YG-1
YG-1 DH453103 10.3 x 12 x 114 x 162 CARBIDE DREAM DRILL INOX W/ COOLANT (8XD)
YG-1
YG-1 DH453103 10.3 x 12 x 114 x 162 CARBIDE DREAM DRILL INOX W/ COOLANT (8XD)
SKUPDW~10955689
MFGR #DH453103
Your Cost: $605.40/ea
YG-1 is a manufacturer of high-quality drills, taps, end mills, spade drills, and rotary tooling. Refer to the sections below for all specifications and product details.
YG-1 is a manufacturer of high-quality drills, taps, end mills, spade drills, and rotary tooling. Refer to the sections below for all specifications and product details.
Application Steel, Stainless Steel Catalog Number DH453103 Country of Origin KR Cutting Depth 8XD Cutting Direction Right Hand Cutting Edge Material Micrograin Solid Carbide Finish TiAIN Flute Length 114 mm Flute Type Spiral Gross Weight Per Pack 0.3200 lb Helix Angle 30 ° Industry Standard DIN 6537 Number of Flutes 2 Point Angle 140 ° Point Length 1.8744 mm Series DH453 Shank Size 12 mm Shank Tolerance h6 Shank Type Straight Specifications Met DIN 6537 Through Coolant Yes Type Dream Drills INOX with coolant holes Brand YG-1 Manufacturer YG-1 U.S.A. Applicable Materials Alloy Steel, Carbon Steel, Pre-Hardened Steel and Stainless Steel Drill Point Length 1.874 Material Carbide Overall Length 162 mm Drill Size 10.3 mm Steel, Stainless Steel
content loaded
content loaded
content loaded
- Attributes
- Applications
- Substitute Products
| Application | Steel, Stainless Steel |
| Catalog Number | DH453103 |
| Country of Origin | KR |
| Cutting Depth | 8XD |
| Cutting Direction | Right Hand |
| Cutting Edge Material | Micrograin Solid Carbide |
| Finish | TiAIN |
| Flute Length | 114 mm |
| Flute Type | Spiral |
| Gross Weight Per Pack | 0.3200 lb |
| Helix Angle | 30 ° |
| Industry Standard | DIN 6537 |
| Number of Flutes | 2 |
| Point Angle | 140 ° |
| Point Length | 1.8744 mm |
| Series | DH453 |
| Shank Size | 12 mm |
| Shank Tolerance | h6 |
| Shank Type | Straight |
| Specifications Met | DIN 6537 |
| Through Coolant | Yes |
| Type | Dream Drills INOX with coolant holes |
| Brand | YG-1 |
| Manufacturer | YG-1 U.S.A. |
| Applicable Materials | Alloy Steel, Carbon Steel, Pre-Hardened Steel and Stainless Steel |
| Drill Point Length | 1.874 |
| Material | Carbide |
| Overall Length | 162 mm |
| Drill Size | 10.3 mm |
| Steel, Stainless Steel |
