78351017387 |
| Voltage AC | 24 VDC |
| Weight [Metric] | 1.9 kg |
| Width | 7.7000 in |
| Width [Metric] | 19.5580 cm |
| Stock Status | NORMALLY STOCKED |
| Brand | nVent HOFFMAN |
| Manufacturer | HOFFMAN ENCLOSURES |
| Amperage Rating | .35 A |
| Voltage Rating | 24 VDC |
| Controls and Drives; Power Distribution |
| Cooling fan package includes fan, air filter, composite air plenum, finger guard and grille |
| EMC upgrade kit includes a grille standoff collar and a special EMC shielding grille |
| Reliable cooling for enclosures with limited space requiring simple filtered airflow for basic cooling |
| Washable foam (Type 1) or disposable (Type 12) filter in fan |
| Dynamically balanced fan impellers molded from polycarbonate material |
| 4 in fan is thermally protected and uses permanently lubricated ball bearings |
| Fans have lead wires for power connection with ends stripped 1/2 in (12 mm) |
| All mounting hardware and installation instructions are furnished |
| Engineered for 50000 hr of continuous operation without lubrication or service (a monthly maintenance schedule is recommended to ensure optimal cooling performance) |
| ABS composite grille is black |
| TFP side-mount fans provide reliable cooling for enclosures with limited space requiring simple filtered airflow for basic cooling |
